Communication: Overview Volkswagen Tiguan I

Communication Devices 1 illustration ~356 words

CONNECTOR OVERVIEW

  1. Antenna Connection SAT Antenna systems, refer to «ANTENNA SYSTEMS»(ref-514679-S20791320052012112100000) .
  2. 8-pin Connector 1, Speaker Outputs Terminal assignment, refer to «8-PIN CONNECTOR 1, SPEAKER OUTPUTS»(ref-514679-S07462305662012112100000) .
  3. 8-pin Connector 2, CAN Bus, Voltage Supply Terminal assignment, refer to «8-PIN CONNECTOR 2, CAN BUS, VOLTAGE SUPPLY»(ref-514679-S40417012902012112100000) .
  4. 12-pin Connector 3, Telephone Terminal assignment, refer to «12-PIN CONNECTOR 3, TELEPHONE»(ref-514679-S02001177872012112100000) .
  5. 12-pin Connector 4, CD changer -R41- /External Audio Source Connection -R199- / External Multimedia Device Interface -R215- Terminal assignment, refer to «12-PIN CONNECTOR 4, CD CHANGER -R41- /EXTERNAL AUDIO SOURCE CONNECTION -R199- /MULTIMEDIA SYSTEM CONTROL MODULE -J650»(ref-514679-S02751519102012112100000) .
  6. 26-pin Connector 5, Video and LF Input Terminal assignment, refer to «26-PIN CONNECTOR 5, VIDEO AND LF INPUT»(ref-514679-S05258874212012112100000) .
  7. Antenna Connection FM2 Antenna systems, refer to «ANTENNA SYSTEMS»(ref-514679-S20791320052012112100000) .
  8. Antenna Connection AM/FM Antenna systems, refer to «ANTENNA SYSTEMS»(ref-514679-S20791320052012112100000) .

TELEPHONE SYSTEM OVERVIEW

Note. The telephone system and telephone preparation primarily differ in that the telephone system has a factory-installed cell phone. Therefore, the following overview only illustrates the complete telephone system.

Scheme 1

Scheme 1: TELEPHONE SYSTEM OVERVIEW
  1. Multifunction Steering Wheel Optional For more information regarding the multifunction steering wheel refer to «MULTIFUNCTION STEERING WHEEL, THROUGH 05.10»(ref-514679-S22244721152012112100000) or «MULTIFUNCTION STEERING WHEEL, FROM 05.10»(ref-514679-S33414419652012112100000) .
  2. Instrument Cluster
  3. Telephone Microphone -R38- Microphone -R38- For hands-free operation of telephone system. Installed in front interior light. Removing and installing, refer to «TELEPHONE MICROPHONE»(ref-514679-S24105076792012112100000) .
  4. Microphone Connector In front light installation frame.
  5. Radio or Radio/Navigation Display Control Module -J503- (radio navigation system)
  6. Right Speaker Group
  7. Left Speaker Group
  8. Cell Phone Operating Electronics Control Module -- (Interface Box) Voltage Supply
  9. Cell Phone Operating Electronics Control Module -J412- (Interface Box) Installed below front right seat. Removing and installing, refer to «CELL PHONE OPERATING ELECTRONICS CONTROL MODULE -J412»(ref-514679-S25317634672012112100000) .
  10. Connector To The Cell Phone Baseplate Installed in telephone bracket wiring harness behind instrument panel
  11. Connector To Operating Electronics Control Module
  12. Telephone Antenna -R51- On rear of roof. For more information regarding the different antenna systems, refer to «ANTENNA SYSTEMS»(ref-514679-S20791320052012112100000) .
  13. Antenna Wiring Connector Antenna telephone connector Below rear headliner
  14. Cellular Telephone -R54- Telephone Baseplate, removing and installing, refer to «CELLULAR PHONE BASEPLATE»(ref-514679-S27970734942012112100000) .
  15. Steering Column Electronic Systems Control Module -J527
