REFRIGERANT R134A, CAPACITIES
| A/C Compressor | Manufacturer | Total Capacity |
|---|---|---|
| PXE16 | Sanden | 600 + 25 gram |
| DSC17E | Zexel | 600 + 25 gram |
| 6SEU14C, 7SEU16C, 7SEU17C | Denso | 600 + 25 gram |
| 6CVC140 | Delphi | 600 + 25 gram |
REFRIGERANT OIL CAPACITIES
The special refrigerant oil (for use with refrigerant circuits R134a only) is no longer obtainable on the refrigerant/machine oil market.
| Refrigerant oil can be obtained using following part number for | |
|---|---|
| PXE16- Sanden | G 052 154 A2 |
| DSC17E- Zexel | G 052 200 A2 |
| 6SEU14C, 7SEU16C, 7SEU17C - Denso | G 052 300 A2 |
| 6CVC140- Delphi | G 052 154 A2 / G 052 300 A2 |
| Type | Total Capacity |
|---|---|
| PXE16- Sanden | 110 cm 3 10 cm 3 |
| DSC17E- Zexel | 120 cm 3 +15 cm 3 |
| 7SEU17C- Denso | 140 cm 3 10 cm 3 |
| 6SEU14C- Denso | 90 cm 3 10 cm 3 |
| 7SEU16C- Denso | 180 cm 3 10 cm 3 |
| 6CVC140- Delphi | 110 cm 3 10 cm 3 |
| This quantity of refrigerant oil is in a replacement compressor and equates to the total capacity. | |
Important Information
Refrigerant oil attracts moisture. Close any opened containers immediately after use to prevent moisture from entering.
Refrigerant oil, because of its chemical properties, must not be disposed of with engine oils or transmission oils.
Oil Distribution
The oil, which is located in the sump of the A/C compressor before initially switching on the air conditioner system, is distributed through the refrigerant circuit as follows
- A/C compressor approximately 50%
- Condenser approximately 10%
- Suction hose approximately 10%
- Evaporator approximately 20%
- Fluid reservoir approximately 10%
CLIMATIC AND CLIMATRONIC COMPONENTS, FASTENER TIGHTENING SPECIFICATIONS
| Component | Nm |
|---|---|
| Climatic/Climatronic Heating and A/C System Controls | 1.5 |
| Heating and A/C Unit to I/P Assembly Carrier | |
| Cable Bracket Bolts | 4 |
| Climatic/Climatronic Bracket Bolts | 9 +/- 1.3 |
| Door Motors | |
| Fresh Air/Recirculating Air/Back Pressure Door Motor | 1.4 |
| Left temperature door motor | 1.4 |
| Indirect ventilation door motor | 3.5 |
| Refrigerant Line Bracket to Body, Nuts | 20 |
REFRIGERANT SYSTEM, FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| A/C Refrigerant Line to A/C Compressor, Bolts | 22 +/- 1 | |
| 2.0L Engine | ||
| A/C Compressor Sub-Assembly Bracket to Engine, Bolts | M10 x 45 | 40 |
| A/C Compressor to A/C Compressor Sub-Assembly Bracket, Bolts | M8 x 100 | 25 |
| 3.6L Engine | ||
| A/C Compressor Sub-Assembly Bracket to Engine, Bolts | 25 | |
| A/C Compressor to A/C Compressor Sub-Assembly Bracket, Bolts | M8 x 100 | 25 |
| Ribbed Belt Pulley, Zexel | ||
| Overload Protection to A/C Compressor, Bolt | 20 | |
| Overload Protection to Ribbed Belt Pulley, Bolts | 5 | |
| Ribbed Belt Pulley, Sanden | ||
| Overload Protection to A/C Compressor, Bolt | 25 | |
| Overload Protection to Ribbed Belt Pulley, Bolts | 4.5 | |
| Condenser to Radiator, Bolts | 5 +/- 0.5 | |
| Dryer Cartridge Cover, Cap | 1.2 +/- 0.3 | |
| Evacuating and Charging Valve Insert | 2 +/- 0.2 | |
| Expansion Valve Heat Shield, Bolt | 2.5 | |
| Expansion Valve Heat Shield, Nut | 4.5 | |
| Expansion Valve to Heating and A/C Unit, Bolts | 5 | |
| High Pressure Sensor | 8 +/- 1 | |
| Refrigerant Lines to Expansion Valve, Bolts | 10 +/- 1 | |
| Refrigerant Lines to Condenser | 12 +/- 1 | |
3.6L Sub-assembly Bracket Tightening Sequence
Scheme 1
Note. Bolts -1- and -2- are fitting bolts.
Tighten the bolts hand-tight in the following sequence: 1 through 5.
Tighten the bolts to 25 Nm in the following sequence: 1 through 5.
SUB-ASSEMBLY BRACKET TIGHTENING SEQUENCE
Note. Bolts -1- and -2- are fitting bolts.
Tighten the bolts hand-tight in the following sequence: 1 through 5.
Tighten the bolts to 25 Nm in the following sequence: 1 through 5.
Scheme 2
1 - Tensioning roller
2 - Ribbed belt pulley - generator
3 - Idler rollers
4 - Ribbed belt
5 - Ribbed belt pulley - A/C compressor
6 - Ribbed belt pulley - crankshaft
7 - Ribbed belt pulley - coolant pump
Scheme 3
- A/C Compressor Zexel Clean the flange before mounting the ribbed belt pulley.
- Ribbed Belt Pulley Removing, refer to «Remove the Ribbed Belt Pulley»(ref-460602-S15345687032012032900000). To loosen and tighten bolt, hold ribbed belt pulley firmly in place using a standard band wrench (with webbing).
- Circlip Replace Install on the proper side, the side with beveled insertion edge faces away from A/C compressor (install flat side facing compressor).
- Overload Protection Bolted with to the ribbed belt pulley. Keeps the ribbed belt pulley from turning when the A/C compressor gets blocked. To loosen and tighten bolts, hold ribbed belt pulley firmly in place using a standard band wrench (with webbing).
- Hex Bolt Replace To loosen and tighten bolt, hold ribbed belt pulley firmly in place using a standard band wrench (with webbing). Clean the thread on the A/C compressor shaft of old locking compound before installing. Install the bolt with Locking compound -D 000 600 A2-. 20 Nm
- Hex Socket Head Bolt 5 Nm Quantity: 3
