Engine Control Module (ECM) - Component Location (544 Body): Overview Volvo S40 II

Engine Control Systems 2 illustrations

Scheme 41

Scheme 41: LOCATION OF COMPONENTS, ENGINE COMPARTMENT (2004, 2005, 2006, 2007)

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentLocated at/on
1Injectors (5 x)The intake manifold.
2Intake camshaft reset valveEngine, timing belt side, the by camshaft.
3A/C pressure sensorAir conditioning (A/C) system high pressure pipe (thin pipe).
4Air conditioning (A/C) pressure switchAir conditioning (A/C) system low pressure pipe (thick pipe).
5Ignition coil (5 x)The cylinder head.
6Evaporative emission system (EVAP) valveCylinder block, by cowl panel.
7Camshaft position (CMP) sensor, intakeEngine, flywheel side, by the camshaft.
8Integrated relay/fusebox
9Engine speed (RPM) sensorAbove the flywheel.
10Mass air flow (MAF) sensor and intake air temperature (IAT) sensor, intakeThe intake manifold.
11Engine coolant temperature (ECT) sensorThe thermostat housing.
12Pressure sensor, intakeEngine, flywheel side.
13Engine control module (ECM)The air cleaner (ACL) module.
14Knock sensor (KS)The cylinder block, under the air cleaner (ACL) module.
15Engine cooling fan (FC) control module
16Oil pressure switchLower front edge of the engine.
17Throttle unitThe intake manifold.
18Fuel pressure/fuel temperature sensorFuel rail right face

Scheme 42

Scheme 42: LOCATION OF COMPONENTS, ENGINE COMPARTMENT (2008, 2009, 2010)

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentLocated at/on
1Injectors (5 x)The intake manifold.
2Intake camshaft reset valveEngine, timing belt side, the by camshaft.
3A/C pressure sensorAir conditioning (A/C) system high pressure pipe (thin pipe).
4Air conditioning (A/C) pressure switchAir conditioning (A/C) system low pressure pipe (thick pipe).
5Ignition coil (5 x)The cylinder head.
6Evaporative emission system (EVAP) valveCylinder block, by cowl panel.
7Camshaft position (CMP) sensor, intakeEngine, flywheel side, by the camshaft.
8Integrated relay/fusebox
9Engine speed (RPM) sensorAbove the flywheel.
10Mass air flow (MAF) sensor + intake air temperature (IAT) sensor, intakeThe intake manifold.
11Engine coolant temperature (ECT) sensorThe thermostat housing.
12Pressure sensor, intakeEngine, flywheel side.
13Engine control module (ECM)The air cleaner (ACL) module.
14Knock sensor (KS)The cylinder block, under the air cleaner (ACL) module.
15Engine cooling fan (FC) control module
16Oil level sensorPlaced in the oil sump
17Oil pressure switchLower front edge of the engine.
18Throttle unitThe intake manifold.
19Fuel pressure/fuel temperature sensorFuel rail right face
