Fuses & Circuit Breakers Volvo 850 I

FUSE PANEL LOCATION

The fuse panel is located in the engine compartment. A label on the inside of the cover lists the fuse amperage and circuits protected.

Scheme 1

1. 1 - 15 Amp Fuel Injection, Distributor Ignition, Automatic Gearbox
2. 2 - 15 Amp Fuel Pump, Alarm System
3. 3 - 10 Amp Courtesy Lights, Oil Level Sensor
4. 4 - Not Used (1993-95)
5. 4 - 10 Amp (1996) Electronic Start Inhibitor (Immobilizer)
6. 5 - 30 Amp ECC Blower (Speed 4)
7. 6 - 25 Amp Central Locking System, Alarm
8. 7 - 15 Amp Audio System (Amplifier)
9. 8 - 25 Amp (1993-95) Power Antenna, Trailer Connector
10. 8 - 40 Amp (1996) Electronic Start Inhibitor (Immobilizer)
11. 9 - 30 Amp ABS, Traction Control System
12. 10 - Not Used (1993-95)
13. 10 - 15 Amp (1996) Heated Rear Seat (If Equipped)
14. 11 - 30 Amp Heated Rear Window & Side Mirrors
15. 12 - 10 Amp Brake Lights
16. 13 - 15 Amp Hazard Flashers, Headlight Flashers, Alarm
17. 14 - 30 Amp ABS, Traction Control System
18. 15 - 10 Amp (1993-95) Audio System, Courtesy Lights, Door Open Light, Trunk Light, Glove Box Light, Remote Control Central Locking System, Oil Level Sensor, Seat Belt Reminder
19. 15 - 10 Amp (1996) Audio System, Courtesy Lights, Door Open Light, Trunk Light, Glove Box Light, Remote Control Central Locking System, Oil Level Sensor, Seat Belt Reminder, Data Link Connector
20. 16 - 30 Amp (1993-95) Accessories
21. 16 - 30 Amp (1996) Power Antenna, Trailer Connector, Accessories
22. 17 - 10 Amp Key Reminder
23. 18 - 25 Amp (1993-95) Heated Front Seats, Power Mirrors
24. 18 - 15 Amp (1996) Front Fog Lamps
25. 19 - 15 Amp Left High Beam Headlight
26. 20 - 15 Amp Right High Beam Headlight, High Beam Indicator
27. 21 - 15 Amp Left Low Beam Headlight
28. 22 - 15 Amp Right Low Beam Headlight
29. 23 - 10 Amp Left Parking Light, License Light
30. 24 - 10 Amp Right Parking Light, Bulb Failure Warning Sensor
31. 25 - 10 Amp Rear Fog Lamps, Fog Lamp Indicator
32. 26 - Not Used (1993-95)
33. 26 - 25 Amp (1996) Heated Front Seats, Power Mirrors
34. 27 - 15 Amp Back-Up Lights, Turn Signals
35. 28 - 10 Amp Cruise Control, Heated Rear Window, Seat Belt Reminder Light, Shiftlock, Bulb Failure Warning Sensor, Heated Rear Seat
36. 29 - 15 Amp ABS, Traction Control System
37. 30 - 10 Amp Cigarette Lighter
38. 31 - 25 Amp ECC, ECC Blower (Speeds 1-3)
39. 32 - 10 Amp Audio System, Remote Controlled Central Locking System
40. 33 - 15 Amp (1993-95) Power Seats, OBD Test Socket, Tailgate Washer/Wipe (Wagon)
41. 33 - 15 Amp (1996) Power Seats, Tailgate Washer/Wipe (Wagon)
42. 34 - 25 Amp Windshield Wiper/Washer, Horn, Headlight Washer/Wiper
43. 35 - 10 Amp Instrument Lights, Sun Roof, Traction Control System
44. 36 - Not Used
45. 37 - Circuit Breaker Power Windows, Power Sun Roof
46. 38 - Not Used
47. 39 - Circuit Breaker Drivers Power Seat
48. 40 - Circuit Breaker Passengers Power Seat

RELAY PANEL LOCATION

The relay panel is located at the left corner of the instrument panel.

Scheme 2

1. A - Control Module, Cruise Control
2. B - Fuel Pump Relay
3. C - Main Headlight Relay with Bulb Malfunction Indicator
4. D - Overload Relay (+X Supply)
5. E - Overload Relay (+15 Supply)
6. F - Overload Relay (+X Supply)
7. G - Oil Level Sensor Control Module (or Lamp Monitor) (1993-95), Fog Lamp Relay (1996)
8. H - Deadlock Setting Relay
9. I - Intermittent Windshield Wiper Relay
10. J - Intermittent Wiper Relay (Rear Tailgate - Wagon)
11. K - Central Lock and Delayed Inside Lighting Relay
12. L - Speed Warning Relay
13. M - Heated Rear Window and Door Mirror Relay
14. N - Not Used
15. O - Anti-Theft Alarm Relay
16. P - Seat Belt Reminder/Key Warning Relay
17. Q - Parking Position Lock (1993-95) Front Fog Lamp Relay (Bridged if not equipped)(1996)
18. R - Heated Rear Seat Relay
19. S - Not Used
