A/c-Heater System - Automatic: Specifications Volvo 850 I

Automatic HVAC System 4 illustrations

A/C SYSTEM SPECIFICATIONS

ApplicationSpecification
Compressor TypeZexel DKS-15CH 6-Cyl.
Compressor Belt Tension(1)
Compressor Oil Capacity(2) 7.0 ozs.
Refrigerant (R-134a) Capacity
Cold Climates29.1 ozs.
Hot Climates26.5 ozs.
System Operating Pressures(3)
(1) Belt tension is maintained by automatic belt tensioner. (2) Use PAG Oil (Part No. 11 61 407-0). (3) Information is not available. To verify proper system operation, perform A/C SYSTEM PERFORMANCE test under TESTING.
(1)Belt tension is maintained by automatic belt tensioner.
(2)Use PAG Oil (Part No. 11 61 407-0).
(3)Information is not available. To verify proper system operation, perform A/C SYSTEM PERFORMANCE test under TESTING.

AUTOMATIC A/C SYSTEM SPECIFICATIONS

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG RESTRAINT SYSTEM article in ACCESSORIES/SAFETY EQUIPMENT section.
CAUTIONWhen battery or radio is disconnected, radio will go into anti-theft protection mode. Obtain radio code anti-theft protection code from owner prior to servicing vehicle.

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Compressor Bracket Bolt30 (40)
Compressor Inlet Fitting15 (20)
Compressor Outlet Fitting33 (45)
Compressor Pipe Flange Bolt18 (24)
Expansion Valve22 (30)
Receiver-Drier Connection22 (30)
INCH Lbs. (N.m)
High Pressure Sensor Connection7 (10)

TORQUE SPECIFICATIONS

Auto. A/C-Heater System Wiring Diagram (2.3L Turbo - 1 Of 2). Scheme 1

Scheme 1: Auto. A/C-Heater System Wiring Diagram (2.3L Turbo - 1 Of 2)
Scheme 1: Auto. A/C-Heater System Wiring Diagram (2.3L Turbo - 1 Of 2)

Auto. A/C-Heater System Wiring Diagram (2.3L Turbo - 2 Of 2). Scheme 2

Scheme 2: Auto. A/C-Heater System Wiring Diagram (2.3L Turbo - 2 Of 2)
Scheme 2: Auto. A/C-Heater System Wiring Diagram (2.3L Turbo - 2 Of 2)

Automatic A/C-Heater System Wiring Diagram (2.4L - 1 Of 2). Scheme 3

Scheme 3: Automatic A/C-Heater System Wiring Diagram (2.4L - 1 Of 2)
Scheme 3: Automatic A/C-Heater System Wiring Diagram (2.4L - 1 Of 2)

Automatic A/C-Heater System Wiring Diagram (2.4L - 2 Of 2). Scheme 4

Scheme 4: Automatic A/C-Heater System Wiring Diagram (2.4L - 2 Of 2)
Scheme 4: Automatic A/C-Heater System Wiring Diagram (2.4L - 2 Of 2)
