VVT UNIT Volvo C70 II рестайлинг

Engine - Removal and Installation 9 illustrations ~137 words

VVT UNIT

Special Tools 999 5452 CAMSHAFT ADJUSTMENT TOOL (alignment-camshaft) B6304 Tool number: 999 5452 Tool description: CAMSHAFT ADJUSTMENT TOOL(alignment-camshaft) B6304 Tool boards: 21 999 5451 ADJUSTMENT TOOL (ALIGNMENT-CRANKSHAFT) B6304 B5254 Tool number: 999 5451 Tool description: ADJUSTMENT TOOL (ALIGNMENT-CRANKSHAFT) B6304 B5254 Tool boards: 21

Scheme 140

Scheme 140: VVT UNIT
Scheme 140: VVT UNIT

Remove the following items

  1. See «AIR CLEANER HOUSING»(ref-488474-S41269173262012072500000)
  2. See «TIMING BELT»(ref-488481-S37477604972012072500000)
  3. See «STARTER MOTOR»(ref-488509-S38268060042012072500000)

Scheme 141

Scheme 141
Scheme 141

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144

see 9995452

Scheme 145

Scheme 145
Scheme 145

Note. Only tighten the bolts finger tight at this stage.

Scheme 146

Scheme 146
Scheme 146

see 9995451

Install timing belt. See TIMING BELT

Scheme 147

Scheme 147
Scheme 147

Torque: VVT unit, center screw

120 Nm

Scheme 148

Scheme 148
Scheme 148
  1. Torque: M10 50 Nm
  2. Torque: M6 10 Nm

Install the following items

  1. See «STARTER MOTOR»(ref-488509-S38268060042012072500000)
  2. See «TIMING BELT»(ref-488481-S02588809912012072500000)
CAUTIONMake sure that the inside of the pipe ends are clean and free of oil residue.

Torque: M6

10 Nm

Install the air filter housing. See AIR CLEANER HOUSING
