Removal & Installation
Raise window up all the way and secure in position with duct tape. Remove door trim panel (Scheme 1) Remove plastic cover. Remove power window motor retaining bolts. (Scheme 2) Disconnect motor electrical connector. Lift out motor. To install, reverse removal procedure.
Scheme 1
Scheme 2
- Disconnect negative battery cable. remove screws from front of ash tray. Pull back and remove ash tray. (Scheme 3) Remove cigarette lighter and light harness connector. Remove panel under parking brake lever. Remove cover from center console storage compartment.
- Remove screws in center console front storage compartment. (Scheme 4) Remove harness connector at front of center console front storage compartment. (Scheme 5) Pull center console upwards. In vehicles equipped with manual transmission, undo gearshift curtain at connection to center console before removing center console. Go to next step.
- Remove harness connector to power window motor control panel. Remove harness connector to autodown relay. Remove clip from control panel wiring harness. Remove control panel push-in hooks on clip and push out on control panel. To install, reverse removal procedure.
