ENGINE COMPARTMENT COVER Volkswagen Touareg II

3.0L - Engine Assembly - Engine Code(s): Cgfa 2 illustrations

ENGINE COMPARTMENT COVER

Removing

Remove the center section -1- first.

Scheme 489

Scheme 489: ENGINE COMPARTMENT COVER
Scheme 489: ENGINE COMPARTMENT COVER

Carefully pull sections -2 and 3- off the mounting points -arrows-.

Installing

Make sure the rubber grommets fit correctly into the mounts when installing.

Scheme 490

Scheme 490
Scheme 490

Press sections -2 and 3- onto the mounting points -arrows-.

Install the center section -1- last.
