2.0L - Engine Assembly - Engine Code(s): Bpy: Specifications Volkswagen Passat B6

FASTENER TIGHTENING SPECIFICATIONS

A = 20 Nm + 90° (1/4) additional turn 1

B = 40 Nm + 90° (1/4) additional turn 1

C = 60 Nm + 90° (1/4) additional turn 1

Scheme 282

1 = 40 Nm + 90° (1/4 turn) additional turn 1

2 = 60 Nm + 90° (1/4 turn) additional turn 1

Scheme 283

Pendulum Support

Scheme 284

Note. First, install pendulum support bolt to the transmission and then to the subframe.

A = Strength category 8.8 = 40 Nm + 90° (1/4) additional turn 1

A = Strength category 10.9 = 50 Nm + 90° (1/4) additional turn 1, 2

B = 100 Nm + 90° (1/4) additional turn 1

Scheme 285

1. 1 Always replace
2. 2 With a manual transmission, only use bolts with a strength category of 10.9 if threaded inserts (for example, HeliCoil) are installed. Identification: Section -arrow- on the first thread.
