| B5244S4 | B5244S5 | B5244S7 | |
|---|---|---|---|
| Engine code | 38 | 66 | 39 |
| Power (kw/rpm) | 125/6000 | 103/6000 | 123/6000 |
| Max torque (Nm/rpm) | 230/1500-4800 | 220/4000 | 230/4000 |
| Max rpm | 6500/6800 | 6500/6800 | 6500/6800 |
| Idling (rpm) | 720 | 720 | 720 |
| Cylinder bore (mm) | 83 | 83 | 83 |
| Stroke (mm) | 90 | 90 | 90 |
| Swept volume (liters) | 2.435 | 2.435 | 2.435 |
| Firing sequence | 1-2-4-5-3 | 1-2-4-5-3 | 1-2-4-5-3 |
| Engine control system | Denso | Denso | Denso |
| Weight, complete, including oil (kg) | 150 | 150 | 150 |
GENERAL DATA
Scheme 149
The engine serial number and type are stamped on the left side of the cylinder block at the top of the mounting for the water pump.
There is also a decal on the timing casing with the engine type, manufacturing number, and serial number.
Scheme 150
The marking is stamped into the engine block and crankshaft. The classification marking is in the engine block above the oil cooler and crankshaft. The classification shall be read from the digit 1 to 6. The first letter after the digit 1 corresponds to the classification of main bearing 1. The bearing positions are numbered starting at the engine's leading edge.
- Classification cylinder block
- Classification crankshaft
- Cylinder block
- Intermediate section
Scheme 151
| Standard | |
|---|---|
| C-marked........ mm | 83.000-83.010 |
| D-marked........ mm | 83.010-83.020 |
| E-marked........ mm | 83.020-83.030 |
CYLINDER BORE (D)
Scheme 152
| Length........ mm | 0.7-1.0 |
Scheme 153
| Standard | The diameter is measured 12 mm from the bottom of the piston |
|---|---|
| C-marked 1 ........ mm | 82.950-82.960 |
| D-marked 1 ........ mm | 82.960-82.970 |
| E-marked 1 ........ mm | 82.970-82.980 |
| 1 Classification is marked on the top of the piston. | |
PISTONS
| Tolerance piston/cylinder - top........ mm | 0.010 - 0.030 |
PISTON RUNNING CLEARANCE
| Top ring........ mm | 1.2 - 0.01/-0.03 |
|---|---|
| 1st ring........ mm | 1.5 - 0.01/-0.03 |
| Oil ring........ mm | 2 - 0.01/-0.136 |
PISTON RINGS
| Diameter........ mm | 21.000 0.000/-0.004 |
|---|---|
| Length........ mm | 57.0 0.0/+0.2 |
PISTON PIN
Scheme 154
| Intake | |
|---|---|
| Length (A)........ mm | 102.00 ± 0.07 |
| Diameter on crown (B)........ mm | 31 ± 0.15 |
| Diameter on shaft (C)........ mm | 5.94 ± 0.07 |
| Valve angle (D)........° | 45.5 ± 0.17 |
| Clearance in guide........μm | 50 - 70 |
| Valve clearance........ mm | 0.20 ± 0.03 |
| Exhaust | |
| Length (A)........ mm | 101.05 ± 0.07 |
| Diameter on crown (B)........ mm | 27 ± 0.15 |
| Diameter on shaft (C)........ mm | 5.94 ± 0.07 |
| Valve angle (D)........° | 45.5 ± 0.17 |
| Clearance in guide........μm | 50 - 70 |
| Valve clearance........ mm | 0.40 ± 0.03 |
VALVES
| Seat angle........° | 45.5 ± 0.17 |
VALVE SEATS
| Diameter........ mm | 32 -0.025/-0.040 |
|---|---|
| Length........ mm | 2.950 - 3.685 ± 0.01 |
TAPPETS
| Max. lift height inlet........ mm | 8.68 |
|---|---|
| Max. lift height exhaust........ mm | 9.05 |
CAMSHAFTS
