GUIDE RAIL BRACKET
Removing
Remove the rear trim. Refer to REAR DOOR WINDOW REAR TRIM .
Scheme 62
Remove guide rail -1- upward from bracket -2-.
Installing
Check bracket -2- for secure fit.
Press guide rail -1- into bracket -2-.
It is further secured with installation of rear trim.
Removing
Remove front trim and rear trim, refer to REAR DOOR WINDOW REAR TRIM .
Scheme 63
Push window guide -2- in upper front and rear area slightly to side.
Remove both clips -3-.
Guide trim removal wedge 3409 -3- in carefully between trim molding -1- and window guide -2-.
Scheme 64
Slide trim removal wedge 3409 evenly between trim molding -1- and window guide -2-.
Installing
Spray soap/water solution on to window guide.
Scheme 65
Press trim molding -1- by hand evenly -arrow- into window guide -2-.
Then press window guide correctly into trim molding mount with pinch roller T 10314.
Install in reverse order of removal.
