METHOD CONTENT Volvo S40 II

METHOD CONTENT

This method consists of

1. See «PIPE/HOSE BETWEEN EVAPORATOR AND RECEIVER, REPLACING»(ref-460918-S16180975092012033000000)
2. See «PIPE/HOSE BETWEEN CONDENSER AND EXPANSION VALVE, REPLACING»(ref-460918-S38193860422012033000000)
3. See «PIPE BETWEEN EXPANSION VALVE AND EVAPORATOR, REPLACING»(ref-460918-S31225941992012033000000) .

Scheme 80

Remove

1. the coolant reservoir (1) but leave the hoses in place. Place the reservoir on the valve cover
2. the power steering fluid reservoir and hoses (2) from its mounting by pulling it upwards at an angle.

Remove

1. the ground strip (3) from the connection at the right-hand suspension turret
2. the 2 switches (4) for the air conditioning (A/C) system pressure sensor from the air conditioning (A/C) pipes/hoses
3. the front bumper cover. See «COVER BUMPER FRONT»(ref-461183-S00435842662012033000000) (2004-2009), «COVER BUMPER FRONT»(ref-461183-S38119309532012033000000) (B5244S4; B5244S7; 2010), or «COVER BUMPER FRONT»(ref-461183-S10882519572012033000000) (B5254T7; 2010-2011).
