Wiring diagram: Body control modules — Body control modules circuit Volvo C70 II
All systems
- Air conditioning 2
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.5l turbo
- Exterior lights 3
- Ground distribution
- Headlights 3
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 2
- Navigation 4
- Power distribution
- Power door locks 3
- Power mirrors 2
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlock
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 2
Body control modules circuit (1 of 2) Volvo C70 II
Components on the diagram
Body control modules circuit (2 of 2) Volvo C70 II
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
