REMOVAL
Remove the cylinder head. See CYLINDER HEAD
INSTALLATION
Install cylinder head. See CYLINDER HEAD
Remove the cylinder head. See CYLINDER HEAD
Install cylinder head. See CYLINDER HEAD
Remove timing belt. See TIMING BELT
Install timing belt. See TIMING BELT
Remove timing belt. See TIMING BELT
Install timing belt. See TIMING BELT
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: Piston cooling nozzle
32 Nm
Scheme 183
Note. Make sure that the classification of the components correspond with each other.
For information about engine. See ENGINE
Scheme 184
Note. Make sure that the classification of the components correspond with each other.
For information about engine. See ENGINE
Scheme 185
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Scheme 186
| CAUTION | Take extra care when handling the components. |
| CAUTION | Make sure that the crankshaft is not rotated. |
Scheme 187
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Scheme 188
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Scheme 189
Torque: Intermediate section for engine block step 1
20 Nm
Torque: Intermediate section for engine block step 2
40 Nm
Scheme 190
Torque: Intermediate section for engine block step 3
24 Nm
Scheme 191
Torque: Intermediate section for engine block step 4
17 Nm
Torque: Intermediate section for engine block step 5
90°
Scheme 192
Note. Make sure that the classification of the components correspond with each other.
For information about engine. See ENGINE
Scheme 193
Scheme 194
For information about engine. See ENGINE
Scheme 195
Scheme 196
Note. Make sure that the classification of the components correspond with each other.
Scheme 197
Scheme 198
see 9995746
Note. Make sure that the classification of the components correspond with each other.
Torque: Cap connecting rod
Stage 1: 30 Nm
Stage 2: 90°
Torque: M7
17 Nm
Scheme 199
see 9997273
Scheme 200
| CAUTION | Make sure that the gaskets are correctly located. |
Scheme 201
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Torque: M7
17 Nm
Torque: M7
17 Nm
Torque: M10
50 Nm
Scheme 202
see 9997174
| CAUTION | Take extra care not to damage the mating faces. |
see 9995651
| CAUTION | Note the position of the components before removal. |
| CAUTION | Take extra care when handling the components. |
see 9995746
| CAUTION | Take extra care not to damage the mating faces. |
| CAUTION | Take extra care when handling the components. |
Note. Only use moderate force.
| CAUTION | Take extra care when handling the components. |
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
Note. Make sure that the classification of the components correspond with each other.
For information about engine. See ENGINE
Note. Make sure that the classification of the components correspond with each other.
For information about engine. See ENGINE
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
| CAUTION | Take extra care when handling the components. |
| CAUTION | Make sure that the crankshaft is not rotated. |
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Torque: Intermediate section for engine block step 1
20 Nm
Torque: Intermediate section for engine block step 2
40 Nm
Torque: Intermediate section for engine block step 3
24 Nm
Torque: Intermediate section for engine block step 4
17 Nm
Torque: Intermediate section for engine block step 5
90°
Note. Make sure that the classification of the components correspond with each other.
For information about engine. See ENGINE
Scheme 203
For information about engine. See ENGINE
Note. Make sure that the classification of the components correspond with each other.
see 9995746
Note. Make sure that the classification of the components correspond with each other.
Torque: Cap connecting rod
Stage 1: 30 Nm
Stage 2: 90°
Torque: M7
17 Nm
see 9997273
| CAUTION | Make sure that the gaskets are correctly located. |
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Torque: M7
17 Nm
Torque: M7
17 Nm
Torque: M10
50 Nm
see 9997174
