SERPENTINE BELT ROUTING
| CAUTION | New belt with new belt routing was introduced for 850 Model with A/C. Belt part number is 9434341-5. (Scheme 2) |
Scheme 1
Scheme 2
| Model | Specification |
|---|
| Coolant Replacement Interval | (1) |
| Coolant Capacity |
| 850 |
| Non-Turbo | 7.6 Qts. (7.2L) |
| Turbo | 7.4 Qts. (7.0L) |
| 960 | 10.5 Qts. (10L) |
| Thermostat Opens |
| Starts (2) | 186°F (90°C) |
| Fully Open | 216°F (102°C) |
| (1) Manufacturer does not require routine coolant replacement. (2) Turbo thermostat starts opening at 180°F (87°C). |
| (1) | Manufacturer does not require routine coolant replacement. |
| (2) | Turbo thermostat starts opening at 180°F (87°C). |
COOLING SYSTEM SPECIFICATIONS
Electric Cooling Fan System Schematic (850). Scheme 3
Scheme 3: Electric Cooling Fan System Schematic (850)
Electric Cooling Fan System Schematic (960). Scheme 4
Scheme 4: Electric Cooling Fan System Schematic (960)
