Contents Section: Automatic Trans All sections

Shift Interlock Systems Volvo 960 I

Automatic Trans 22 illustrations ~493 words

SHIFT LOCK

Note. Numbers and letters in parenthesis refer to numbers and letters in illustrations. (Scheme 14)or (Scheme 15).

To prevent inadvertent movement of gear selector lever from position P, cars in certain markets are also equipped with an electrically operated shift lock function which blocks gear selector detent pin (1) in latch segment and locks mechanism in parking position (Scheme 14)(A).

To move lever from this position, ignition must be switched on and brake pedal depressed. Switching on ignition while depressing brake pedal activates a solenoid (2) in gear selector unit.

The solenoid locking pin (3) is pressed inward, enabling release button on lever to be pressed on normal manner and another position to be selected. (Scheme 14)(B).

KEYLOCK & SHIFT LOCK

Note. Numbers and letters in parenthesis refer to numbers and letters in illustrations. (Scheme 14)or (Scheme 15).

In certain marketed, these functions are complemented by yet another safety feature in form of a keylock operated mechanically by a cable connected to ignition switch. The function is controlled by position of locking plunger (4) in ignition switch and by position of gear selector lever. This means that the lever must be in position P before key can be withdrawn from switch, also that key must be turned to position 1 or 2 before lever can be moved from that position. The key lock function is used only in combination with shift lock and was introduced in conjunction with modified gear selector lever installed in models from 1993 on.

The shift lock mechanism can be released to move gear selector from P position if battery is disconnected or in event of a fault in shift lock system. The mechanical release consists of a pushbutton (5) marked SHIFT-LOCK OVERRIDE on gear lever. When button is depressed, solenoid locking pin (3) is released, enabling lever to be moved from position P. (Scheme 15)(C). (in earlier models, mechanical release was located under gear lever brush beside text SHIFT-LOCK RELEASE.)

Note. On cars with key lock feature, ignition key must be first turned to position 1 or 2.

As long as fault persists, mechanical release and key must be used each time lever is to be moved from position P. The electrical circuit between brake light switch and solenoid incorporates a microswitch (6), which closes circuit only in position P to prevent operation of solenoid when driver operates brake pedal while driving.

START INHIBITOR FUNCTION

The gear selector lever is provided with a start inhibit function to prevent starting of engine while gear is selected. this feature ensures that engine can be started only in position "P" or "N", preventing vehicle from moving accidentally at the instant of starting.

Scheme 14

Scheme 14: START INHIBITOR FUNCTION

Scheme 15

Scheme 15

Scheme 16

Scheme 16: BASIC ADJUSTMENT (1991-92)

Scheme 17

Scheme 17: ADJUSTING CLEARANCE (1991-92)

Scheme 18

Scheme 18: GEAR SELECTOR UNIT (1991-92) - (GF)

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22: GEAR SELECTOR MECHANISM (1993-95) - (GG)

Scheme 23

Scheme 23

Scheme 24

Scheme 24: GEAR LEVER UNIT (1993-95) - (GH)

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29: SHIFT LOCK SOLENOID (1991-92) - (GJ)

Scheme 30

Scheme 30

Scheme 31

Scheme 31: KEY LOCK CABLE REPLACEMENT - (GK)

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35
