Note. Make sure locking cable is routed correctly when installing Illustration -N37- -0667, LOCKING CABLE . Locking cable must not be kinked. Adjust locking cable after installing LOCKING CABLE, ADJUSTING .

Shift selector lever into "P" position.

Press locking cable into support bracket on selector lever housing until tabs on retaining clip -arrows- spring outward.

Attach locking cable in locking lever.

Turn ignition key to "ignition on" position.

Push locking cable into steering lock Fig. A37-0206, LOCKING CABLE => Pull out clip -2- for locking cable -3-. .

Push clip into locking cable.

Make sure that clip is properly located.

Adjusting locking cable LOCKING CABLE, ADJUSTING .

Special tools and workshop equipment required

Support device 10-222A (modifying guide 10-222A/21 «GUIDE 10-222A/21 FROM 10-222A, MODIFYING»(/volkswagen/new-beetle/a4-1997-2005/remont/automatic-trans/#controls-housing-automatic-transmission-01m-hatchback__guide-10-222a21-from-10-222a-modifying) )
Hose clamps 3094
Transmission support 3282
Adjustment plate 3282/2
Engine support 3300A
Transmission lifting beam 3336
Support rails VW457/1 (modifying «SUPPORT RAILS VW 457/1, MODIFYING»(/volkswagen/new-beetle/a4-1997-2005/remont/automatic-trans/#controls-housing-automatic-transmission-01m-hatchback__support-rails-vw-4571-modifying) )
Adapter 10-222A/8
Torque wrench VAG1331
Torque wrench VAG1332
Engine/transmission jack VAG1383A
Socket V/175

Removing

Remove cover from engine.

Check whether a coded radio is installed. If so, obtain anti-theft coding.

With ignition switched off disconnect battery Ground strap.

Remove power steering reservoir from battery carrier. Do not loosen hoses.

Tie power steering reservoir to lock carrier.

Remove battery.

Remove battery carrier.

Pull intake hose -1- and connector -2- off mass air flow sensor.

Scheme 76

Remove bolts -3-, -4- and -5-.

Remove air cleaner complete.

Disconnect connector from speedometer sensor.

Remove electrical connections -1- to -4- at transmission.

Scheme 77

To solenoid valves
To vehicle speed sensor (VSS) -G68
To multi-function transmission range (TR) switch -F125
On transmission vehicle speed sensor (VSS) -G38

Unclip wiring harness from retainer on transmission and place to one side.

Remove bracket for power steering pressure lines/hoses, with retainer for wiring harness, from transmission.

Position selector lever in position "P" and press selector lever cable -1- off selector shaft lever -2- with a screwdriver.

Remove circlip -3- at selector lever cable support bracket and remove selector lever cable.

Note. Do not kink selector lever cable.

2.0L Engine

Unscrew sensor from speedometer drive.

Scheme 78

Remove bolt -2-.

Remove heat shield -3- from engine exhaust manifold.

Continued for all vehicles

Remove Ground cable -1- from upper engine/transmission securing bolt.

Scheme 79

Disconnect electrical connections -3- and -4- on Starter.

Separate connector -2- and pull out of retainer.

Remove wiring harness retainer on Starter.

Remove upper Starter motor bolt.

Clamp-off ATF cooler hoses with 3094 and disconnect at ATF cooler.

Scheme 80

Seal off ATF cooler with clean plugs.

Remove upper engine/transmission securing bolts.

Erect support device 10-222A with adapter 10-222A/8.

Scheme 81

Note. Do not seat the adapter 10-222A/8 on the securing bolts for the front end/fender.

Take weight of engine/transmission assembly on spindles.

Remove front left wheel bolts.

Raise vehicle.

Remove left front wheel.

Remove sound insulation tray -arrows-.

Scheme 82

Remove left sound insulation -arrows-.

Scheme 83

TDI Engine

Remove charge air pipe between charge air cooler and exhaust gas turbocharger.

Continued for all vehicles

Remove right sound insulation.

Remove ATF oil pan protective plate -arrows-.

Scheme 84

Remove power steering pressure lines/hoses from Starter and transmission.

Remove lower Starter bolt

Remove Starter. Removal and Installation

Remove right hand inner constant velocity joint protective cover from engine if installed.

Disconnect drive shafts at transmission flanges.

Raise right drive shaft and secure.

Remove pendulum support -arrows-.

Scheme 85

Remove additional radiator fan on right-hand side of vehicle, if part of original equipment. [For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] Removal and Installation , or refer to [For engine(s) APH, BNU, AWP, AWV, BKF] Removal and Installation , or refer to [For engine(s) ALH] Removal and Installation , or refer to [For engine(s) BPR, BPS] Removal and Installation , or refer to [For engine(s) BEW] Removal and Installation .

Unclip cap for torque converter cover.

Remove nut -arrow- from torque converter (Qty. 3) using special tool V 175.

Scheme 86

Turn crankshaft 120° further in each case.

Turn steering to left lock.

Mark installation position of ball joint bolts on left-hand control arm and remove bolts.

Remove bolts (arrows).

Scheme 87

Disconnect left coupling rod -1- from control arm and turn rod upward.

Scheme 88

Swing wheel bearing housing outward.

Guide left-hand drive shaft -2- out between assembly carrier and transmission.

Lift drive shaft and secure to suspension strut with wire.

Disconnect exhaust system after front exhaust pipe at double clamp. Remove front exhaust system supports from assembly carrier if necessary. [For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] REMOVAL AND INSTALLATION , or refer to [For engine(s) BPR, BPS] REMOVAL AND INSTALLATION , or refer to [For engine(s) APH, BNU, AWP, AWV, BKF] Description and Operation , or refer to [For engine(s) ALH] Description and Operation , or refer to [For engine(s) BEW] Description and Operation

Remove left assembly mounting -2- hex bolts -arrows- from left mount -1-.

Scheme 89

Carefully tilt engine and transmission by lowering left-hand spindle approx. 60 mm on support bar 10-222A.

Remove left mount -1- from transmission -arrows-.

Scheme 90

Bolt Support rails VW 457 to both pendulum support securing holes on subframe.

Scheme 91

Insert spacers totaling 6 mm between subframe and support rail VW457/1.

A- Qty. 2 hex bolts M 8 x 25

Install support device 3300A and tighten with bolt -B-.

Tilt engine and transmission forward with support device 3300A.

Set up transmission support 3282.

Scheme 92

The transmission support 3282 is set up with the adjusting plate 3282/2 for removing the automatic transmission 01M.

The symbols on the adjusting plate indicate the supports required.

Move jack VAG 1383A with transmission support 3282 underneath and support transmission.

Scheme 93

Place safety support pin on oil pan and secure to transmission housing (arrow).

Scheme 94

Turn right-hand drive flange so that flattened side -arrow- is in a vertical position.

Scheme 95

Remove lower engine/transmission connecting bolts.

Press transmission off engine while pressing torque converter out of drive plate.

Press torque converter against ATF pump.

Lower transmission slightly.

While lowering guide power steering pressure line past transmission.

Swivel transmission and carefully lower, guiding right-hand drive flange past engine and support 3300A.

Check also that multi-function TR switch does not contact assembly carrier.

Secure torque converter to prevent it falling out.

Installing

Installation is performed in the reverse order of removal.

When installing the torque converter, ensure that both drive pins engage in the ATF pump inner wheel recesses.

Before installing, ensure that dowel sleeves are correctly located.

When installing transmission, observe torque converter contact impression on drive plate.

Replace selector cable anchorage locking washer.

Check selector lever cable adjustment, adjust if necessary SELECTOR LEVER CABLE, CHECKING AND ADJUSTING .

Check and top off ATF level ATF LEVEL, CHECKING .

Perform On Board Diagnostic (OBD) Diagnosis and Testing

LOCKING CABLE Volkswagen New Beetle A4

LOCKING CABLE

Scheme 74

Scheme 75
