Maintenance Information Volvo 760 I

Procedures 26 illustrations ~3020 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

Scheme 2: VIN Code ID Explanation
Scheme 2: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Operating Conditions From Severe Service Schedule

Severe Service (Unique Driving Conditions)

  1. Extended Idling Or Low Speed Operation
  2. Frequent Short Trips Of Less Than 7 Miles
  3. Extended Operation In Dusty Or Sandy Conditions
  4. Trailer Towing Operations
  5. Driving In Mountainous Conditions

CAMSHAFT TIMING BELT (TURBO MODELS)

CAUTIONFailure to replace a faulty camshaft timing belt may result in serious engine damage.

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

  1. Cracks Or Tears In Belt Surface
  2. Missing, Damaged, Cracked Or Rounded Teeth
  3. Oil Contamination
  4. Damaged Or Faulty Tensioners
  5. Incorrect Tension Adjustment

Replace timing belt every 50,000 miles.

Scheme 3

Scheme 3: SERVICE POINT LOCATIONS
Scheme 3: SERVICE POINT LOCATIONS

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: VALVE CLEARANCE ADJUSTMENT - 2.8L V6
Scheme 5: VALVE CLEARANCE ADJUSTMENT - 2.8L V6

Note. For more information regarding valve clearance adjustments refer to the 2.8L V6 article in the ENGINE MECHANICAL section.

Scheme 6

Scheme 6: ADJUSTING IDLE MIXTURE - 2.8L V6
Scheme 6: ADJUSTING IDLE MIXTURE - 2.8L V6

Note. For more information regarding fuel system service refer to the TUNE-UP - V6 article in the ENGINE PERFORMANCE section.

Scheme 7

Scheme 7: PCV VALVE & FLAME TRAP MAINTENANCE POINTS - 2.8L V6
Scheme 7: PCV VALVE & FLAME TRAP MAINTENANCE POINTS - 2.8L V6

OXYGEN SENSOR WARNING LIGHT (760 GLE)

  1. Warning light in the dash will illuminate every 30,000 miles as a reminder to replace the oxygen sensor. After replacing sensor reset mileage counter.
  2. On 1986 760 GLE models, locate unit under dash (follow wires or small cable from back of speedometer to unit). Remove retaining screw and switch cover. Press reset button. Ensure reminder light is out. Install switch cover.
  3. On 1987-90 models there is no warning light used for oxygen sensor service intervals.

SERVICE INTERVAL REMINDER LIGHT 1988-90 (IF EQUIPPED)

  1. Service interval reminder light will come on at 5000 mile intervals to indicate oil and filter change is scheduled. After changing oil and filter, reset mileage counter.
  2. To reset counter on 1988-90 760, remove rubber grommet to left of odometer. Using a small screwdriver, depress reset knob. (Scheme 8)

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: ALIGNING CAMSHAFT TIMING MARKS - 2.3L TURBO
Scheme 9: ALIGNING CAMSHAFT TIMING MARKS - 2.3L TURBO

Note. For more information on camshaft timing belt service see the 2.1L 4-CYL TURBO, 2.3L 4-CYL & 2.3L 4-CYL TURBO article in the ENGINE MECHANICAL section.

Scheme 10

Scheme 10: VALVE CLEARANCE ADJUSTMENT - GASOLINE
Scheme 10: VALVE CLEARANCE ADJUSTMENT - GASOLINE

Note. For more information on valve clearance adjustments see the 2.1L 4-CYL TURBO, 2.3L 4-CYL & 2.3L 4-CYL TURBO article in the ENGINE MECHANICAL section.

Scheme 11

Scheme 11: ADJUSTING IDLE SPEED
Scheme 11: ADJUSTING IDLE SPEED

Note. For more information regarding fuel injection service refer to the TUNE-UP - 4-CYL article in the ENGINE PERFORMANCE section.

Scheme 12

Scheme 12: PCV VALVE MAINTENANCE POINTS
Scheme 12: PCV VALVE MAINTENANCE POINTS

Scheme 13

Scheme 13: ENGINE COOLANT REFILLING - TURBO
Scheme 13: ENGINE COOLANT REFILLING - TURBO

Scheme 14

Scheme 14: REFILLING AUTOMATIC TRANSMISSION FLUID (AW-71)
Scheme 14: REFILLING AUTOMATIC TRANSMISSION FLUID (AW-71)

Scheme 15

Scheme 15: MANUAL TRANSMISSION OVERDRIVE FILTER LOCATION (M46)
Scheme 15: MANUAL TRANSMISSION OVERDRIVE FILTER LOCATION (M46)

Scheme 16

Scheme 16: BODY SERVICE POINTS
Scheme 16: BODY SERVICE POINTS

Scheme 17

Scheme 17: VEHICLE LIFT POINTS
Scheme 17: VEHICLE LIFT POINTS

Note. For more information regarding lifting and hoisting refer to the JACKING & HOISTING article in the WHEEL ALIGNMENT section.

Scheme 18

Scheme 18: INFORMATION LABEL LOCATIONS
Scheme 18: INFORMATION LABEL LOCATIONS

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

LUBRICATION SPECIFICATIONS

CAUTIONDO NOT use SAE 15W-40 oil in extremely low ambient temperatures.

TIRE INFLATION

Tire specification label is located on the right front door.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 63 ft. lbs. (85 N.m) using pattern (Scheme 19)

Scheme 19

Scheme 19: TIRE ROTATION PATTERNS
Scheme 19: TIRE ROTATION PATTERNS

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

Gasoline engine vehicles use batteries with a 66 amp hour rating. Diesel engine vehicles use batteries with a 88 amp hour rating.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG)

Note. See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAR WARNING

Note. For information on air bag DIAGNOSIS & TESTING or DISPOSAL PROCEDURES, see AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

System circuit is grounded by 2 screws beneath the driver's seat. DO NOT use these screws to ground any other accessory. DO NOT ground any other components near this system.

ANTI-LOCK BRAKE SYSTEM

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.

REPLACING BLOWN FUSES

CAUTIONBefore replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE SYSTEM

CAUTIONIf brake warning light comes on while driving it indicates a low fluid level or failure in one of the braking circuits. If the brake pedal can be depressed further than normal it is an indication that one of the brake circuits is not functioning. Stop vehicle and check brake reservoir fluid level. If level is below MIN mark, DO NOT drive vehicle. Have it towed to a repair shop. If level is between the MIN and MAX marks, proceed cautiously to a repair shop.

BRAKE PAD WEAR INDICATOR

CAUTIONIndicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

CAUTIONContinued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.
CAUTIONAny modification to the exhaust system on turbo models, which reduces exhaust backpressure, will lead to lean fuel mixtures and excessive spark advance. This could cause serious engine damage.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

TURBOCHARGED MODELS

CAUTIONDo not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings.

WHEELS & TIRES

Only wheels tested and approved by the manufacturer should be used on models equipped with Air Dam aerodynamic components.

WARRANTY INFORMATION

CAUTIONAlways refer to customer's copy of warranty information for specific model application and/or coverage limitations.

BASIC WARRANTY (1983-90 MODELS)

The manufacturer warrants that repairs due to defects in material or workmanship, occurring under normal use, will be performed at no charge to the vehicle owner during period covered by the appropriate warranty. During the warranty period the warranty is fully transferable to subsequent owners. The warranty period is divided into 3 periods (1, 3 and 5 year). All periods begin the day the vehicle is delivered to the first retail customer or put into service, which ever comes first. The Basic Warranty covers the entire vehicle, with the exception of expendable items such as tires, for a period of 12 months with unlimited mileage.

MAJOR ASSEMBLY COVERAGE (1983-90 MODELS)

Covers the following items and components for a period of 36 months with unlimited mileage from warranty start date

  1. Engine And Cooling System
  2. Transmission And Driveshaft
  3. Rear Axle And Axle Shafts
  4. Brakes (Excluding Brake Pads)
  5. Steering
  6. Suspension (Excluding Shock Absorbers)
  7. Air Conditioning
  8. Computerized Engine Control Systems
  9. Electrical Components

CORROSION PROTECTION WARRANTY

Painted body panels are warranted against perforation for a period of 5 years. Structural damage due to rust or corrosion is warranted for 8 years.

SUPPLEMENTAL RESTRAINT SYSTEMS & SEAT BELTS

Factory installed seat belts or restraint systems are warranted for a period of 5 years.

EMISSION SYSTEM WARRANTY

Manufacturer warrants that the vehicle emission control system was designed and installed to conform, at the time of sale, to all applicable U.S. emission standards. The warranty covers repairs resulting from any defect in material or workmanship which could cause the vehicle not to meet emission standards during the warranty period. The warranty period is 5 years or 50,000 miles. The following items are not warranted

  1. Normal Scheduled Maintenance Of Emission Components
  2. Regular Maintenance Items
  3. Damage To Components Due To Accidents
  4. Damage Due To Contaminated Or Incorrect Fuels
  5. Any Component On A Vehicle With An Altered Odometer
  6. Damaged Caused By The Use Of Non-Genuine Parts

The following components are covered by Emission System or Emission Performance warranties

  1. Ignition Cables
  2. Distributor Components
  3. Ignition Coil
  4. Power Stage
  5. Ignition Control Unit
  6. Spark Plugs
  7. Knock Sensor
  8. Engine RPM Sensor
  9. Fuel Pressure Regulator
  10. Mass Airflow Meter
  11. Fuel Injection Control Unit
  12. Fuel Injectors
  13. Idle Air Valve
  14. Coolant Temperature Sensor
  15. Throttle Position Sensor
  16. Throttle Potentiometer
  17. Series Resistor
  18. Oxygen Sensor
  19. Cold Start Injector
  20. Temperature Sensor
  21. Manifold Pressure Sensor
  22. Camshaft Sensor
  23. Evaporative Emission System
  24. Turbocharger System
  25. PCV System
  26. Air Intake System
  27. Catalytic Converter
  28. Exhaust Manifold
  29. Exhaust Pipe (Manifold-To-Catalyst)
  30. EGR System
  31. Miscellaneous Items Used In Above System

FUSE PANEL LOCATION

On 1986-87 models the fuse panel is located in the center console behind the ashtray. To gain access to the panel, remove the ashtray and retainer. On 1988-90 models the fuse panel is located on the left side of the instrument panel behind a cover panel.

Scheme 20

Scheme 20: FUSE PANEL IDENTIFICATION
Scheme 20: FUSE PANEL IDENTIFICATION

Fuse & Circuit Breaker Identification

  1. 1 - 25 Amp Fuel Pump, Turbo Fuel Injection System
  2. 2 - 25 Amp Hazard Warning Lights, Headlight Flash (Via Fuse 17 & 18), Central Locking
  3. 3 - 15 Amp Auxiliary Light Relay (Spot/Fog In Front Spoiler), Rear Foglight Relay
  4. 4 - 15 Amp Brake Lights, Gear Shift Indicator
  5. 5 - 15 Amp Clock, Vanity Mirror Light, Glove Compartment Light, Engine Compartment & Trunk Light, Courtesy Lighting, Radio, Power Antenna, Door-Open Warning Lamps
  6. 6 - 15 Amp Heated Front Seats
  7. 7 - 25 Amp Electric Cooling Fan
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Direction Indicators, Fasten Seat Belt Light, Heated Front Seats, Power Windows, A/C, Electric Cooling Fan
  10. 10 - 30 Amp Heated Rear Window, Power Sun Roof, Power Door Mirrors
  11. 11 - 15 Amp Tank Pump, Heated Lambda-Sond
  12. 12 - 15 Amp Back-Up Lights, Low Oil Level Indicator Lamp, Over Drive, Ignition Advance, Cruise Control
  13. 13 - 15 Amp CIS FI System, Fuel Valve (Diesel), Glow Plugs (Diesel)
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Tailgate Wiper
  15. 15 - 25 Amp Horn, Windshield Wiper, Headlight Washer/Wiper
  16. 16 - 30 Amp Heater Fan, A/C
  17. 17 - 15 Amp Left Headlight (High Beam)
  18. 18 - 15 Amp Right Headlight (High Beam), Spot Lamps
  19. 19 - 15 Amp Left Headlight (Low Beam)
  20. 20 - 15 Amp Right Headlight (Low Beam)
  21. 21 - 15 Amp Instrument & Panel Lighting, Tail Lights & Parking Lights, Left License Plate Light
  22. 22 - 15 Amp Seat Belt Light, Rear Ashtray Light, Automatic Transmission Selector Panel Light, Transmission Tunnel Switch Lighting, Right Tail Lights & Parking Lights, Auxiliary Light Relay
  23. 23 - 15 Amp Spare
  24. 24 - 15 Amp Spare
  25. 25 - 15 Amp Rear Fog Lights
  26. 26 - 30 Amp Spare

Scheme 21

Scheme 21: FUSE & RELAY PANEL IDENTIFICATION (1987)
Scheme 21: FUSE & RELAY PANEL IDENTIFICATION (1987)

Scheme 22

Scheme 22
Scheme 22
  1. 1 - 25 Amp Fuel Pump, Fuel Injection System
  2. 2 - 25 Amp Central Locking System, Hazard Warning Lights, Headlight Flashers, ABS System
  3. 3 - 15 Amp Fog Lamps, Watch-Dog Alarm System
  4. 4 - 15 Amp Brake Lights, Trunk Lid Switch
  5. 5 - 15 Amp Glove Box Light, Clock, Radio, Engine Compartment Light, Interior Lighting, Trunk Light, Electric Antenna, Door Courtesy Lights, Vanity Mirror
  6. 6 - 15 Amp Electrically-Heated Front Seat (Passenger)
  7. 7 - 30 Amp Electronic Climate Cooling Fan
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Seat Belt Reminder, Turn Signal Indicators, Air Conditioning, Electrically-Heated Front Seat (Driver), Power Windows
  10. 10 - 30 Amp Heated Rear Window, Heated Door Mirrors, Power Moonroof
  11. 11 - 15 Amp Fuel Tank Pump, Heated Oxygen Sensor (Lambda-sond)
  12. 12 - 15 Amp Back-Up Lights, Cruise Control, Ignition On, Overdrive (4th Gear), SRS (Air Bag), ABS System
  13. 13 - 15 Amp Spare
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Fuel Door Lid
  15. 15 - 25 Amp Horn, Windshield Washer/Wiper, SRS (Primary Side of Fuse)
  16. 16 - 30 Amp Heater Blower, Air Conditioning
  17. 17 - 15 Amp Left High Beam
  18. 18 - 15 Amp Right High Beam, Supplementary High Beam
  19. 19 - 15 Amp Left Low Beam
  20. 20 - 15 Amp Right Low Beam
  21. 21 - 15 Amp Left Parking Lights (Front & Rear), License Plate Lights, Ashtray Light, Heated Rear Window Switch Light, Sunroof, Instrument Lighting, Switch Lighting (Left Of Steering Wheel) Watch-Dog Alarm System
  22. 22 - 15 Amp Seat Belt Lock Illumination, Center Storage Box Light Right Parking Lights (Front & Rear), Fog Lamps
  23. 23 - 15 Amp Power Front Seat Relay
  24. 24 - 30 Amp Power Passenger Seat
  25. 25 - 15 Amp Rear Fog Lamps
  26. 26 - 30 Amp Power Driver's Seat

Relay Identification

  1. A - Headlight Relay with Bulb Malfunction Indicator
  2. B - Fasten Seat Belt Relay
  3. C - Intermittent Windshield Wiper Relay
  4. D - Not Used
  5. E - LH-Jetronic 2.2 Fuel Injection Relay (B230F-T Engines)
  6. F - Headlamp Hi-Beam Relay
  7. G - Flasher Relay
  8. H - Fuel Tank Door Relay
  9. I - Overdrive Relay
  10. J - Power Windows and Electric Cooling Fan Relay
  11. K - Automatic Cut-Out Headlights Relay
  12. L - Central Locking System Relay
  13. M - Rear Fog Lamps Relay
  14. N - Front Fog Lamps Relay
  15. O - Not Used
  16. P - Not Used
  17. R - Alarm (Watch Dog) Relay
  18. S - Starter Inhibitor (Watch Dog) Relay

ABS FUSE PANEL IDENTIFICATION (1987)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the system is protected by (2) additional fuses. (1) 10 Amp fuse located in the trunk compartment on the right side, and (1) 80 Amp fuse located on the left inner fender. (Scheme 23)

Scheme 23

Scheme 23: ABS FUSE PANEL IDENTIFICATION (1987)
Scheme 23: ABS FUSE PANEL IDENTIFICATION (1987)

ABS RELAY IDENTIFICATION (1987)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the ABS pump motor, solenoids and relays are located in the trunk compartment on the right side. (Scheme 24)

Scheme 24

Scheme 24: ABS RELAY IDENTIFICATION (1987)
Scheme 24: ABS RELAY IDENTIFICATION (1987)

Note. The ABS system is protected by an additional 10 Amp fuse which is located under the instrument panel to the left of the steering wheel.

  1. 1 - 25 Amp Fuel Pump, Turbo Fuel Injection System
  2. 2 - 25 Amp Hazard Warning Lights, Headlight Flash (Via Fuse 17 & 18), Central Locking
  3. 3 - 15 Amp Auxiliary Light Relay (Spot/Fog In Front Spoiler), Rear Foglight Relay
  4. 4 - 15 Amp Brake Lights, Gear Shift Indicator
  5. 5 - 15 Amp Clock, Vanity Mirror Light, Glove Compartment Light, Engine Compartment & Trunk Light, Courtesy Lighting, Radio, Power Antenna, Door-Open Warning Lamps
  6. 6 - 15 Amp Heated Front Seats
  7. 7 - 25 Amp Electric Cooling Fan
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Direction Indicators, Fasten Seat Belt Light, Heated Front Seats, Power Windows, A/C, Electric Cooling Fan
  10. 10 - 30 Amp Heated Rear Window, Power Sun Roof, Power Door Mirrors
  11. 11 - 15 Amp Tank Pump, Heated Lambda-Sond
  12. 12 - 15 Amp Back-Up Lights, Low Oil Level Indicator Lamp, Over Drive, Ignition Advance, Cruise Control
  13. 13 - 15 Amp CIS FI System, Fuel Valve (Diesel), Glow Plugs (Diesel)
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Tailgate Wiper
  15. 15 - 25 Amp Horn, Windshield Wiper, Headlight Washer/Wiper
  16. 16 - 30 Amp Heater Fan, A/C
  17. 17 - 15 Amp Left Headlight (High Beam)
  18. 18 - 15 Amp Right Headlight (High Beam), Spot Lamps
  19. 19 - 15 Amp Left Headlight (Low Beam)
  20. 20 - 15 Amp Right Headlight (Low Beam)
  21. 21 - 15 Amp Instrument & Panel Lighting, Tail Lights & Parking Lights, Left License Plate Light
  22. 22 - 15 Amp Seat Belt Light, Rear Ashtray Light, Automatic Transmission Selector Panel Light, Transmission Tunnel Switch Lighting, Right Tail Lights & Parking Lights, Auxiliary Light Relay
  23. 23 - 15 Amp Spare
  24. 24 - 15 Amp Spare
  25. 25 - 15 Amp Rear Fog Lights
  26. 26 - 30 Amp Spare
  27. 23 - 15 Amp Power Seats, Daytime Running Lights
  28. 24 - 30 Amp Supplemental Restraint System (Air Bag)
  29. 25 - 15 Amp Daytime Running Lights, Rear Fog Lights
  30. 26 - 30 Amp Power Driver's Seat

Scheme 25

Scheme 25: FUSE PANEL IDENTIFICATION (1988-90)
Scheme 25: FUSE PANEL IDENTIFICATION (1988-90)
  1. 1 - 10 Amp Left Parking Light, License Plate Lights
  2. 2 - 10 Amp Right Parking Light
  3. 3 - 15 Amp Left Headlight (High Beam)
  4. 4 - 15 Amp Right Headlight (High Beam)
  5. 5 - SRS Test Socket
  6. 6 - 15 Amp Left Headlight (Low Beam)
  7. 7 - 15 Amp Right Headlight (Low Beam)
  8. 8 - 15 Amp Front Foglight
  9. 9 - 10 Amp Rear Foglight
  10. 10 - 5 Amp Instrument & Control Lighting
  11. 11 - 15 Amp Back-up Lights, Turn Signals
  12. 12 - Blank
  13. 13 - 25 Amp Heated Rear Window, Heated Door Mirrors
  14. 14 - 10 Amp Overdrive, Power Sunroof Relay, Power Windows
  15. 15 - Blank
  16. 16 - Blank
  17. 17 - Blank
  18. 18 - 5 Amp Radio
  19. 19 - 15 Amp ECC, Power Door Mirrors, Rear Window Washer/Wiper (Wagon), Power Seats, Cigar Lighter
  20. 20 - 25 Amp Horn, Windshield Wipers, Headlight Wipers
  21. 21 - 5 Amp ETC, Glow Plugs (Diesel), Constant Idle System (CIS)
  22. 22 - Blank
  23. 23 - Blank
  24. 24 - Blank
  25. 25 - 25 Amp Hazard Warning Lights, Central Locking
  26. 26 - 10 Amp Clock, Interior Lighting, Door Open Warning Lights, Glove Box Light, Cargo Space & Vanity Mirror Lights
  27. 27 - 15 Amp Brake Lights
  28. 28 - 30 Amp ECC Heater Fan, ECC
  29. 29 - 30 Amp Power Antenna, Towing Bracket Lights
  30. 30 - 10 Amp Fuel Tank Pump, Lambda-Sond
  31. 31 - 25 Amp Fuel Injection, Main Fuel Pump
  32. 32 - 15 Amp Radio Amplifier
  33. 33 - 10 Amp Radio
  34. 34 - 30 Amp Power Windows, Power Sunroof
  35. 35 - 30 Amp Heated Seats, Power Seats

Scheme 26

Scheme 26
Scheme 26
  1. A - Headlight Relay with Bulb Malfunction Indicator
  2. B - Fuel Pump Relay
  3. C - Central Locking Relay
  4. D - Foglight Relay
  5. E - Headlight Relay with Bulb Malfunction Indicator
  6. F - Bulb Failure Sensor
  7. G - Overdrive Relay
  8. J - Power Relay
  9. K - Intermittent Wiper Relay (Rear Tailgate - Wagon)
  10. L - Intermittent Windshield Wiper Relay
  11. M - Seat Belt Reminder Relay

ABS FUSE PANEL IDENTIFICATION (1988-90)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the system is protected by an additional 10 Amp fuse located to the left of the steering column. (Scheme 27)

Scheme 27

Scheme 27: ABS FUSE PANEL IDENTIFICATION (1988-90)
Scheme 27: ABS FUSE PANEL IDENTIFICATION (1988-90)

Note. The ABS system is protected by an additional 10 AMP fuse which is incorporated in the surge protector at the brake pedal mounting.

More articles — Maintenance
