Wheel Alignment Specifications & Procedures Volvo 780 I

Wheel Alignment 1 illustration

Application				Specification
740, 760 & 780 Series
Front
Camber in Degrees
Fraction				7/16 +/- 3/16
Decimal				.44 +/- .19
Caster in Degrees
Fraction				5 +/- 1/2
Decimal				5.00 +/- .50
Toe-In in Inches
Fraction				3/32 +/- 1/32
Decimal				.09 +/- .03
Toe-In in Degrees
Fraction				3/16 +/- 1/16
Decimal				.19 +/- .06
760 Series
Rear
Camber in Degrees
Fraction				1/2 +/- 1/4
Decimal				.50 +/- .25
Toe-In in Inches
Fraction				0 +/- 3/64
Decimal				0 +/- .05
Toe-In in Degrees
Fraction				0 +/- 1/8
Decimal				0 +/- .13

WHEEL ALIGNMENT SPECIFICATIONS

Rear Adjustment. Scheme 1

Scheme 1: Rear Adjustment

Scheme 1: Rear Adjustment

Note. Alignment procedures not available.
