Glass, Window Regulators: Overview Volkswagen Passat B6

Windows 3 illustrations ~605 words

FRONT DOOR WINDOW ASSEMBLY OVERVIEW

Note. The illustration shows a right door hinge. The left door hinge is identical.

Scheme 1

Scheme 1: FRONT DOOR WINDOW ASSEMBLY OVERVIEW
Scheme 1: FRONT DOOR WINDOW ASSEMBLY OVERVIEW
  1. Door window Removing and Installing, refer to «FRONT DOOR WINDOW»(ref-460532-S02892799822012032900000).
  2. Window guide Inserted on flange. Removing and Installing, refer to «WINDOW GUIDE»(ref-460532-S07062494952012032900000). Version with and without trim molding.
  3. Decorative trim strip Placed into window guide. Removing
  4. Clip For securing trim molding in window guide.
  5. Trim Removing, refer to «TRIM PANEL»(ref-460532-S30322527992012032900000)
  6. Bolt Quantity: 2 Tightening specification: 2 Nm
  7. Spring nut Quantity: 2
  8. Outer window recess seal Inserted on flange.
  9. Intermediate piece Between door and trim panel.
  10. Inner window recess seal Inserted on flange. Version with and without trim molding.
  11. Bolt For door lock. Quantity: 2 Tightening specification: 20 Nm
  12. Insulation Self-adhesive Between the inner door panel and the door window.
  13. Bolt Left hand threaded Quantity: 2 Tightening specification: 8 Nm
  14. Cover Quantity: 2
  15. Rivet Quantity: 3 For securing retaining bracket.
  16. Retaining bracket Secured by 3 rivets.
  17. Subframe Removing and Installing see scheme 51 Window regulator is a component of the subframe. Window regulator motor is bolted to subframe from front.
  18. Bolt Quantity: 10 Tightening specification: 8 Nm
  19. Rivet Quantity: 8 For the speaker mounting
  20. Speaker Secured by 8 rivets.
  21. Clamping brackets Quantity: 2
  22. Connector On the A-pillar
  23. Window regulator Component of subframe.

REAR DOOR WINDOW ASSEMBLY OVERVIEW, SEDAN

Note. The illustration shows a right door hinge. The left door hinge is identical.

Scheme 2

Scheme 2: REAR DOOR WINDOW ASSEMBLY OVERVIEW, SEDAN
Scheme 2: REAR DOOR WINDOW ASSEMBLY OVERVIEW, SEDAN
  1. Door window
  2. Door
  3. Window guide With fixed window. Inserted on flange. Removing and Installing, refer to Version with and without trim molding.
  4. Clip For securing trim molding in window guide.
  5. Decorative trim strip Placed into window guide. Removing, refer to «WINDOW GUIDE TRIM MOLDING»(ref-460532-S14114315532012032900000)
  6. Spring nut Quantity: 2
  7. Trim Removing, refer to «TRIM PANEL»(ref-460532-S19442756902012032900000)
  8. Bolt Quantity: 2 Tightening specification: 2 Nm
  9. Fixed door glass Component of window guide. Removing and installing with window guide, refer to «WINDOW GUIDE»(ref-460532-S24344455252012032900000)
  10. Guide rail Removing and Installing, refer to
  11. Outer window recess seal Inserted on flange. Version with and without trim molding. Removing, refer to «DOOR WINDOW RECESS SEAL»(ref-460532-S13529490862012032900000)
  12. Inner window recess seal Inserted on flange.
  13. Bolt For center bar. Quantity: 2 Tightening specification: 6 Nm
  14. Cover Quantity: 2
  15. Bolt For door lock. Quantity: 2 Tightening specification: 20 Nm
  16. Clamping brackets
  17. Spreader pin Door window retainer
  18. Spreader plug Door window retainer
  19. Cover
  20. Speaker Secured by 3 rivets.
  21. Rivet Quantity: 3
  22. Bolt Quantity: 10 Tightening specification: 8 Nm
  23. Connector

REAR DOOR WINDOW ASSEMBLY OVERVIEW, WAGON

Note. The illustration shows a right door hinge. The left door hinge is identical.

Scheme 3

Scheme 3: REAR DOOR WINDOW ASSEMBLY OVERVIEW, WAGON
Scheme 3: REAR DOOR WINDOW ASSEMBLY OVERVIEW, WAGON
  1. Door window
  2. Door
  3. Window guide Inserted on flange. Removing and Installing, refer to «WINDOW GUIDE»(ref-460532-S12287719782012032900000). Version with and without trim molding.
  4. Clip For securing trim molding in window guide. Quantity: 2
  5. Decorative trim strip Placed into window guide. Removing, refer to «WINDOW GUIDE TRIM MOLDING»(ref-460532-S02147059302012032900000)
  6. Spring nut Quantity: 2
  7. Front trim Removing, refer to «REAR DOOR WINDOW FRONT TRIM»(ref-460532-S05968810202012032900000)
  8. Bolt Quantity: 2 Tightening specification: 2 Nm
  9. Bolt Quantity: 2 Tightening specification: 2 Nm
  10. Rear trim Removing, refer to «REAR DOOR WINDOW REAR TRIM»(ref-460532-S16798818832012032900000)
  11. Spring nut Quantity: 2
  12. Outer window recess seal Inserted on flange. Version with and without trim molding. Removing, refer to «REAR DOOR WINDOW RECESS SEAL, WAGON»(ref-460532-S32414635062012032900000)
  13. Backing
  14. Inner window recess seal Inserted on flange.
  15. Guide rail For mounting window guide. Removing and Installing, refer to «WINDOW GUIDE RAILS»(ref-460532-S16258627702012032900000).
  16. Bracket For mounting guide rail.
  17. Bolt For door lock. Quantity: 2 Tightening specification: 20 Nm
  18. Clamping brackets
  19. Spreader pin Door window retainer
  20. Spreader plug Door window retainer
  21. Cover
  22. Speaker Secured by 3 rivets.
  23. Rivet Quantity: 3
  24. Bolt Quantity: 10 Tightening specification: 8 Nm
  25. Connector
