Maintenance Information Volvo 740 I

Procedures 41 illustrations ~4253 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

Scheme 2: VIN Code ID Explanation
Scheme 2: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Operating Conditions From Severe Service Schedule

Severe Service (Unique Driving Conditions)

  1. Extended Idling Or Low Speed Operation
  2. Frequent Short Trips Of Less Than 7 Miles
  3. Extended Operation In Dusty Or Sandy Conditions
  4. Trailer Towing Operations
  5. Driving In Mountainous Conditions

CAMSHAFT TIMING BELT

CAUTIONFailure to replace a faulty camshaft timing belt may result in serious engine damage.

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

  1. Cracks Or Tears In Belt Surface
  2. Missing, Damaged, Cracked Or Rounded Teeth
  3. Oil Contamination
  4. Damaged Or Faulty Tensioners
  5. Incorrect Tension Adjustment

Volvo recommends replacement of the camshaft timing belt at the following intervals

ApplicationInterval (Miles)
Non-Turbo50,000
Turbo50,000
Diesel (1)75,000
(1) Diesel Engines have (2) timing belts, (1) at the front of the engine for the camshaft and (1) at the rear of the engine that drives the fuel injection pump from the rear of the camshaft.
(1)Diesel Engines have (2) timing belts, (1) at the front of the engine for the camshaft and (1) at the rear of the engine that drives the fuel injection pump from the rear of the camshaft.

CAMSHAFT TIMING BELT REPLACEMENT INTERVAL

Scheme 3

Scheme 3: SERVICE POINT LOCATIONS
Scheme 3: SERVICE POINT LOCATIONS

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7: EMERGENCY DIESEL ENGINE SHUT-OFF
Scheme 7: EMERGENCY DIESEL ENGINE SHUT-OFF
WARNINGUse extreme caution when performing the emergency shut-off on diesel engine vehicles. The vehicle should be on level ground with the parking brake ENGAGED, and NO personnel should be standing in front or behind the vehicle.

Note. The shut-off valve is only on automatic transmission models.

AUTOMATIC TRANSMISSION EQUIPPED VEHICLES

  1. Place transmission into PARK.
  2. Apply parking brake.
  3. Turn ignition switch to the OFF position.
  4. Push the emergency shut-off lever on the fuel injection pump forward. (Scheme 7)
  5. Engine should shut-off.

MANUAL TRANSMISSION EQUIPPED VEHICLES

  1. Apply parking brake.
  2. Depress and HOLD foot brake.
  3. Turn ignition switch to the OFF position.
  4. Engage clutch and place transmission into 3rd or 4th gear.
  5. Disengage clutch.
  6. Engine should stop.

Scheme 8

Scheme 8: DIESEL FUEL FILTER MAINTENANCE
Scheme 8: DIESEL FUEL FILTER MAINTENANCE

Note. Use new Diesel Fuel Filter (P/N 354786-7) when changing diesel fuel filter.

Note. For more information regarding diesel fuel filter service refer to the GROUP 23, NO. 136 DIESEL FUEL QUALITY/FILTER article in the TSB section.

Scheme 9

Scheme 9: ALIGNING CAMSHAFT TIMING MARKS
Scheme 9: ALIGNING CAMSHAFT TIMING MARKS

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Note. For more information on camshaft timing belt service see the 2.4L 6-CYL DIESEL & 2.4L 6-CYL TURBO DIESEL article in the ENGINE MECHANICAL section.

Scheme 12

Scheme 12: ADJUSTING FUEL INJECTION PUMP TIMING - DIESEL
Scheme 12: ADJUSTING FUEL INJECTION PUMP TIMING - DIESEL

Note. For more information regarding fuel injection system service refer to the FUEL INJECTION SYSTEM - DIESEL article in the FUEL SYSTEMS section.

Scheme 13

Scheme 13: ADJUSTING IDLE SPEED - DIESEL
Scheme 13: ADJUSTING IDLE SPEED - DIESEL

Note. For more information regarding fuel injection system service refer to the FUEL INJECTION SYSTEM - DIESEL article in the ENGINE PERFORMANCE section.

COMPRESSION TEST - DIESEL

Note. For more information regarding compression testing refer to the FUEL INJECTION SYSTEM - DIESEL article in the ENGINE PERFORMANCE section.

FUEL INJECTOR CLEANING/ADJUSTMENTS - DIESEL

Note. For more information regarding fuel injector service refer to the FUEL INJECTION SYSTEM - DIESEL article in the ENGINE PERFORMANCE section.

Scheme 14

Scheme 14: VALVE CLEARANCE ADJUSTMENT - DIESEL
Scheme 14: VALVE CLEARANCE ADJUSTMENT - DIESEL

Note. For more information on valve clearance adjustments see the 2.4L 6-CYL DIESEL & 2.4L 6-CYL TURBO DIESEL article in the ENGINE MECHANICAL section.

Scheme 15

Scheme 15: ENGINE COOLANT REFILLING - DIESEL
Scheme 15: ENGINE COOLANT REFILLING - DIESEL

EMISSION CONTROL TYPE 1989-92 MODELS

Note. Check EIN (Engine Identification Code) shown in figures to the six-digit number on decal on camshaft drive cover. Number is also stamped on left side of engine block.

Scheme 16

Scheme 16: EMISSION CONTROL TYPE 1989-92 MODELS
Scheme 16: EMISSION CONTROL TYPE 1989-92 MODELS

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19: VALVE CLEARANCE ADJUSTMENT - 2.3L NON-TURBO
Scheme 19: VALVE CLEARANCE ADJUSTMENT - 2.3L NON-TURBO

Note. For more information regarding valve clearance adjustments refer to the 2.3L 4-CYL & 2.3L 4-CYL TURBO article in the ENGINE MECHANICAL section.

Scheme 20

Scheme 20: ALIGNING CAMSHAFT TIMING MARKS - 2.3L NON-TURBO
Scheme 20: ALIGNING CAMSHAFT TIMING MARKS - 2.3L NON-TURBO

Note. For more information regarding camshaft timing belt service refer to the 2.3L 4-CYL & 2.3L 4-CYL TURBO article in the ENGINE MECHANICAL section.

Scheme 21

Scheme 21: PCV VALVE & FLAME TRAP MAINTENANCE POINTS - 2.3L NON-TURBO
Scheme 21: PCV VALVE & FLAME TRAP MAINTENANCE POINTS - 2.3L NON-TURBO

VALVE CLEARANCE ADJUSTMENT - 2.3L DOHC 16-VALVE

Note. The 2.3L DOHC 16-Valve engine has self adjusting valves.

ALIGNING CAMSHAFT TIMING MARKS - 2.3L DOHC 16-VALVE

CAUTIONBefore servicing the Camshaft Timing Belt on 2.3L 16-Valve engines refer to the following TSB's. Engine damage may result if the proper parts and procedures are not followed.

Note. For more information regarding camshaft timing belt service refer to the GROUP 21, NO.706 TIMING BELT REPLACEMENT article in the TSB section.

Note. For more information regarding camshaft timing belt service refer to the GROUP 21, NO.706 TIMING BELT REPLACEMENT article in the TSB section.

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Note. For more information regarding camshaft timing belt service refer to the 2.3L 4-CYL DOHC 16-VALVE article in the ENGINE MECHANICAL section.

Scheme 24

Scheme 24: PCV VALVE & FLAME TRAP MAINTENANCE POINTS - 2.3L DOHC
Scheme 24: PCV VALVE & FLAME TRAP MAINTENANCE POINTS - 2.3L DOHC

TIMING BELT REPLACEMENT INTERVALS

EngineModel Year5K10K50K55K60K100K105K110K
B230F1991A"XA"XA"
B230F1992"AX"AX"A
B234F89-90 *A"XA"XA"

MODELS 740 with B230/B234 TIMING BELT REPLACEMENT

EngineModel YearPart No.
B230F/FT1992271713-0
B234FEarly 1990 * *271720-5
B234FLate 1990- * *271714-8

TIMING BELT KIT PART NUMBERS

ALIGNING CAMSHAFT TIMING MARKS - 2.3L TURBO

Note. For more information regarding camshaft timing belt service refer to the 2.3L 4-CYL & 2.3L 4-CYL TURBO article in the ENGINE MECHANICAL section.

VALVE CLEARANCE ADJUSTMENT - 2.3L TURBO (GASOLINE)

Note. For more information regarding valve clearance adjustments refer to the 2.3L 4-CYL & 2.3L 4-CYL TURBO article in the ENGINE MECHANICAL section.

Scheme 25

Scheme 25: ADJUSTING IDLE SPEED
Scheme 25: ADJUSTING IDLE SPEED

Note. For more information regarding fuel injection service refer to the TUNE-UP - 4-CYL article in the ENGINE PERFORMANCE section.

Scheme 26

Scheme 26: PCV VALVE MAINTENANCE POINTS
Scheme 26: PCV VALVE MAINTENANCE POINTS

Scheme 27

Scheme 27: ENGINE COOLANT REFILLING - TURBO
Scheme 27: ENGINE COOLANT REFILLING - TURBO

Scheme 28

Scheme 28: ADJUSTING KICKDOWN CABLE (AUTOMATIC TRANSMISSION)
Scheme 28: ADJUSTING KICKDOWN CABLE (AUTOMATIC TRANSMISSION)

Note. For more information regarding kickdown cable service refer to the ADJUSTMENTS article in the ENGINE PERFORMANCE section.

Scheme 29

Scheme 29: REFILLING AUTOMATIC TRANSMISSION FLUID (AW-71)
Scheme 29: REFILLING AUTOMATIC TRANSMISSION FLUID (AW-71)

Scheme 30

Scheme 30: MANUAL TRANSMISSION OVERDRIVE FILTER LOCATION (M46)
Scheme 30: MANUAL TRANSMISSION OVERDRIVE FILTER LOCATION (M46)

Scheme 31

Scheme 31: ADDITIONAL SERVICE INFORMATION
Scheme 31: ADDITIONAL SERVICE INFORMATION
  1. With gear selector in Park, depress brake pedal.
  2. Move gear selector to desired position.
  3. If gear selector DOES NOT MOVE, check fuse #4.
  4. TO MANUALLY RELEASE gear selector, push finger between brushes at base of shifter and push catch forward. (Scheme 31)).
  5. Select a gear.

SERVICE INTERVAL REMINDER LIGHT 1987-93 (IF EQUIPPED)

  1. Service interval reminder light will come on at 5000 mile intervals to indicate oil and filter change is scheduled. After changing oil and filter, reset mileage counter.
  2. To reset counter on 1987-88 models, locate button behind right center of instrument cluster and press. (Scheme 32) To reset counter on 1989-92 models, remove rubber grommet to left of odometer. Using a small screwdriver, depress reset knob. (Scheme 33)

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34: BODY SERVICE POINTS
Scheme 34: BODY SERVICE POINTS

Scheme 35

Scheme 35: VEHICLE LIFT POINTS
Scheme 35: VEHICLE LIFT POINTS

Note. For more information regarding lifting and hoisting refer to the JACKING & HOISTING article in the WHEEL ALIGNMENT section.

Scheme 36

Scheme 36: INFORMATION LABEL LOCATIONS
Scheme 36: INFORMATION LABEL LOCATIONS

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

LUBRICATION SPECIFICATIONS

CAUTIONDO NOT use SAE 15W-40 oil in extremely low ambient temperatures.

TIRE INFLATION

Tire specification label is located on the right front door.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 63 ft. lbs. (85 N.m) using pattern (Scheme 37)

Scheme 37

Scheme 37: TIRE ROTATION PATTERNS
Scheme 37: TIRE ROTATION PATTERNS

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

Gasoline engine vehicles use batteries with a 66 amp hour rating. Diesel engine vehicles use batteries with a 88 amp hour rating.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG) (1988-92)

Note. See the AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAGS article in ACCESSORIES/SAFETY EQUIPMENT.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAR WARNING

Note. For information on air bag DIAGNOSIS & TESTING or DISPOSAL PROCEDURES, see AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

System circuit is grounded by 2 screws beneath the driver's seat. DO NOT use these screws to ground any other accessory. DO NOT ground any other components near this system.

ANTI-LOCK BRAKE SYSTEM (1987-92)

The anti-lock brake system contains electronic equipment that can be susceptible to interference caused by improperly installed or high output radio transmitting equipment. Since this interference could cause the possible loss of the anti-lock braking capability, such equipment should be installed by qualified professionals.

On models equipped with anti-lock brake systems, ALWAYS observe the following cautions

  1. DO NOT attempt to bleed hydraulic system without first referring to the appropriate ANTI-LOCK BRAKE SYSTEM article in the BRAKES Section.
  2. DO NOT mix tire sizes. As long as tires remain close to the original diameter, increasing the width is acceptable. Rolling diameter must be identical for all 4 tires. Some manufacturers recommend tires of the same brand, style and type. Failure to follow this precaution may cause inaccurate wheel speed readings.
  3. Use ONLY recommended brake fluids. DO NOT use silicone brake fluids in an ABS-equipped vehicle.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section.

REPLACING BLOWN FUSES

CAUTIONBefore replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE SYSTEM

CAUTIONIf brake warning light comes on while driving it indicates a low fluid level or failure in one of the braking circuits. If the brake pedal can be depressed further than normal it is an indication that one of the brake circuits is not functioning. Stop vehicle and check brake reservoir fluid level. If level is below MIN mark, DO NOT drive vehicle. Have it towed to a repair shop. If level is between the MIN and MAX marks, proceed cautiously to a repair shop.

BRAKE PAD WEAR INDICATOR

CAUTIONIndicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

CAUTIONContinued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

Any modification to the exhaust system on turbo models, which reduces exhaust backpressure, will lead to lean fuel mixtures and excessive spark advance. This could cause serious engine damage.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

TURBOCHARGED MODELS

CAUTIONDo not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings.

WHEELS & TIRES

Only wheels tested and approved by the manufacturer should be used on models equipped with Air Dam aerodynamic components.

WARRANTY INFORMATION

CAUTIONAlways refer to customer's copy of warranty information for specific model application and/or coverage limitations.

BASIC WARRANTY (1983-90 MODELS)

The manufacturer warrants that repairs due to defects in material or workmanship, occurring under normal use, will be performed at no charge to the vehicle owner during period covered by the appropriate warranty. During the warranty period the warranty is fully transferable to subsequent owners. The warranty period is divided into 3 periods (1, 3 and 5 year). All periods begin the day the vehicle is delivered to the first retail customer or put into service, which ever comes first. The Basic Warranty covers the entire vehicle, with the exception of expendable items such as tires, for a period of 12 months with unlimited mileage.

BASIC WARRANTY (1991-92 MODELS)

Warranty coverage is 3 years or 50,000 miles, whichever occurs first.

MAJOR ASSEMBLY COVERAGE (1983-90 MODELS)

Covers the following items and components for a period of 36 months with unlimited mileage from warranty start date

  1. Engine And Cooling System
  2. Transmission And Driveshaft
  3. Rear Axle And Axle Shafts
  4. Brakes (Excluding Brake Pads)
  5. Steering
  6. Suspension (Excluding Shock Absorbers)
  7. Air Conditioning
  8. Computerized Engine Control Systems
  9. Electrical Components

MAJOR ASSEMBLY COVERAGE (1991-92 MODELS)

Warranty coverage is 3 years or 50,000 miles, whichever occurs first.

CORROSION PROTECTION WARRANTY

Painted body panels are warranted against perforation for a period of 5 years. Structural damage due to rust or corrosion is warranted for 8 years.

SUPPLEMENTAL RESTRAINT SYSTEMS & SEAT BELTS

Factory installed seat belts or restraint systems are warranted for a period of 5 years.

EMISSION SYSTEM WARRANTY

Manufacturer warrants that the vehicle emission control system was designed and installed to conform, at the time of sale, to all applicable U.S. emission standards. The warranty covers repairs resulting from any defect in material or workmanship which could cause the vehicle not to meet emission standards during the warranty period. The warranty period is 5 years or 50,000 miles. The following items are not warranted

  1. Normal Scheduled Maintenance Of Emission Components
  2. Regular Maintenance Items
  3. Damage To Components Due To Accidents
  4. Damage Due To Contaminated Or Incorrect Fuels
  5. Any Component On A Vehicle With An Altered Odometer
  6. Damaged Caused By The Use Of Non-Genuine Parts

The following components are covered by Emission System or Emission Performance warranties

  1. Ignition Cables
  2. Distributor Components
  3. Ignition Coil
  4. Power Stage
  5. Ignition Control Unit
  6. Spark Plugs
  7. Knock Sensor
  8. Engine RPM Sensor
  9. Fuel Pressure Regulator
  10. Mass Airflow Meter
  11. Fuel Injection Control Unit
  12. Fuel Injectors
  13. Idle Air Valve
  14. Coolant Temperature Sensor
  15. Throttle Position Sensor
  16. Throttle Potentiometer
  17. Series Resistor
  18. Oxygen Sensor
  19. Cold Start Injector
  20. Temperature Sensor
  21. Manifold Pressure Sensor
  22. Camshaft Sensor
  23. Evaporative Emission System
  24. Turbocharger System
  25. PCV System
  26. Air Intake System
  27. Catalytic Converter
  28. Exhaust Manifold
  29. Exhaust Pipe (Manifold-To-Catalyst)
  30. EGR System
  31. Miscellaneous Items Used In Above System

FUSE PANEL LOCATION

The fuse panel is located in the center console behind the ashtray. To gain access to the panel, remove the ashtray and retainer.

Note. 1986 diesel models are equipped with Glow Plug Control Unit (P/N 1348 339) with an 80 Amp fuse. (Scheme 38)

Scheme 38

Scheme 38: FUSE PANEL LOCATION
Scheme 38: FUSE PANEL LOCATION

Scheme 39

Scheme 39: FUSE PANEL IDENTIFICATION
Scheme 39: FUSE PANEL IDENTIFICATION

Fuse & Circuit Breaker Identification

  1. 1 - 25 Amp (Diesel) Spare 25 Amp (Gasoline) Fuel Pump, Fuel Injection System
  2. 2 - 25 Amp Hazard Warning Lights, Headlight Flash (Via Fuse 17 & 18), Central Locking
  3. 3 - 15 Amp Auxiliary Light Relay (Spot/Fog In Front Spoiler), Rear Foglight Relay
  4. 4 - 15 Amp Brake Lights, Gear Shift Indicator
  5. 5 - 15 Amp Clock, Vanity Mirror Light, Glove Compartment Light, Engine Compartment & Trunk Light, Courtesy Lighting, Radio, Power Antenna, Door-Open Warning Lamps
  6. 6 - 15 Amp Heated Front Seats
  7. 7 - 25 Amp (Diesel) Spare 25 Amp (Gasoline) Electric Cooling Fan
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Turn Signals, Fasten Seat Belt Light, Heated Front Seats, Power Windows, A/C, Electric Cooling Fan
  10. 10 - 30 Amp Heated Rear Window
  11. 11 - 15 Amp (Diesel) Spare 15 Amp (Gasoline) Tank Pump
  12. 12 - 15 Amp Back-Up Lights, Low Oil Level Indicator Lamp, Over-Drive, Ignition Advance, Cruise Control
  13. 13 - 15 Amp (Diesel) Fuel Stop Valve, Glow Plugs 15 Amp (Gasoline) Spare
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Tailgate Wiper
  15. 15 - 25 Amp Horn, Windshield Wiper, Headlight Washer/Wiper
  16. 16 - 30 Amp Heater Blower Fan, A/C
  17. 17 - 15 Amp Left Headlight (High Beam)
  18. 18 - 15 Amp Right Headlight (High Beam), Spot Lamps
  19. 19 - 15 Amp Left Headlight (Low Beam)
  20. 20 - 15 Amp Right Headlight (Low Beam)
  21. 21 - 15 Amp Instrument & Panel Lighting, License Plate Light, Left Tail Lights & Parking Lights, Sunroof Switch
  22. 22 - 15 Amp Seat Belt Light, Rear Ashtray Light, Automatic Transmission Selector Panel Light, Transmission Tunnel Switch Lighting, Right Tail Lights & Parking Lights, Auxiliary Light Relay
  23. 23 - 15 Amp Spare
  24. 24 - 15 Amp Spare
  25. 25 - 15 Amp Rear Fog Lights
  26. 26 - 30 Amp Spare

Relay Identification

  1. A - Bulb Failure Warning Sensor Relay
  2. B - Seat Belt Reminder/Key Warning Relay
  3. C - Intermittent Windshield Wiper Relay
  4. D - Intermittent Wiper Relay (Rear Tailgate - Wagon)
  5. E - Fuel Injection Relay
  6. F - Fog Lamps (Front) Relay
  7. G - Headlight Flasher
  8. H - Up-Shift Indicator
  9. I - Overdrive Relay
  10. J - Overload Relay 15I (Power Windows/Seat Heater)
  11. K - Headlight Relay
  12. L - Central Locking Relay
  13. M - Rear Fog Lamp Relay
  14. N - Supplementary High-Beam Relay
  15. 0 - Not Used
  16. P - Not Used
  17. R - Not Used
  18. S - Not Used
  1. 1 - 25 Amp Fuel Pump, Fuel Injection System
  2. 2 - 25 Amp Hazard Warning Lights, Headlight Flash (Via Fuse 17 & 18), Central Locking
  3. 3 - 15 Amp Fog Lamps
  4. 4 - 15 Amp Brake Lights, Gear Shift Indicator
  5. 5 - 15 Amp Clock, Vanity Mirror Light, Glove Compartment Light, Engine Compartment & Trunk Light, Courtesy Lighting, Radio, Power Antenna, Door-Open Warning Lamps, Vanity Mirrors
  6. 6 - 15 Amp Heated Front Seats
  7. 7 - 25 Amp Electric Cooling Fan
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Turn Signals, Fasten Seat Belt Light, Heated Front Seats, Power Windows, A/C, Electric Cooling Fan
  10. 10 - 30 Amp Heated Rear Window
  11. 11 - 15 Amp Tank Pump
  12. 12 - 15 Amp Back-Up Lights, Low Oil Level Indicator Lamp, Over-Drive, Ignition Advance, Cruise Control
  13. 13 - 15 Amp Spare
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Tailgate Wiper
  15. 15 - 25 Amp Horn, Windshield Wiper, Headlight Washer/Wiper
  16. 16 - 30 Amp Heater Blower Fan, A/C
  17. 17 - 15 Amp Left Headlight (High Beam)
  18. 18 - 15 Amp Right Headlight (High Beam), Spot Lamps
  19. 19 - 15 Amp Left Headlight (Low Beam)
  20. 20 - 15 Amp Right Headlight (Low Beam)
  21. 21 - 15 Amp Instrument & Panel Lighting, License Plate Light, Left Tail Lights & Parking Lights, Sunroof Switch
  22. 22 - 15 Amp Seat Belt Light, Rear Ashtray Light, Automatic Transmission Selector Panel Light, Transmission Tunnel Switch Lighting, Right Tail Lights & Parking Lights, Auxiliary Light Relay
  23. 23 - 15 Amp Spare
  24. 24 - Diagnostic Socket
  25. 25 - 15 Amp Rear Fog Lights
  26. 26 - 30 Amp Spare
  1. A - Bulb Failure Warning Sensor Relay
  2. B - Seat Belt Reminder/Key Warning Relay
  3. C - Intermittent Windshield Wiper Relay
  4. D - Intermittent Wiper Relay (Rear Tailgate - Wagon)
  5. E - Fuel Injection Relay
  6. F - Fog Lamps (Front) Relay
  7. G - Headlight Flasher
  8. H - Up-Shift Indicator
  9. I - Overdrive Relay
  10. J - Overload Relay 15I (Power Windows/Seat Heater)
  11. K - Headlight Relay
  12. L - Central Locking Relay
  13. M - Rear Fog Lamp Relay
  14. N - Supplementary High-Beam Relay
  15. 0 - Not Used
  16. P - Not Used
  17. R - Not Used
  18. S - Not Used

ABS FUSE PANEL IDENTIFICATION (1987)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the system is protected by (2) additional fuses. (1) 10 Amp fuse located in the trunk compartment on the right side, and (1) 80 Amp fuse located on the left inner fender. (Scheme 40)

Scheme 40

Scheme 40: ABS FUSE PANEL IDENTIFICATION (1987)
Scheme 40: ABS FUSE PANEL IDENTIFICATION (1987)

ABS RELAY IDENTIFICATION (1987)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the ABS pump motor, solenoids and relays are located in the trunk compartment on the right side. (Scheme 41)

Scheme 41

Scheme 41: ABS RELAY IDENTIFICATION (1987)
Scheme 41: ABS RELAY IDENTIFICATION (1987)
  1. 1 - 25 Amp Fuel Pump, Fuel Injection System
  2. 2 - 25 Amp Hazard Warning Lights, Headlight Flash (Via Fuse 17 & 18), Central Locking
  3. 3 - 15 Amp Fog Lamps
  4. 4 - 15 Amp Brake Lights, Gear Shift Indicator
  5. 5 - 15 Amp Clock, Vanity Mirror Light, Glove Compartment Light, Engine Compartment & Trunk Light, Courtesy Lighting, Radio, Power Antenna, Door-Open Warning Lamps, Vanity Mirrors
  6. 6 - 15 Amp Heated Front Seats
  7. 7 - 25 Amp Electric Cooling Fan
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Turn Signals, Fasten Seat Belt Light, Heated Front Seats, Power Windows, A/C, Electric Cooling Fan
  10. 10 - 30 Amp Heated Rear Window, Power Sunroof
  11. 11 - 15 Amp Tank Pump
  12. 12 - 15 Amp Back-Up Lights, Low Oil Level Indicator Lamp, Over-Drive, Ignition Advance, Cruise Control
  13. 13 - 15 Amp Spare
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Tailgate Wiper
  15. 15 - 25 Amp Horn, Windshield Wiper, Headlight Washer/Wiper
  16. 16 - 30 Amp Heater Blower Fan, A/C
  17. 17 - 15 Amp Left Headlight (High Beam)
  18. 18 - 15 Amp Right Headlight (High Beam), Spot Lamps
  19. 19 - 15 Amp Left Headlight (Low Beam)
  20. 20 - 15 Amp Right Headlight (Low Beam)
  21. 21 - 15 Amp Instrument & Panel Lighting, License Plate Light, Left Tail Lights & Parking Lights, Sunroof Switch
  22. 22 - 15 Amp Seat Belt Light, Rear Ashtray Light, Automatic Transmission Selector Panel Light, Transmission Tunnel Switch Lighting, Right Tail Lights & Parking Lights, Auxiliary Light Relay
  23. 23 - 15 Amp Spare
  24. 24 - Diagnostic Socket
  25. 25 - 15 Amp Rear Fog Lights
  26. 26 - 30 Amp Spare
  1. A - Bulb Failure Warning Sensor Relay
  2. B - Seat Belt Reminder/Key Warning Relay
  3. C - Intermittent Windshield Wiper Relay
  4. D - Intermittent Wiper Relay (Rear Tailgate - Wagon)
  5. E - Fuel Injection Relay
  6. F - Fog Lamps (Front) Relay
  7. G - Headlight Flasher
  8. H - Up-Shift Indicator
  9. I - Overdrive Relay
  10. J - Overload Relay 15I (Power Windows/Seat Heater)
  11. K - Headlight Relay
  12. L - Central Locking Relay
  13. M - Rear Fog Lamp Relay
  14. N - Supplementary High-Beam Relay
  15. 0 - Not Used
  16. P - Not Used
  17. R - Not Used
  18. S - Not Used

ABS FUSE PANEL IDENTIFICATION (1988-89)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the system is protected by an additional 10 Amp fuse located to the left of the steering column. (Scheme 42)

Scheme 42

Scheme 42: ABS FUSE PANEL IDENTIFICATION (1988-89)
Scheme 42: ABS FUSE PANEL IDENTIFICATION (1988-89)

Note. The ABS system is protected by an additional 10 AMP fuse which is incorporated in the surge protector at the brake pedal mounting.

ABS RELAY IDENTIFICATION (1988-89)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the ABS pump motor, solenoids and relays are located under the hood, on the right side. see scheme 46

  1. 1 - 25 Amp Fuel Pump, Fuel Injection System
  2. 2 - 25 Amp Hazard Warning Lights, Headlight Flash (Via Fuse 17 & 18), Central Locking
  3. 3 - 15 Amp Spare
  4. 4 - 15 Amp Brake Lights
  5. 5 - 15 Amp Clock, Vanity Mirror Light, Glove Compartment Light, Engine Compartment & Trunk Light, Courtesy Lighting, Radio, Power Antenna, Door-Open Warning Lamps
  6. 6 - 30 Amp Heater Fan ECC
  7. 7 - 30 Amp Power Seats
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Turn Signals, Seat Belt Reminder, Power Windows, Heated Front Seats, A/C Relay
  10. 10 - 30 Amp Heated Rear Window, Power Sun Roof, Heated Power Mirrors
  11. 11 - 15 Amp Fuel Tank Pump, Heated Lambda-Sond
  12. 12 - 15 Amp Back-Up Lights, Overdrive Relay, Spade Connectors (+15), Central Electrical Unit, Cruise Control
  13. 13 - 15 Amp Spare
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Tailgate Wiper Interval Relay
  15. 15 - 25 Amp Horn, Windshield Wiper, Headlight Wipers
  16. 16 - 15 Amp Heater Blower Fan, A/C
  17. 17 - 15 Amp Left Headlight (High Beam), High Beam Indicator Lamp
  18. 18 - 15 Amp Right Headlight (High Beam), Auxiliary Light Relay
  19. 19 - 15 Amp Left Headlight (Low Beam)
  20. 20 - 15 Amp Right Headlight (Low Beam)
  21. 21 - 15 Amp Parking Lights (Left Front & Back), License Plate Lights, Instrument & Control Lighting
  22. 22 - 15 Amp Parking Lights (Right Front & Back), Lighting For Rear Seat Belt Locks & Ashtray, Automatic Transmission Panel Light
  23. 23 - 15 Amp Heated Front Seats
  24. 24 - SRS Test Socket
  25. 25 - 15 Amp Rear Fog Lamps
  26. 26 - 15 Amp Radio Amplifier
  1. A - Bulb Failure Warning Sensor Relay
  2. B - Seat Belt Reminder/Key Warning Relay
  3. C - Intermittent Windshield Wiper Relay
  4. D - Intermittent Wiper Relay (Rear Tailgate - Wagon)
  5. E - Fuel Injection Relay
  6. F - Fog Lamps (Front) Relay
  7. G - Headlight Flasher
  8. H - Up-Shift Indicator
  9. I - Overdrive Relay
  10. J - Overload Relay 15I (Power Windows/Seat Heater)
  11. K - Headlight Relay
  12. L - Central Locking Relay
  13. M - Rear Fog Lamp Relay
  14. N - Supplementary High-Beam Relay
  15. 0 - Not Used
  16. P - Not Used
  17. R - Not Used
  18. S - Not Used

ABS FUSE PANEL IDENTIFICATION (1990)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the system is protected by an additional 10 Amp fuse located to the left of the steering column. see scheme 48

Note. The ABS system is protected by an additional 10 AMP fuse which is incorporated in the surge protector at the brake pedal mounting.

ABS RELAY IDENTIFICATION (1990)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the ABS pump motor, solenoids and relays are located under the hood, on the right side. see scheme 49

  1. 1 - 25 Amp Fuel Pump, Fuel Injection System
  2. 2 - 25 Amp Hazard Warning Lights, Headlight Flash (Via Fuse 17 & 18), Central Locking
  3. 3 - 15 Amp Spare
  4. 4 - 30 Amp Brake Lights, Shift Lock
  5. 5 - 15 Amp Clock, Vanity Mirror Light, Glove Compartment Light, Engine Compartment & Trunk Light, Courtesy Lighting, Radio, Power Antenna, Door-Open Warning Lamps
  6. 6 - 30 Amp Heater Fan MCC
  7. 7 - 30 Amp Extra Lights
  8. 8 - 30 Amp Power Windows
  9. 9 - 15 Amp Turn Signals, Seat Belt Reminder, Power Windows, Heated Front Seats, A/C Relay, Shift Lock
  10. 10 - 30 Amp Heated Rear Window, Power Sun Roof, Heated Power Mirrors
  11. 11 - 15 Amp Fuel Tank Pump, Heated Lambda-Sond
  12. 12 - 15 Amp Back-Up Lights, Overdrive Relay, Spade Connectors (+15), Central Electrical Unit, Cruise Control
  13. 13 - 15 Amp Hot Start Valve
  14. 14 - 15 Amp Power Door Mirrors, Cigar Lighter, Radio, Tailgate Wiper Interval Relay
  15. 15 - 25 Amp Horn, Windshield Wiper, Headlight Wipers
  16. 16 - 15 Amp Heater Blower Fan, A/C
  17. 17 - 15 Amp Left Headlight (High Beam), High Beam Indicator Lamp
  18. 18 - 15 Amp Right Headlight (High Beam), Auxiliary Light Relay
  19. 19 - 15 Amp Left Headlight (Low Beam)
  20. 20 - 15 Amp Right Headlight (Low Beam)
  21. 21 - 15 Amp Parking Lights (Left Front & Back), License Plate Lights, Instrument & Control Lighting
  22. 22 - 15 Amp Parking Lights (Right Front & Back), Lighting For Rear Seat Belt Locks & Ashtray, Automatic Transmission Panel Light
  23. 23 - 15 Amp Heated Front Seats
  24. 24 - SRS Test Socket
  25. 25 - 15 Amp Rear Fog Lamps
  26. 26 - 15 Amp Radio Amplifier
  1. A - Bulb Failure Warning Sensor Relay
  2. B - Seat Belt Reminder/Key Warning Relay
  3. C - Intermittent Windshield Wiper Relay
  4. D - Intermittent Wiper Relay (Rear Tailgate - Wagon)
  5. E - Fuel Injection Relay
  6. F - Fog Lamps (Front) Relay
  7. G - Headlight Flasher
  8. H - Up-Shift Indicator
  9. I - Overdrive Relay
  10. J - Overload Relay 15I (Power Windows/Seat Heater)
  11. K - Headlight Relay
  12. L - Central Locking Relay
  13. M - Rear Fog Lamp Relay
  14. N - Supplementary High-Beam Relay
  15. 0 - Not Used
  16. P - Not Used
  17. R - Not Used
  18. S - Not Used

ABS FUSE PANEL IDENTIFICATION (1991-92)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the system is protected by an additional 10 Amp fuse located to the left of the steering column. see scheme 51

Note. The ABS system is protected by an additional 10 AMP fuse which is incorporated in the surge protector at the brake pedal mounting.

ABS RELAY IDENTIFICATION (1991-92)

Note. On vehicles equipped with Anti-Lock Brakes (ABS), the ABS pump motor, solenoids and relays are located under the hood, on the right side. see scheme 52

More articles — Maintenance
