Wiring diagram: Shift interlock — Shift interlock circuit, without direct shift Volkswagen Passat B7
All systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body control modules 2
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.0l turbo diesel
- Engine performance 2.5l
- Engine performance 3.6l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems
- Navigation 3
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 3
- Power top/sunroof
- Power windows
- Radio 2
- Shift interlock 2
- Starting/charging 2.0l turbo diesel 2
- Starting/charging 2.5l 2
- Starting/charging 3.6l 2
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
