Alternator & Regulator - Bosch Volvo 760 I

Charging System 2 illustrations ~945 words

DESCRIPTION

Bosch alternators are conventional 3-phase, self-rectifying type alternators. Bosch 55 through 75-amp alternators use 3 positive and 3 negative diodes connected to stator windings to rectify current. Bosch 80 and 90-amp alternators use 14 diodes.

All alternators use 3 exciter diodes connected to stator windings. These diodes turn off the alternator indicator light and supply power to the voltage regulator while the engine is running. Bosch regulators are transistorized solid state and integral with alternator.

WIRING CONTINUITY TEST

  1. Connect a voltmeter between alternator "B+" terminal and ground. Voltmeter should indicate battery voltage. If not, check wiring between alternator and battery.
  2. Turn ignition on and check that alternator indicator light comes on. If light does not come on, check wiring between alternator and warning light, including indicator bulb.

Exploded View of Bosch 55-Ampere Alternator. Scheme 1

Scheme 1: Exploded View of Bosch 55-Ampere Alternator
Scheme 1: Exploded View of Bosch 55-Ampere Alternator

VOLTAGE DROP TEST - POSITIVE SIDE

  1. Connect a voltmeter between positive battery terminal and alternator "B+" terminal.
  2. Start engine and run at 2000 RPM. Turn on headlights, rear window defogger, and heater blower. If voltage drop is more than 0.2 volts, check circuit between alternator "B+" terminal and starter for corroded or loose connections. Check circuit between starter and battery positive terminal.

VOLTAGE DROP TEST - GROUND SIDE

  1. Connect a voltmeter between negative battery terminal and alternator housing. Start engine and run at 2000 RPM.
  2. Turn on headlights, rear window defogger, and heater blower. On either model, if voltage drop is more than .2 volts, check battery terminals, vehicle, and engine ground for corroded or loose connections.

OUTPUT TEST

  1. Ensure connections at battery, alternator, and starter (most vehicles) are clean and tight. Ensure alternator, engine and body are properly grounded. Ensure alternator drive belt is tight and in good condition.
  2. Connect ammeter following manufacturer's instructions. Connect voltmeter leads to battery terminals.
  3. Start engine and run at 3000 RPM. Adjust carbon pile on tester to obtain maximum alternator output. Do not allow voltage to go below 12.6 volts.
  4. Alternator output should equal alternator rated output, minus 16-20 amps. If reading is 16-20 amps below alternator rating, replace regulator and retest. If output is still too low, repair or replace alternator.

REGULATOR CONTROL VOLTAGE TEST

  1. Connect ammeter following manufacturer's instructions. Connect voltmeter leads to battery terminals. Start engine and run at 3000 RPM.
  2. Run engine until voltage stops rising. Voltage should be 13.5-14.5 volts. If reading is incorrect, remove regulator and ensure brushes are longer than 7/32" (6 mm). Replace if necessary.
  3. If brushes are okay and regulator fails to keep voltage within specified limits, replace regulator and retest. If voltage is still incorrect, repair or replace alternator.

Note. On Volvo alternators, if old (rectangular) style regulator is being replaced with new (round) style regulator, replace regulator attaching screws. Replacement Screws (1323069-3 ) should be used. If old screws (18 mm or longer) are used, they will contact diode assembly, causing a short circuit.

Diode Assembly

  1. Place ohmmeter scale on x100 scale. Connect ohmmeter leads across "B+" terminal and 3 stator terminals one at a time. Reverse leads. Ohmmeter should indicate continuity in one direction only.
  2. Connect ohmmeter leads across negative plate and 3 stator terminals one at a time. (Scheme 2) Reverse leads. Ohmmeter should indicate continuity in one direction only.
  3. Connect ohmmeter leads across "D+" terminal and 3 stator terminals one at a time. Reverse leads. Ohmmeter should indicate continuity in one direction only. If diodes are found to be defective, replace diode assembly.

Bosch Diode Assembly Test Diode assembly for 55-amp alternator is shown. Others are similar. Scheme 2

Scheme 2: Bosch Diode Assembly Test Diode assembly for 55-amp alternator is shown. Others are similar.
Scheme 2: Bosch Diode Assembly Test Diode assembly for 55-amp alternator is shown. Others are similar.

Stator

  1. Place ohmmeter on lowest scale. Connect ohmmeter across stator leads. Resistance between leads should be .14-.15 ohms for 55-amp alternator and .09-.10 ohms for 65 through 90-amp alternators. If resistance is incorrect, stator has open or shorted windings and must be replaced.
  2. Place ohmmeter on x1000 scale. Connect ohmmeter between stator core and stator lead. No continuity should exist. If continuity exists, stator is grounded and must be replaced.

Rotor

  1. Place ohmmeter on lowest scale. Connect ohmmeter across slip rings. Resistance should be 3.4-3.8 ohms for 55-amp alternator and 2.8-3.1 ohms for 65 through 90-amp alternators.
  2. If resistance is too low, rotor has short circuit and must be replaced. If resistance is infinity (no continuity), rotor has open circuit and must be replaced.
  3. Place ohmmeter on x1000 scale. Connect ohmmeter between either slip ring and rotor core. No continuity should exist. If continuity exists, rotor is grounded and must be replaced.
  4. Clean slip rings using fine sandpaper. Rings which are worn or pitted should be turned on lathe. Minimum ring diameter is 1 1/16". If slip rings are beyond repair, replace slip rings as outlined in steps 5) and 6).
  5. Remove rear bearing from slip ring end of rotor. Unsolder wires from slip rings and bend up ends of rotor winding. Pull off slip rings. Ensure ends of rotor winding are not damaged.
  6. Insert ends of rotor winding into slip ring and press new slip ring onto rotor. Slip ring end must be 9/64" from end of collar. Solder rotor winding to slip ring terminals. Turn rings on lathe and retest rotor. Maximum slip ring run-out is .0012" (.03 mm).

Bearings

Always replace bearings. If replacement front bearing is sealed on one side only, open side must face rotor. If replacement rear bearing is sealed on one side only, open side must face away from rotor.

Brushes

Ensure brushes are longer than 7/32". Replace if necessary. Unsolder brushes from voltage regulator. Solder new brushes. Do not allow solder to run into strands of brush leads. Brushes must be free to slide in brush holder with normal spring tension of 10-14 ozs. (283-397 g).
