Parking assistance sensor rear, replacing
Special tools
9814214
Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.
Scheme 171
Ignition off.
Remove the rear bumper. See: Bumper rear, replacing .
Method content
This method consists of
- See «Parking assistance sensor rear, replacing»(/volvo/s60/i-2004-2009/remont/collisionavoidance/#parking-assistance-sensor-replacing)
- See «Connector parking assistance module (PAM), replacing»(/volvo/s60/i-2004-2009/remont/collisionavoidance/#parking-assistance-sensor-replacing) .
Scheme 172
Remove the 4 connectors.
Depress: 9814214 between the sensor and the 2 standing catches located on the holder. Ensure that the catches release from the sensor.
Carefully pull up the sensor.
Install parking assistance sensor
Install
- the sensor in the holder. Press the sensor down so that the catches lock the sensor
- the 4 connectors.
For finishing work, see: Installing the rear bumper .
Scheme 173
Remove the left-hand side panel in cargo compartment.
Note. The control module is located behind the left-hand wheel arch in the cargo compartment.
| CAUTION | The following procedure must be carried out to ensure that the connector and wiring are not damaged when removing the bumper foam. |
Follow the cable from the connector for the sensors in the bumper up to the control module.
Remove the connector.
Note. Disconnect the correct connector. The control module has 2 connectors.
Scheme 174
Pull the cable out of the hole in the body.
Install connector parking assistance module (PAM)
Route the cable through the lead-in in the rear section. See the illustration.
Install
- the connector
- the left-hand side panel in the cargo compartment.
For finishing work, see: Installing the rear bumper .
Install rear bumper
Install the rear bumper. See: Bumper rear, replacing .
