Access/Start Authorization Switch E415 , removing and installing Volkswagen Touareg I facelift

Electrical Equipment 4 illustrations ~261 words

Access/Start Authorization Switch E415 , removing and installing

CAUTIONWhen removing and installing components in visible area (switches, covers, trim, etc.), cover by taping the areas at which a prying tool (plastic wedge, screwdriver) will be positioned using commercially available adhesive tape.

Note. Access/Start Authorization Switch E415 with integrated lock cylinder, integrated Anti-Theft Engine Disable Sensor D1 and integrated Ignition Switch Key Lock Solenoid N376 is one component and can only be replaced completely.

Special tools, testers and auxiliary items required

Scheme 344

Scheme 344
  1. Wrench T10152
  1. Release lever T10039
  2. Wedge T10039/1

Removing

CAUTIONWhen disconnecting battery, procedure must always be followed as described in the article. Not adhering to sequence will result in the deactivation of Main Battery Switch -E74- and subsequent damage to electrical system components.
  1. Disconnect battery --> «Battery, disconnecting and reconnecting»(ref-281400-S09101717962008031100000) .
  2. Remove radio or radio-navigation system --> 91 RADIO, TELEPHONE, NAVIGATION, TRIP COMPUTER .

Scheme 345

Scheme 345
  1. Pry trim strip - 1 - out of locking mechanisms using wedge T10039/1.

Scheme 346

Scheme 346
  1. Place polydrive key T10152 on Access/Start Authorization Switch E415 into cut-outs of mounting nut.
  2. Remove mounting nut of Access/Start Authorization Switch E415 and grasp Access/Start Authorization Switch E415 through instrument cluster (radio or radio-navigation system removed) and guide Access/Start Authorization Switch E415 out.
  3. Disconnect multi-pin harness connector from Access/Start Authorization Switch E415.

Installing

Install in reverse order of removal, noting the following

  1. Tighten mounting nut of Access/Start Authorization Switch E415 by hand using polydrive key T10152.

Note. Adaptation or coding of Access/Start Authorization Switch E415 after removing or installing is not necessary.

Scheme 347

Scheme 347: Connector assignment of Access/Start Authorization Switch E415

Connector, 12-pin

1 - Switch contact 2

2 - Solenoid for key lock

3 - Voltage supply, negative

4 - Anti-theft immobilizer, "shift lock"

5 - Switch contact 1

6 - Switch contact 6

7 - Switch contact 3

8 - Immobilizer, Data 2

9 - Voltage supply, positive

10 - Switch contact 5

11 - Switch contact 4

12 - Immobilizer, Data 1
