Central Electronic Module (Cem) - Component Location: Overview Volvo C70 II

Body Electrical 9 illustrations ~293 words

Scheme 448

Scheme 448: CENTRAL ELECTRONIC MODULE (CEM), LOCATION OF COMPONENTS
Scheme 448: CENTRAL ELECTRONIC MODULE (CEM), LOCATION OF COMPONENTS

central electronic module (CEM)

  1. central electronic module (CEM)

Scheme 449

Scheme 449
Scheme 449

Secondary Battery

  1. Secondary battery (only on vehicles with the function Automatic start/stop of engine).

Scheme 450

Scheme 450
Scheme 450

Lighting exterior, front

  1. Low beam
  2. High beam
  3. Parking lamps
  4. Turn signal lamps
  5. Side marking
  6. Turn signal lamp door mirror
  7. Local lighting
  8. Fog lamps

Scheme 451

Scheme 451
Scheme 451

Lighting exterior, rear

  1. Stop lamps
  2. Tail lamps
  3. Turn signal lamps
  4. Back-up (reversing) lamps
  5. Fog tail lamps
  6. License plate lighting
  7. High level stop lamp.

Scheme 452

Scheme 452
Scheme 452

Inner lighting

  1. Front interior lighting
  2. Rear interior lighting
  3. Lighting glove compartment
  4. Courtesy lighting left
  5. Courtesy lighting right.

Scheme 453

Scheme 453
Scheme 453

Warning and indicator lamps

  1. Seat belt reminder
  2. PAD lamp
  3. PAE lamp (2008-)
  4. MIL lamp
  5. Alarm diode
  6. Indication reduced alarm
  7. Indicator lamp hazard warning signal flashers
  8. Indicator lamp fog lamp front
  9. Indicator lamp fog lamp rear.

Scheme 454

Scheme 454
Scheme 454

Sensors

  1. Battery temperature (removed from and including structure week 200605)
  2. Outside temperature
  3. Fuel level
  4. Clutch pedal
  5. Accelerator pedal (AP) position sensor
  6. Twilight sensor
  7. Sun sensor
  8. Position sensor GDL front
  9. Position sensor GDL rear.
  10. Humidity sensor (HUS) (2008-)

Scheme 455

Scheme 455
Scheme 455

LIN nodes

  1. Wiper motor module (WMM)
  2. Rain sensor module (RSM)
  3. Gas discharge lamp module (GDL), left (does not apply to S40/V50, 2008-)
  4. Gas discharge lamp module (GDL), right (does not apply to S40/V50, 2008-)
  5. Siren control module (SCM)
  6. Remote Receiver Module (RRX)
  7. Remote Keyless Entry (RKE)
  8. Steering column lock module (SCL)
  9. Start control module (SCU)
  10. Battery monitoring sensor (only on vehicles with the function brake energy regeneration)

Scheme 456

Scheme 456
Scheme 456

Alarm components

  1. Siren control module (SCM)
  2. Alarm diode
  3. Mass movement sensor module (MMS)
  4. Ajar position sensor, left front
  5. Ajar position sensor, right front
  6. Ajar position sensor, left rear
  7. Ajar position sensor, right rear
  8. Switch hood
  9. Switch trunk lid / tailgate
  10. Switch reduced alarm.
