Engine Assembly: Overview Volkswagen Tiguan I

Scheme 152

1. Bolt 20 Nm + an additional 90° (1/4) turn. Always replace.
2. Bolt 40 Nm + an additional 90° (1/4) turn. Always replace. Engine mount to body.
3. Engine Mount
4. Bolt 40 Nm + an additional 90° (1/4) turn. Always replace. Engine mount to body.
5. Bolt 60 Nm + an additional 90° (1/4) turn. Always replace. Engine mount to engine mount bracket.
6. Pendulum Support
7. Bolt 100 Nm + an additional 90° (1/4) turn. Always replace. First, secure the pendulum support to the transmission and then to the subframe. Pendulum support to subframe.
8. Bolt Tightening specification, refer to «Specifications»(ref-514685-S02962137742012112100000) . Pendulum support to transmission.
9. Bolt Tightening specification, refer to «Specifications»(ref-514685-S02962137742012112100000) . Pendulum support to transmission.
10. Bolt 60 Nm + an additional 90° (1/4) turn. Always replace. Transmission mount bracket to transmission.
11. Bolt 40 Nm + an additional 90° (1/4) turn. Always replace. Transmission mount to body.
12. Transmission Mount The illustration shows a Direct Shift Gearbox (DSG®) version, this is not available in the US/Canadian market.
13. Engine Mount Bracket
14. Bolts 40 Nm + an additional 180° (1/2) turn. Always replace. Engine mount bracket to engine.
