Glass, Window Regulators: Overview Volkswagen Tiguan I

FRONT DOOR WINDOW ASSEMBLY OVERVIEW

Note. The illustration shows a right door hinge. The left door hinge is identical.

Scheme 31

1. Door window Removing and Installing, refer to «DOOR WINDOW»(ref-514691-S21931616362012112100000)
2. Decorative trim strip Placed into window guide. Removing, refer to «WINDOW GUIDE TRIM MOLDING»(ref-514691-S30710940082012112100000)
3. Clip For securing trim molding in window guide.
4. Window guide Inserted on flange. Version with and without trim molding.
5. Trim Removing, refer to «TRIM PANEL»(ref-514691-S27665855492012112100000)
6. Bolt Quantity: 3 2 Nm
7. Spring nut Quantity: 3
8. Outer window shaft seal Inserted on flange Removing, refer to «WINDOW RECESS SEAL»(ref-514691-S17670655382012112100000)
9. Inner window recess seal Inserted on flange Version with and without trim molding
10. Bolt For the door lock Quantity: 2 20 Nm
11. Bolt (left thread) Quantity: 2 8 Nm
12. Cover Quantity: 2
13. Bolt Quantity: 10 8 Nm
14. Window Regulator Motor
15. Connector On the A-pillar
16. Subframe Removing and Installing, refer to «SUBFRAME»(ref-514659-S34252180022012112100000) Window regulator is a component of the subframe. Window regulator motor is bolted to subframe from front.
17. Window regulator Component of subframe.

REAR DOOR WINDOW ASSEMBLY OVERVIEW

Note. The illustration shows a right door hinge. The left door hinge is identical.

Scheme 32

1. Door Window
2. Adhesive tape On the window guide -8-, taped with the trim -5
3. Spring nut Quantity: 3
4. Clip For securing trim molding in window guide. Quantity: 2
5. Trim Removing, refer to «TRIM PANEL»(ref-514691-S12823900052012112100000)
6. Bolt Quantity: 3 2 Nm
7. Decorative trim strip Placed into window guide. Removing, refer to «WINDOW GUIDE TRIM MOLDING»(ref-514691-S00965751072012112100000)
8. Window guide Inserted on flange. Removing and installing, refer to «WINDOW GUIDE»(ref-514691-S29975114422012112100000) Version with and without trim molding.
9. Outer window recess seal Inserted on flange. Version with and without trim molding. Removing, refer to «WINDOW RECESS SEAL»(ref-514691-S14456604162012112100000)
10. Centering pin
11. Fixed door window
12. Bolt Quantity: 2 8 Nm
13. Inner window recess seal Inserted on flange.
14. Bolt For door lock. Quantity: 2 20 Nm
15. Cover for the fixed door window bolts
16. Clamping brackets
17. Spreader pin Securing piece of door window.
18. Spreader plug Securing piece of door window.
19. Cover
20. Subframe
21. Rivet Quantity: 3 For the speaker
22. Window Regulator Motor
23. Connector
24. Window regulator
25. Cover
