| B5244S4 | B5244S5 | B5244S7 | |
|---|---|---|---|
| Engine code | 38 | 66 | 39 |
| Power (kw/rpm) | 125/6000 | 103/6000 | 123/6000 |
| Max torque (Nm/rpm) | 230/1500-4800 | 220/4000 | 230/4000 |
| Max rpm | 6500/6800 | 6500/6800 | 6500/6800 |
| Idling (rpm) | 720 | 720 | 720 |
| Cylinder bore (mm) | 83 | 83 | 83 |
| Stroke (mm) | 90 | 90 | 90 |
| Swept volume (liters) | 2.435 | 2.435 | 2.435 |
| Firing sequence | 1-2-4-5-3 | 1-2-4-5-3 | 1-2-4-5-3 |
| Engine control system | Denso | Denso | Denso |
| Weight, complete, including oil (kg) | 150 | 150 | 150 |
GENERAL DATA
Scheme 183
The engine serial number and type are stamped on the left side of the cylinder block at the top of the mounting for the water pump.
There is also a decal on the timing casing with the engine type, manufacturing number, and serial number.
Scheme 184
The marking is stamped into the engine block and crankshaft. The classification marking is in the engine block above the oil cooler and crankshaft. The classification shall be read from the digit 1 to 6. The first letter after the digit 1 corresponds to the classification of main bearing 1. The bearing positions are numbered starting at the engine's leading edge.
- Classification cylinder block
- Classification crankshaft
- Cylinder block
- Intermediate section
Scheme 185
| Standard | |
|---|---|
| C-marked mm | 83.000-83.010 |
| D-marked mm | 83.010-83.020 |
| E-marked mm | 83.020-83.030 |
CYLINDER BORE (D)
Scheme 186
| Length mm | 0.7-1.0 |
Scheme 187
| Standard | The diameter is measured 12 mm from the bottom of the piston |
|---|---|
| C-marked 1 mm | 82.950-82.960 |
| D-marked 1 mm | 82.960-82.970 |
| E-marked 1 mm | 82.970-82.980 |
| Classification is marked on the top of the piston. | |
PISTONS
| Tolerance piston/cylinder - top mm | 0.010 - 0.030 |
PISTON RUNNING CLEARANCE
| Top ring mm | 1.2-0.01/-0.03 |
|---|---|
| 1st ring mm | 1.5-0.01/-0.03 |
| Oil ring mm | 2-0.01/-0.136 |
PISTON RINGS
| Diameter mm | 21.000 0.000/-0.004 |
|---|---|
| Length mm | 57.0 0.0/+0.2 |
PISTON PIN
Scheme 188
| Intake | |
|---|---|
| Length (A) mm | 102.00 ± 0.07 |
| Diameter on crown (B) mm | 31 ± 0.15 |
| Diameter on shaft (C) mm | 5.94 ± 0.07 |
| Valve angle (D) ° | 45.5 ± 0.17 |
| Clearance in guide μm | 50 - 70 |
| Valve clearance mm | 0.20 ± 0.03 |
| Exhaust | |
| Length (A) mm | 101.05 ± 0.07 |
| Diameter on crown (B) mm | 27 ± 0.15 |
| Diameter on shaft (C) mm | 5.94 ± 0.07 |
| Valve angle (D) ° | 45.5 ± 0.17 |
| Clearance in guide μm | 50 - 70 |
| Valve clearance mm | 0.40 ± 0.03 |
VALVES
| Seat angle ° | 45.5 ± 0.17 |
VALVE SEATS
| Diameter mm | 32-0.025/-0.040 |
|---|---|
| Length mm | 2.950 - 3.685 ± 0.01 |
TAPPETS
| Max. lift height inlet mm | 8.68 |
|---|---|
| Max. lift height exhaust mm | 9.05 |
CAMSHAFTS
