ENGINE NUMBER
For the engine specifications, refer to ENGINE DATA .
The engine number (engine code and serial number) are stamped on the right side of the cylinder block.
Scheme 1
In addition, a sticker with the engine code and serial number is affixed to the toothed belt guard.
The engine code is also included on the vehicle data plate.
ENGINE DATA
| Engine code | AXQ | ||
|---|---|---|---|
| Manufactured | From 03.03 | ||
| Cylinder arrangement | V engine | ||
| Cylinder angle | 90° | ||
| Displacement | Liter | 4.2 | |
| Output | KW at RPM | 228 at 6200 | |
| Torque | Nm at RPM | 410 at 3200 | |
| Bore | Diameter in mm | 84.5 | |
| Stroke | Mm | 93.0 | |
| Compression ratio | 11.0 | ||
| Valves per cylinder | 5 | ||
| Fuel injection, ignition | Motronic ME7.1 | ||
| Ignition sequence | 1-5-4-8-6-3-7-2 | ||
| Knock control | 2 knock sensors | ||
| Oxygen sensor regulation | 4 sensors | ||
| Leak detection system | Yes | ||
| Catalytic converter | Yes | ||
| Exhaust Gas Recirculation (EGR) | No | ||
| Turbocharger, Supercharger | No | ||
| Secondary Air Injection (AIR) System | Yes | ||
| Electronic Power Control (EPC) | Yes | ||
| Variable intake manifold | Yes | ||
| Variable valve timing | Yes | ||
| Research Octane Number (RON) | Min. | 98 unleaded 1 | |
- 1 In exceptional circumstances min. 95 RON, however with reduced performance
