TELEMATICS CONTROL HEAD BUTTONS, FUNCTIONALITY

Telematics control head is located at front center under headliner.

"OnStar" button is used by customer to call "OnStar" Telematics call center, so he can easily make use of several services provided. After replacing Telematics Control Module, it is also used to reactivate subscription of customer and to update customer account.

"Emergency" button is used by customer to call "OnStar" Telematics call center in order to ask for emergency services, such as fire department, police etc.

"Communication" button is used for ending conversation with "OnStar" Telematics call center. Additionally, button is used to make personal calls to Telematics call center or to answer calls. Accidentally pressing another Telematics system button can end the procedure using the "Communication" button.

Note. Use of certain "OnStar" services requires a subscriber's Personal Identification Number (PIN).

Scheme 124

Scheme 124: TELEMATICS CONTROL MODULE, 42-PIN CONNECTOR ASSIGNMENT
  1. Signal activation - Dual Horn Auxiliary Relay
  2. Signal activation "lock vehicle"
  3. Cellular telephone, input signal audio, not assigned
  4. Cellular telephone, signal battery charge condition of cellular telephone, not assigned
  5. Cellular telephone, negative
  6. Cellular telephone, TXD transfer, not assigned
  7. Cellular telephone, RTS, ready to transmit, not assigned
  8. Cellular telephone, shielding telephone line, not assigned
  9. CAN bus High
  10. Audio signal to radio, positive
  11. Emergency speaker, positive, not assigned
  12. Microphone signal, positive
  13. K-wire, diagnosis connection
  14. Voltage supply terminal 15, positive
  15. Status red LED
  16. Status green LED
  17. not used
  18. Negative, terminal 31
  19. Negative, terminal 31
  20. not used
  21. not used
  22. Signal activation - Auxiliary Emergency Flasher Relay
  23. Signal activation "unlock vehicle"
  24. Cellular telephone, output signal audio, not assigned
  25. Cellular telephone, negative, not assigned
  26. Cellular telephone, voltage supply, positive, not assigned
  27. Cellular telephone, RXD transfer, not assigned
  28. Cellular telephone, RTS, ready to transmit, not assigned
  29. Signal status telephone base plate, cellular telephone inserted or removed, not assigned
  30. CAN bus Low
  31. Audio signal to radio, negative
  32. Emergency speaker, negative, not assigned
  33. Microphone signal, negative
  34. Signal for radio muting
  35. Input signal "SOS" from Telematics control head
  36. Input signal "SOS" from Telematics control head
  37. not used
  38. Input airbag signal "Crash"
  39. Terminal 30 voltage supply
  40. Terminal 30 voltage supply
  41. Emergency battery, positive, not assigned
  42. Emergency battery, negative, not assigned

Scheme 125

Scheme 125: TELEMATICS SYSTEM OVERVIEW
  1. Radio/Navigation Display Control Module -J503
  2. Indicator Lamp -K186- Installed in Telematics Control Head Designed as LED Troubleshooting on Telematics system, refer to «TELEMATICS SYSTEM»(ref-509936-S37830677222012101700000)
  3. Telematics Control Module -J499- Notes for removing and installing Telematics Control Module, refer to «TELEMATICS CONTROL MODULE»(ref-509936-S38197439042012101700000) . Installed below front right seat Removing and installing, refer to «TELEMATICS CONTROL MODULE»(ref-509936-S38197439042012101700000) .
  4. Telephone Antenna -R65- Installed at front on roof. Removing and installing, refer to «ROOF ANTENNA»(ref-509936-S16349528292012101700000) .
  5. Comfort System Central Control Module -J393- The functions unlocking and locking doors for Telematics system are carried out via Comfort System Central Control Module. Installed in right of luggage compartment.
  6. Telematics Control Head -E264- Installed in front in roof console Removing and installing, refer to «TELEMATICS CONTROL HEAD»(ref-509936-S04199144622012101700000) . Description of function of buttons in Telematics control head, refer to «TELEMATICS CONTROL HEAD BUTTONS, FUNCTIONALITY»(ref-509936-S11125740422012101700000) .
  7. Vehicle Electrical System Control Module -J519- Functions for emergency flasher blinking and operation of horn for Telematics system are carried out via Vehicle Electrical System Control Module. Installed under instrument panel in driver's side footwell.
  8. Microphone -R38- Installed in front roof console. Removing and installing.
