On Board Diagnostic - Automatic Transmission 01m (hatchback) Volkswagen New Beetle A4

TRANSMISSION, ELECTRICAL TEST

Special tools and workshop equipment required

1. Digital multimeter, Fluke 83 or equivalent
2. Adapter set VAG 1594A
3. Test box VAG 1598/18

Additional information required

1. New Beetle 1998 -->, Repair Information, Automatic Transmission 01M, refer to «AUTOMATIC TRANSMISSION 01M»(/volkswagen/new-beetle/a4-1997-2005/remont/automatic-trans/#general-technical-data-automatic-transmission-01m-hatchback)
2. New Beetle 1998 --> Electrical Wiring Diagrams, Troubleshooting and Component Locations binder

Test requirements

1. Battery voltage OK
2. Vehicle voltage supply OK
3. Fuses No. 7, 11, 15 and 31 OK
4. Fuse in main fuse box (110 amps) OK
5. Ground connections for transmission OK

Ground connection points are located in the plenum chamber and below the battery in the engine compartment.

Check battery Ground strap and Ground strap between battery and transmission.

SELECTABLE FUNCTIONS

Further functions, which can be printed out by pressing the HELP button, need not be considered.

The Scan Tool VAG 1551 returns to the following start position after checking each function

Indicated on display

OBD FUNCTION

The automatic transmission is controlled electro-hydraulically. On Board Diagnostic (OBD) refers specifically to the electronic/electric controls of the automatic transmission.

Additional Information

1. Repair Information, Automatic Transmission 01M. Refer to «ON BOARD DIAGNOSTIC SYSTEMS»(ref-492781-S01671769632012080600000) and refer to «AUTOMATIC TRANSMISSION»(ref-492781-S01497227702012080600000) and refer to «AUTOMATIC TRANSMISSION 01M»(/volkswagen/new-beetle/a4-1997-2005/remont/automatic-trans/#general-technical-data-automatic-transmission-01m-hatchback)

Transmission Control Module (TCM) -J217- with adaptive gear shift points (fuzzy logic)

The transmission control module determines the driving dependent gear shift points automatically.

Advantages

1. Gear shifts will be directed toward optimum fuel consumption
2. Maximum engine output is always available
3. Individual adaptation of gear shift points in all driving situations
4. Gear shift points are infinitely variable

Shift point variations for hills

An additional gear shift map automatically selects shifts for hills dependent upon accelerator pedal position and driving speed.

1. Gear shift map for extreme uphill stretches is matched to engine output
2. Gear shift map for extreme downhill stretches is matched to the braking effect of the engine

Safety functions of the Transmission Control Module (TCM) -J217

The TCM -J217- receives information from components that effect the selection of gears and passes the information on to solenoid valves in the valve body.

The control module is equipped with a Diagnostic Trouble Code (DTC) memory so that in the event of an electronic/electrical component malfunction or an open circuit the location can be determined quickly. Malfunctions are recognized by electrical signals and stored in the DTC memory.

If malfunctions occur in the monitored sensors or components, these are stored in the DTC memory together with an indication of the type of malfunction.

Malfunctions which only occur once are known as sporadic (temporary) malfunctions and are identified as such.

If malfunctions do not reoccur within a minimum of 5 km (3 miles) or 6 minutes or a maximum of 20 km (12 miles) or 24 minutes, they are stored as sporadic malfunctions.

Electrical malfunctions that affect vehicle performance can be determined with the Scan Tool VAG 1551.

The diagnostic possibilities can only be fully exploited with operating mode 1, "Rapid data transfer", of the Scan Tool VAG 1551.

For a list of functions which the Scan Tool VAG 1551 can register DTC TABLE .

Emergency running mode

If critical malfunctions occur when driving, the transmission will continue to operate, but in an emergency running mode. If the malfunction occurs in "D", "3" or "2", then 3rd gear emergency running mode is activated.

If the malfunction occurs in "1", "P", "N" or "R" then the emergency running mode for that stage is activated.

If the engine is started again in the emergency running mode and the malfunction occurs when the selector lever is in position "D", "3" or "2" then 3rd gear is activated hydraulically, until the malfunction is corrected.

For all malfunctions which can lead to the emergency running mode, the transmission will remain in this mode until the malfunction is no longer recognized by the control module over a predetermined period.

Malfunctions which may lead to emergency running

1. Open circuit in wiring
2. Short circuit in wiring
3. Wiring open circuit and/or CAN-Bus wiring short circuit.
4. Electrical or hydraulic components faulty

TCM -J217- Malfunction Recognition

If a malfunction exists it is stored as a static malfunction. If the malfunction no longer exists after a predetermined period or distance travelled, it is considered a sporadic malfunction.

Sporadic malfunctions are stored in the memory and displayed as "sporadic" when retrieved by the Scan Tool VAG 1551. "SP" appears on the right of the display in such cases. If the printer is switched on, "sporadic malfunctions" are printed out after the DTC memory is addressed.

Malfunctions which are stored in the memory as sporadically occurring malfunctions are automatically erased after 1, 000 km (625 miles) or 20 hours.

The information exchange between vehicle control modules is conducted by "CAN-Bus". The advantages of the "CAN-Bus" are a very rapid data transfer and less wiring in the vehicle.

Faulty CAN-Bus wiring, e.g. open circuits, can be directly detected as such by the control module. The exact location of the malfunction cannot be determined, however, until all control module DTC memories have been checked.

Scan Tool VAG 1551

From July 1997 a further number on the right next to the DTC code will be displayed/printed-out when checking the DTC memory (with up-todate program card version of VAG 1551). This number indicates the type of malfunction, which is also given again in text under the affected component on the VAG 1551 display.

DIAGNOSTIC GUIDE

Troubleshooting with Scan Tool VAG 1551

Scheme 58

1. Transmission Control Module -J217- Location «Location of Transmission Control Module (TCM) -J217»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__location-of-transmission-control-module-tcm) Removing «Removing TCM -J217»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__removing-tcm-j217) Installing «Installing TCM -J217»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__installing-tcm-j217) Checked by On Board Diagnostic (OBD) «VAG 1551, CONNECTING AND SELECTING FUNCTIONS»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__vag-1551-connecting-and-selecting-functions) tighten nut for ground wire (located left of TCM) to 9 ± 1 Nm (80 ± in. lb)
2. Engine Control Module Removing and installing (Scheme 59) Location (Scheme 59) NOTE: If engine or transmission control modules are replaced, the system must be returned to basic setting «BASIC SETTING, INITIATING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__basic-setting-initiating), Initiating basic setting.
3. Data Link Connector (DLC) Location (Scheme 60)
4. Valve body Location (Scheme 61) The solenoid valves -N88-, -N89-, -N90-, -N91-, -N92-, -N93- and -N94- are attached to the valve body The valves are checked by On Board Diagnostic (OBD)
5. Conductor strip with integrated Transmission Fluid Temperature Sensor -G93- Location see scheme 5 Removing and installing (Scheme 62) -G93- is checked by On Board Diagnostic (OBD)
6. Multi-Function Transmission Range (TR) Switch -F125- Location and removing and installing (Scheme 63) -F125- is checked by On Board Diagnostic (OBD)
7. Transmission Vehicle Speed (VSS) Sensor -G38- Location and removing and installing (Scheme 71) -G38- is checked by On Board Diagnostic (OBD)
8. Vehicle Speed Sensor (VSS) -G68- Location and removing and installing (Scheme 72) -G68- is checked by On Board Diagnostic (OBD)
9. Throttle Position (TP) Sensor -G69- Signal of -G69- is checked by On Board Diagnostic (OBD) Location, further information and removing and installing (Scheme 65)
10. Shift Lock Solenoid -N110- Location, removing and installing (Scheme 68) The solenoid is checked by On Board Diagnostic (OBD) Can be checked electrically «TRANSMISSION, ELECTRICAL TEST»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__transmission-electrical-test) and via reading measured value block «MEASURED VALUE BLOCK, READING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__measured-value-block-reading)
11. Transmission Range (TR) Selector Lever Display -Y5- Location (Scheme 64)
12. Cruise Control Switch -E45- Location, removing and installing (Scheme 67) Can be checked via reading measured value block «MEASURED VALUE BLOCK, READING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__measured-value-block-reading)
13. Kick Down Switch -F8- Location, further information and removing and installing (Scheme 66) Can be checked electrically «TRANSMISSION, ELECTRICAL TEST»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__transmission-electrical-test) and via reading measured value block «MEASURED VALUE BLOCK, READING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__measured-value-block-reading)
14. Brake Light Switch -F- Location, removing and installing (Scheme 69) Can be checked electrically «TRANSMISSION, ELECTRICAL TEST»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__transmission-electrical-test) and via reading measured value block «MEASURED VALUE BLOCK, READING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__measured-value-block-reading)
15. Park/Neutral Position (PNP) Relay -J226- Location (Scheme 70)

Scheme 59

Location: plenum chamber

Removing and installing control module.

[For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] ENGINE CONTROL MODULE , or refer to [For engine(s) APH, BNU, AWP, AWV, BKF] ENGINE CONTROL MODULE , or refer to [For engine(s) BPR, BPS] ENGINE CONTROL MODULE .

[For engine(s) BEW] ENGINE CONTROL MODULE , or refer to [For engine(s) ALH] ENGINE CONTROL MODULE

Scheme 60

Location: left of the steering column

Note. The DLC may be found in the center console on some vehicles.

Scheme 61

Location: above oil pan

The solenoid valves -N88-, -N89-, -N90-, -N91-, -N92-, -N93- and -N94- are attached to the valve body.

Removing and installing valve body. Removal and Installation

Location: in oil pan on valve body

Scheme 62

The conductor strip can be replaced with the transmission installed and without removing the valve body.

Note. Do not kink or damage the conductor strip.

Separate connector at transmission and remove retaining clamp.

Drain ATF.

Remove transmission oil pan and remove wiring guide.

Pry conductor strip off solenoid valve in direction of -arrow- with special tool Lever 3373.

Note. If the locating points are damaged the valve body must be replaced. Installation is performed in the reverse order. Do not kink or damage the conductor strip.

Removing and installing valve body. Removal and Installation

Scheme 63

Location: on rear of transmission

Removing and installing multi-function TR switch

Switch off ignition.

Pull connector off multi-function TR switch.

Remove bolt and retainer.

Remove multi-function TR switch.

Replace seal.

Installation is performed in the reverse order.

Tighten bolt to10 Nm (7 ft lb).

Scheme 64

Location: in instrument cluster

Removing and installing selector lever position display.

Removal and Installation

Scheme 65

Locations

On gasoline engines the TP sensor is a component part of the Throttle Valve Control Module -J338- located on the throttle valve housing (engine).

On Diesel engines the "throttle valve signal" is generated in the Throttle Position (TP) Sensor -G79- located near the accelerator pedal.

For On Board Diagnostic (OBD)

The TP sensor is an engine control module sensor. However, the transmission control module also requires the TP signal.

On vehicles with CAN-Bus, the automatic transmission control module receives the TP signal from the CAN-Bus.

The On Board Diagnostic (OBD) of the automatic transmission only checks the signal, not the sensor! On vehicles without CAN-Bus, the wire for the signal is also checked.

The signal can only be read in the Measured Value Block.

Note. Always check the engine OBD when the transmission OBD indicates that the TP sensor is faulty.

Checking and adjusting or removing and installing throttle valve potentiometer

THROTTLE VALVE CONTROL MODULE

[For engine(s) BEW] Removal and Installation

Scheme 66

Locations

Integrated into accelerator cable and is located on bulkhead in engine compartment

On vehicles which do not have an accelerator cable the kickdown signal is generated in the Throttle Position (TP) Sensor -G79- located near the accelerator pedal.

For On Board Diagnostic (OBD)

On vehicles without an accelerator cable, the kickdown switch signal is transmitted from the engine control module to the transmission control module.

Removing and installing kick down switch

The accelerator cable must be removed to be able to remove and install the kick down switch. Readjust the cable after installing the switch.

Scheme 67

Location: on steering column switch

Removing and installing cruise control switch. Steering Column Switch

Scheme 68

Location: in the selector lever housing

Removing and installing selector lever lock solenoid. Removal and Installation

Scheme 69

Location: on pedal cluster

Removing and installing brake light switch. Removal and Installation

Scheme 70

Location: on additional relay carrier under instrument panel, left side

Relay is marked with number "175" -arrow-.

Scheme 71

Location: on top of transmission

Removing and installing transmission vehicle speed sensor

Switch off ignition.

Disconnect connector from sensor.

Remove bolt and take out sensor.

Replace seal.

Installation is performed in the reverse order.

Tighten bolt to 10 Nm (7 ft lb).

Scheme 72

Location: on top of transmission

When the transmission is installed the sensor is covered by the left transmission mount.

Removing and installing vehicle speed sensor

Additional information

1. Repair Information, Automatic Transmission 01M. «Removal and Installation»(/volkswagen/new-beetle/a4-1997-2005/remont/ac-compressor/#general-technical-data-refrigerant-r134a-servicing-hatchback)

Special tools, testers and auxiliary items: Removal and Installation

Obtain radio code for vehicles with coded radio.

Switch ignition off and disconnect battery Ground strap.

Remove battery.

Remove air cleaner.

Install support bar 10-222A with legs 10-222A/8 and support engine/transmission in position.

Scheme 73

Remove bracket for power steering pressure hose.

Scheme 74

Remove pendulum support -arrows-.

Scheme 75

Lower transmission approx. 60 mm (2.4 in.) -a-.

Scheme 76

Disconnect black connector from sensor.

Remove bolt and take sensor -1- out.

Replace seal.

Installation is performed in the reverse order.

Tighten bolt to 10 Nm (7 ft lb).

Tightening torques

Specifications

Location of Transmission Control Module (TCM) -J217

The control module -arrow- is located in the plenum chamber, center right.

Scheme 77

Removing TCM -J217

Switch off ignition.

Remove inner cover of plenum chamber. Removal and Installation

Disconnect multi-pin connector, then remove connector from control module.

Scheme 78

Remove screws -arrows-.

Scheme 79

Remove control module.

Installing TCM -J217

Install the TCM in the reverse order of removal and note the following

Locate multi-pin connector on TCM -J217- pins -arrows- then lock connector.

Scheme 80

Perform On Board Diagnostic (OBD) VAG 1551, CONNECTING AND SELECTING FUNCTIONS .

Initiate basic setting BASIC SETTING, INITIATING .

OBD TECHNICAL DATA

DIAGNOSIS AND TESTING

Transmission, Electrical Test

VAG 1551, CONNECTING AND SELECTING FUNCTIONS

Test Conditions

1. Vehicle voltage supply OK
2. Fuses No. 07, 11, 15 and 31 OK
3. Fuse in main fuse box (110 amps.) OK
4. Ground connections for transmission OK
5. Selector lever in "P" and parking brake applied

Check Ground connections for corrosion and poor contact; repair if necessary.

Ground connecting points are located in plenum chamber and below the battery in engine compartment.

Check battery Ground strap and Ground strap between battery and transmission.

Switch ignition off and connect Scan Tool VAG 1551 with adapter VAG 1551/3A.

Indicated on display

or

1. appears alternately.

Note. The DLC may be found in the center console on some vehicles. Additional operating instructions can be retrieved by pressing the HELP button of VAG 1551. The --> button is used for advancing within the program sequence. An automatic check (buttons 00) can be selected in operating mode 1 "Rapid data transfer". All vehicle control modules will then be checked automatically.

Switch on ignition.

Switch on printer with Print button (indicator lamp in button lights).

Press button 1 for "Rapid data transfer" mode.

Indicated on display

Press buttons 0 and 2 to enter "transmission electronics" address word 02.

Indicated on display

Confirm entry with Q button.

Example

The control module identification, the coding and the dealership number of the VAG 1551 are displayed

Control Module Identification

Depending upon build level (program level) the control module can indicate a different control module identification to that shown in the example.

1. 01M 927 733 FK: Part No.
2. AG4 transmission 01M: 4-speed automatic transmission 01M
3. 3952: EPROM (Program level)
4. Coding 00000: not required at present.
5. WSC 00000: VAG 1551 dealership number with which the last coding was performed.

Indicated on display

Press HELP button to print out a list of possible fault causes.

After eliminating possible causes of faults, again enter the address word 02 for "transmission electronics" and confirm.

If "Control module does not answer!" again appears

Indicated on display

Check control module voltage supply.

Perform test step 1 TRANSMISSION, ELECTRICAL TEST , Electrical check.

Check wiring connections to Data Link Connector (DLC). Refer to the appropriate SYSTEM WIRING DIAGRAMS information.

Diagnostic Trouble Code (DTC) table, DTC TABLE under DTC 65535 control module faulty!

Press --> button.

Indicated on display

After the HELP button is pressed, a list of the possible functions is printed out.

DTC MEMORY, CHECKING

Connect Scan Tool VAG 1551 and enter address word "02 Transmission electronics".

Advance until "Select function XX" appears in display VAG 1551, CONNECTING AND SELECTING FUNCTIONS .

Indicated on display

Press buttons 0 and 2 to select "Check DTC memory".

Indicated on display

Confirm entry with Q button.

The number of stored DTCs or "No DTC recognized" appears in the display.

The stored DTCs are displayed in turn and printed out. After the last DTC has been displayed and printed out

Correct malfunctions as described in the DTC table DTC TABLE .

Press --> button.

Indicated on display

After checking the DTC memory and correcting the malfunctions

Erase DTC memory DTC MEMORY, ERASING .

DTC TABLE

Note. All the possible DTCs which are recognized by the Transmission Control Module -J217- and displayed on the Scan Tool VAG 1551 with the printer switched on, are listed below grouped according to the DTC number. If malfunctions occur only occasionally or if the DTC memory was not erased after correcting the malfunctions, these will be displayed as "sporadic malfunctions" for a stipulated period of time TCM -J217- malfunction recognition, TCM -J217- Malfunction Recognition . If components are indicated as being faulty when the DTC memory is checked, additionally test the wiring to the components for short and open circuits according to the wiring diagram. Refer to the appropriate SYSTEM WIRING DIAGRAMS information. The DTC and (with 7.0 program card) the type of malfunction in numbers is printed out in the "rapid data transfer" mode only when the VAG 1551 printer is switched on. Example: DTC (5-position) 65535 XYZ (type of DTC, explained in text below component name)

Note. Do not replace the Transmission Control Module -J217-, ELECTRICAL AND ELECTRONIC COMPONENTS AND LOCATIONS , or return the system to basic setting, BASIC SETTING, INITIATING , until the possible cause of any malfunction has been determined and the following types of malfunction have been corrected: mechanical malfunctions hydraulic malfunctions all affected electrical/electronic components and wiring connections

DTC MEMORY, ERASING

Requirement

1. DTC memory has been checked «DTC MEMORY, CHECKING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__dtc-memory-checking) .

Indicated on display

Press buttons 0 and 5 to select "Erase DTC memory" function 05.

Indicated on display

Confirm entry with Q button.

Display reads

Note. If the ignition was switched off between checking the DTC memory and erasing the DTC memory, the DTC memory will not be erased. Always adhere to the sequence of operations, i.e. first check the DTC memory.

Indicated on display

(The DTC memory will be erased approx. 5 secs. after the display appears.)

Note. Wait about 1 minute before checking the DTC memory again.

Indicated on display

Print out with printer switched on

or

The Transmission Control Module -J217- was not given sufficient time to recognize malfunctions.

Wait about 1 minute before checking DTC memory again.

After checking and erasing DTC memory, test drive vehicle and check DTC memory again.

The following display should appear

"No DTC recognized!"

BASIC SETTING, INITIATING

Note. Initiate the basic setting after performing the following repairs: Engine replacement Engine control module replacement Throttle valve replacement/adjustment (setting idling speed) Throttle Position (TP) Sensor -G69- replacement TP Sensor -G69- setting alteration, e.g. when adjusting Closed Throttle Position (CTP) Switch (engine) Transmission Control Module (TCM) -J217- replacement

Connect Scan Tool VAG 1551 and enter address word "02 transmission electronics". Advance until "Select function XX" appears in display from VAG 1551, CONNECTING AND SELECTING FUNCTIONS .

Indicated on display

Press buttons 0 and 4 to select "Initiating basic setting" function 04.

Note. The accelerator pedal must remain in the idling position.

Indicated on display

Confirm entry with Q button.

Indicated on display

Press button 0 , 0 and 0 .

Confirm entry with Q button.

Indicated on display

The system is now in the basic setting.

Depress accelerator pedal as far as kickdown and hold in this position for 3 seconds.

Press button --> .

Indicated on display

MEASURED VALUE BLOCK, READING

Additional information

1. Electrical Wiring Diagrams, Troubleshooting and Component Locations binder.

Connect Scan Tool VAG 1551 and enter address word "02 transmission electronics". Advance until "Select function XX" indicated on display, from VAG 1551, CONNECTING AND SELECTING FUNCTIONS .

Indicated on display

Press buttons 0 and 8 to select "Read measured value block" function 08.

Indicated on display

Confirm entry with Q button.

Indicated on display

Enter display group number List of selectable display group numbers, List of selectable display group numbers .

Confirm entry with Q button.

4 display fields always appear in the measured value block (in physical values if necessary). Decoding the individual values in display fields 1 to 4 Test table TEST TABLE .

List of selectable display group numbers

Note. If the printer is switched on, the current display is printed out. If the specified values are reached in all the display fields

Press --> button.

Indicated on display

TEST TABLE

Reading measured value block; Display group number 004; "Checking solenoid valves while driving"

Note. The solenoid valves can be checked while driving via "Read measured value block 08" ; display group number 004. The table shows the solenoid valves -N88-, -N89- and -N90- (displays 1 to 3) as activated in each selector lever position. These solenoid valves control the shift valves for the relevant gears. The solenoid valve -N91- activates the lock-up clutch modulation valve and is not covered here. The solenoid valves -N92- and -N94- are supplementary valves which affect gear shifts. These valves are only controlled during gear shifts and are displayed in fields 5 and 6. They can show "0" or "1" depending on the driving situation. At the start of a test drive the selector lever can be in position "1". During the drive it can be shifted progressively up to position "D". The mechanical gear "M" is not always engaged. The control module can engage this gear dependent upon the driving situation. The lock-up clutch can be checked in display group number 005. VAG 1551 display field 1 has 6 characters (0000 00) and is read as follows

1. Non-activated solenoid valves display "0" and activated solenoid valves display "1".
2. All solenoid valves are checked via On Board Diagnostic (OBD) Checking DTC memory, «DTC MEMORY, CHECKING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__dtc-memory-checking) .

Checking solenoid valves while driving

ELECTRICAL TEST

Switch off ignition.

Remove plenum panel inner cover. Removal and Installation

Release multi-pin connector, then disconnect connector from control module.

Connect test box VAG 1598/18 to multi-pin connector -1- and lock in direction of -arrow 2-.

Scheme 81

Using the test box VAG 1598/18 the wiring can be checked according to the wiring diagram.

Note. For testing use a Fluke 83 multimeter or equivalent with auxiliay wiring from VAG 1594. The specified values are valid for an ambient temperature of 0° - 40° C (50 - 104° F). If measured values deviate from the specified values, determine the malfunction using the appropriate wiring diagram. If measured values deviate only slightly from the specified values, clean the sockets and connectors of the testers and test leads and repeat the test. Before replacing the particular components, test wiring and connections and, particularly if specified values are below 10 ohms, repeat resistance measurement on component. Before replacing components, check the respective wiring and connectors. Repeat resistance tests when values are below 10 ohms

After electrical tests

Connect multi-pin connector on Transmission Control Module -J217- pins -arrows- then lock connector.

1. Conducting On Board Diagnostic (OBD) «VAG 1551, CONNECTING AND SELECTING FUNCTIONS»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__vag-1551-connecting-and-selecting-functions)
2. Initiating basic setting «BASIC SETTING, INITIATING»(/volkswagen/new-beetle/a4-1997-2005/remont/testing-diagnostics/#on-board-diagnostic-automatic-transmission-01m-hatchback__basic-setting-initiating)

Transmission Control Module (TCM) -J217- 68-pin connector (socket numbers on VAG 1598/18)

Overview of test steps

1. Conduct only those test steps recommended in the Diagnostic Trouble Code (DTC) and measured value block tables
2. Steps listed below according to component

Test Step 15 - Multi-Function Transmission Range Switch F125

Disconnect connector from multi-function TR switch.

Connector Pin Assignment

Scheme 82

1. To Pin 63 of TCM connector
2. To Pin 40 of TCM connector
3. To pin Pin 1 of TCM connector (Ground)
4. Vacant
5. To Pin 18 of TCM connector
6. To Pin 62 of TCM connector
7. To Pin 23 of TCM connector (voltage supply terminal 15)

Supply Voltage, Checking

Connect test box VAG 1598/18.

Switch multimeter to 20 V measuring range.

Switch ignition on.

Measure between terminal 7 and terminal 3 (Ground) on disconnected multi-function TR switch connector.

Specification: Battery voltage

Measure from terminal 7 of connector to socket 1 on 1598/18 (Ground).

Measure from socket 23 (terminal 15) on 1598/18 to socket 1 on 1598/18 (Ground).

Specification: Battery voltage

If the specifications are not obtained:s Repair wiring according to wiring diagram.

If the specifications are obtained: Check wiring further.

Switch ignition off.

Remove relay for Park/Neutral Position (PNP) Relay -J226-.

Set multimeter to 200 ohms resistance measuring range.

Check the wiring between the multi-pin connector on the TCM and the connector on the multi-function TR switch.

Measure between sockets 1 and 18 on VAG 1598/18.

Specification: Infinity ohms

Measure between sockets 23 and 18 on VAG 1598/18.

Specification: Infinity ohms

Measure between socket 18 on VAG 1598/18 and terminal 5 on connector.

Specification: Less than 1.5 ohms

If the specifications are not obtained: Repair wiring using wiring diagram.

If the specifications are obtained: Check wiring further

Measure between sockets 1 and 63 on VAG 1598/18.

Specification: Infinity ohms

Measure between sockets 23 and 63 on VAG 1598/18.

Specification: Infinity ohms

Measure between socket 63 on VAG 1598/18 and terminal 1 on connector.

Specification: Less than 1.5 ohms

If the specifications are not obtained: Repair wiring according to the wiring diagram.

If the specifications are obtained: Check wiring further

Measure between sockets 1 and 62 on VAG 1598/18.

Specification: Infinity ohms

Measure between sockets 23 and 62 on VAG 1598/18.

Specification: Infinity ohms

Measure between socket 62 on VAG 1598/18 and terminal 6 on connector.

Specification: Less than 1.5 ohms

If the specifications are not obtained: Repair wiring using wiring diagram.

If the specifications are obtained: Check wiring further

Measure between sockets 1 and 40 on VAG 1598/18.

Specification: Infinity ohms

Measure between sockets 23 and 40 on VAG 1598/18.

Specification: Infinity ohms

Measure between socket 40 on VAG 1598/18 and terminal 2 on connector.

Specification: Less than 1.5 ohms

If the specifications are not obtained: Repair wiring using wiring diagram.

If the specifications are obtained: Replace multi-function TR switch (Scheme 63).

Install Park/Neutral Position (PNP) Relay -J226-.

Scheme 83

Special tools and workshop equipment required

1. Adapter set VAG 1594A
2. Test box VAG 1598/18

Special tools and workshop equipment required

Scheme 84

Scheme 85

1. Scan Tool VAG 1551
2. Adapter VAG 1551/3A

See also:
• AUTOMATIC TRANSMISSION 01M
• [For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] ENGINE CONTROL MODULE
• [For engine(s) APH, BNU, AWP, AWV, BKF] ENGINE CONTROL MODULE
• [For engine(s) ALH] ENGINE CONTROL MODULE
• Removal and Installation
• Removal and Installation
• Steering Column Switch
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Removal and Installation
• Diagnosis and Testing
• ENGINE CONTROL MODULE DTC MEMORY, CHECKING AND ERASING
• Diagnosis and Testing
• Removal and Installation
• [For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] ACCELERATOR PEDAL CABLE OVERVIEW
• VAG 1551, CONNECTING AND SELECTING FUNCTIONS
• DTC MEMORY, CHECKING
• BASIC SETTING, INITIATING
• DTC MEMORY, ERASING
• MEASURED VALUE BLOCK, READING
• DTC TABLE
• Location of Transmission Control Module (TCM) -J217
• Removing TCM -J217
• Installing TCM -J217
• TRANSMISSION, ELECTRICAL TEST
• ELECTRICAL AND ELECTRONIC COMPONENTS AND LOCATIONS
• TCM -J217- Malfunction Recognition
• List of selectable display group numbers
• TEST TABLE
• Removing and installing vehicle speed sensor
