REMOVING ENGINE COMPARTMENT COMPONENTS

Remove the air cleaner (ACL) module. See

Scheme 135

Scheme 135: REMOVING THE GEAR SELECTOR CABLE
Scheme 135: REMOVING THE GEAR SELECTOR CABLE

Note. Ensure that the cable and sleeve do not crack or break.

Remove

  1. the lever. Use: see «9997077»(ref-460875-S05662014872012033000000)
  2. the cable from the bracket. Move the cover sleeve backwards. Move the cable to one side.
  3. the oil line from the transaxle cover and the oil cooler. Plug the cover and the oil cooler using plastic plugs.

HINT: The quick-release connector for the oil line is detached by pressing the clutch housing towards the cover. Hold the clutch housing in this position. Pull back the lugs on the connection housing. Pull the connector off the cover and oil cooler.
