Heating, Ventilation: Overview Volkswagen Passat B6

A/c Compressor 2 illustrations ~389 words

PASSENGER COMPARTMENT HEATING OVERVIEW

Disconnect battery before removing components marked with **. Refer to Removal and Installation .

Scheme 1

Scheme 1: PASSENGER COMPARTMENT HEATING OVERVIEW
Scheme 1: PASSENGER COMPARTMENT HEATING OVERVIEW
  1. Dash Panel **
  2. Center Vents Removing vents, refer to «CENTER VENT»(ref-460530-S31778173552012032900000) .
  3. Air Duct To The Right Side Vent
  4. Passenger Vent Removing vents, refer to «DRIVER AND PASSENGER SIDE»(ref-460530-S42944636972012032900000) .
  5. Fresh Air And Heated Air Controls With Fresh air/recirculating door switch -E159-. Also with Immediate heating button -E537- in vehicles with an auxiliary heater. Removing controls, refer to «HEAT AND FRESH AIR CONTROLS»(ref-460530-S16820531682012032900000) . On vehicles with heated seals also with Heated driver seat adjuster -E94- and Heated front passenger seat adjuster -E95-.
  6. Fresh/Recirculating Air Door Motor -V154- Removing, refer to «FRESH/RECIRCULATING AIR DOOR MOTOR -V154»(ref-460530-S27804433942012032900000) .
  7. Right Footwell Vent Removing and installing, refer to «RIGHT FOOTWELL VENT»(ref-460530-S09413493542012032900000) .
  8. Fresh Air Blower -V2- Removing, refer to «FRESH AIR BLOWER -V2»(ref-460530-S25591634172012032900000) .
  9. Fresh Air Blower Series Resistor With Fuse -N24- Removing and installing, refer to «FRESH AIR BLOWER SERIES RESISTOR WITH FUSE -N24»(ref-460530-S12233790562012032900000) .
  10. Heating Unit Partition Removing, refer to «Removing Heater Partition»(ref-460530-S32795348982012032900000) .
  11. Dust and Pollen Filter With or without an activated charcoal filter element. Different versions depending on the vehicle version and equipment level. Removing and installing, refer to «DUST AND POLLEN FILTER»(ref-460530-S32585915782012032900000) .
  12. Cap Only in vehicles without air duct to vent installed in center console at rear.
  13. Connection For air duct, rear vent. To remove, the center console must be removed. Refer to «Removal and Installation»(ref-460566-S06948114362012032900000) .
  14. Air Duct To Rear Vent
  15. Rear Vent
  16. Rear Channel For Right Footwell Removing and installing, refer to «REAR CHANNEL, FOOTWELL»(ref-460530-S05482996862012032900000) .
  17. Rear Channel For Left Footwell Removing and installing, refer to «REAR CHANNEL, FOOTWELL»(ref-460530-S05482996862012032900000) .
  18. Screw Quantity: 8
  19. Adapter For Controls
  20. Heat Exchanger After replacing the heater core, the coolant must be replaced completely. Refer to «DRAINING AND FILLING»(ref-460595-S10297144382012032900000) . Removing and installing, refer to «HEAT EXCHANGER»(ref-460530-S33155149692012032900000) .
  21. Left Footwell Vent Removing and installing, refer to «LEFT FOOTWELL VENT»(ref-460530-S24974849172012032900000) .
  22. Auxiliary Heater Heating Element -Z35- Not applicable to the US or Canada
  23. Bowden Cable For Temperature Door Removing and installing, refer to «TEMPERATURE DOOR RELEASE CABLE»(ref-460530-S22931472372012032900000) .
  24. Flexible Shaft Removing and installing, refer to «FLEXIBLE AIR DISTRIBUTION SHAFT»(ref-460530-S19878823522012032900000) .
  25. Heater Unit Removing and installing, refer to «HEATER»(ref-460530-S10229013962012032900000) . Disassembling and assembling, refer to «HEATER»(ref-460530-S27192388172012032900000) .

Scheme 2

Scheme 2: Removing Heater Partition
Scheme 2: Removing Heater Partition

Remove the plastic screws -2- and the partition -1-.
