ENGINE NUMBER
Engine code -arrow A- and engine number -arrow B- (serial number) are located on the rear side of the engine, above the partition of the cylinder block/upper oil pan.
Scheme 1
The engine number consists of up to nine characters (alphanumeric). The first part (maximum 3 letters) represents the engine code, the second (six digit) is the serial number. If more than 999, 999 engines with the same engine code are produced, the first of the six characters is replaced with a letter.
In addition, a sticker with the engine code and engine number is applied on the cylinder head cover.
The engine code letters are also located on the vehicle data plate. The data plate is located as well, in the customer service plan as well as on vehicle in the rear spare tire wheel well or on the luggage compartment floor.
ENGINE DATA
| Engine codes | BPR | BPS | ||
|---|---|---|---|---|
| Manufactured | From 05.05 | From 05.05 | ||
| Emission values in accordance with | SULEV (1) | Tier 2 | ||
| Displacement | Liter | 2.5 | 2.5 | |
| Output | KW at RPM | 110 at 5000 | 110 at 5000 | |
| Torque | Nm at RPM | 228 at 3750 | 228 at 3750 | |
| Bore | Diameter mm | 82.5 | 82.5 | |
| Stroke | Mm | 92.8 | 92.8 | |
| Compression ratio | 10.0 | 10.0 | ||
| Valves per cylinder | 4 | 4 | ||
| RON | Min. | 91 unleaded | 91 unleaded | |
| Fuel injection, ignition | Motronic ME 7.1.1 | Motronic ME 7.1.1 | ||
| Knock control | 2 sensors | 2 sensors | ||
| Variable valve timing | Yes | Yes | ||
| Variable intake manifold | No | No | ||
| On Board Diagnostic (OBD) | Yes | Yes | ||
| Oxygen Sensor (O2) regulation | 3 sensors | 2 sensors | ||
| Catalytic converter | Yes | Yes | ||
| Exhaust Gas Recirculation (EGR) | No | No | ||
| Turbocharger, G-Charger | No | No | ||
| Secondary Air Injection (AIR) system | Yes | Yes | ||
| Electronic Power Control (EPC) | Yes | Yes | ||
| (1) SULEV: Super Ultra Low Emission Vehicles | ||||
| (1) | SULEV: Super Ultra Low Emission Vehicles |
