| WARNING | Never replace a fuse with one that has a higher amperage rating. A fuse with a too high amperage could damage the electrical part and cause a fire. On no account should fuses be repaired (e.g. with tin foil or wire) as this may cause serious damage elsewhere in the electrical circuit or cause a fire. |
FUSE COLOR IDENTIFICATION
| Fuse Color | Amp Rating |
|---|
| Black | 1A |
| Violet | 2A |
| Lilac | 3A |
| Beige | 5A |
| Brown | 7.5A |
| Red | 10A |
| Blue | 15A |
| Yellow | 20A |
| White | 25A |
| Green | 30A |
| Orange | 30A |
| Green | 40A |
| Orange | 40A |
| Red | 50A |
| Blue | 60A |
| Yellow | 60A |
| Brown | 70A |
| White | 80A |
| Blue | 100A |
| Pink | 125A |
| Gray | 150A |
| Purple | 200A |
| Note: Variation in fuse color, interior fuses may differ in color from the fuses (SA) in the engine compartment. |
Scheme 1
Scheme 1: Overview Of Fuses (SA), (SB), On Electric Box
Scheme 2
Scheme 3
Scheme 4
1 - Fuses (SA) On Fuse Panel "A"
2 - Fuses (SB) On Electronics Box High / Low
| Location No. | Description/ Refer to | Figure |
|---|
| 1 Fuses (SA) On Fuse Panel "A" | Location of fuses (SA) on fuse panel on Electronics Box, in engine compartmet: - Fuse Arrangements (SA) On Fuse Panel On Electronics Box - Engine Compartment - Left Side - Fuses (SA) on fuse panel on Electronics Box High, from November 2004: - Fuses (SA) On Fuse Panel On Electronics Box High - From November 2004 - Fuses (SA) on fuse panel on Electronics Box Low, from May 2005: - Fuses (SA) On Fuse Panel On Electronics Box Low - From May 2005 - Fuses (SA) on fuse panel on Electronics Box High, engine code BPY, from May 2005: - Fuses (SA) On Fuse Panel On Electronics Box High - Engine Code BPY - From May 2005 - Fuses (SA) on fuse panel on Electronics Box Low, from July 2006: - Fuses (SA) On Fuse Panel On Electronics Box Low - From July 2006 - Fuses (SA) on fuse panel on Electronics Box High, engine code BP from July 2006: - Fuses (SA) On Fuse Panel On Electronics Box High - Engine Code BPY - From July 2006 - Fuses (SA) on fuse panel on Electronics Box Low, from July 2007: - Fuses (SA) On Fuse Panel On Electronics Box Low - From July 2007 - Fuses (SA) on fuse panel on Electronics Box High, engine code BPY, from July 2007: - Fuses (SA) On Fuse Panel On Electronics Box High - Engine Code BPY - From July 2007 | (Scheme 1), (Scheme 2) |
| 2 Fuses (SB) On Electronics Box High | Location of fuses on electronics box,in engine compartmet, left side: - Fuse Arrangements (SB) On Fuse Panel On Electronics Box High - Engine Compartment - Left Side - Fuses (SB) on Electronics Box High, from November 2004: - Fuses (SB) On Fuse Panel On Electronics Box High - From November 2004 - Fuses (SB) on Electronics Box High, from May 2005: - Fuses (SB) On Fuse Panel On Electronics Box High - From May 2005 - Fuses (SB) on Electronics Box High, from July 2006: - Fuses (SB) On Fuse Panel On Electronics Box High - From July 2006 - Fuses (SB) on Electronics Box High, from July 2007: - Fuses (SB) On Fuse Panel On Electronics Box High - From July 2007 | (Scheme 3) |
| 2 Fuses (SB) On Electronics Box Low | Location of fuses on electronics box, low, in engine compartment, left side: - Fuse Arrangements (SB) On Fuse Panel On Electronics Box Low - Engine Compartment - Fuses (SB) on Electronics Box Low, from May 2005: - Fuses (SB) On Fuse Panel On Electronics Box Low - From May 2005 - Fuses (SB) on Electronics Box Low, from July 2006: - Fuses (SB) On Fuse Panel On Electronics Box Low - From July 2006 - Fuses (SB) on Electronics Box Low, from July 2007: - Fuses (SB) On Fuse Panel On Electronics Box Low - From July 2007 | (Scheme 4) |
Overview Of Fuses On (SC) Panel, Circuit Breaker & Relay Holder
Note. The under instrument panel circuit breaker holder also supports relays, for location of other relay used on vehicle, refer to RELAYS .
Scheme 5
Scheme 5: Overview Of Fuses On (SC) Panel, Circuit Breaker & Relay Holder
Scheme 6
Scheme 7
1 - Fuses (SC) On Fuse Panel "C"
| Location No. | Description Refer to |
|---|
| 1 Fuses (SC) On Fuse Panel "C": (1) | Location of fuses on fuse panel instrument panel, left: - Fuse (SC) Arrangement In Fuse (C) Panel, Instrument Panel - Left Side - Fuse arrangements, electronics box Low from November 2004: - Fuses (SC) On Fuse Panel C (Low E-Box) From November 2004 - Fuse arrangements, electronics box Low, from May 2005: - Fuses (SC) On Fuse Panel C (Low E-Box) From May 2005 - Fuse arrangements, electronics box High, engine code BPY from May 2005: - Fuses (SC) On Fuse Panel C (High E-Box) From May 2005 - Fuse arrangements, electronics box Low, from July 2006: - Fuses (SC) On Fuse Panel C (Low E-Box) From July 2006 - Fuse arrangements, electronics box High, engine code BPY, from July 2006: - Fuses (SC) On Fuse Panel C (High E-Box) From July 2006 - Fuse arrangements, electronics box Low, from July 2007: - Fuses (SC) On Fuse Panel C (Low E-Box) From July 2007 - Fuse arrangements, electronics box High, engine code BPY from July 2007: - Fuses (SC) On Fuse Panel C (High E-Box) From July 2007 |
| (1) For location of fuse box SC, refer to illustrations (Scheme 5) and (Scheme 6). |
2 - Circuit Breaker -Left Side
| Location No. | Description/ Refer to |
|---|
| 2 Circuit Breaker under Instrument Panel -Left Side: (1) | Driver Power Seat Adjustment Circuit Breaker 1 -S44- 30A, from May 2005: - Circuit Breakers Under Instrument Panel, Left Side - From May 2005 - Driver Power Seat Adjustment Circuit Breaker 1 -S44- 30A, engine code BPY, from May 2005: - Circuit Breakers Under Instrument Panel, Left Side, Engine Code BPY, From May 2005 - Driver Power Seat Adjustment Circuit Breaker 1 -S44- 30A, from July 2006: - Circuit Breakers Under Instrument Panel, Left Side, From July 2006 - Driver Power Seat Adjustment Circuit Breaker 1 -S44- 30A, engine code BP from July 2006: - Circuit Breakers Under Instrument Panel, Left Side, Engine Code BPY, From July 2006 - Driver Power Seat Adjustment Circuit Breaker 1 -S44- 30A, from July 2007: - Circuit Breakers Under Instrument Panel, Left Side, From July 2007 - Driver Power Seat Adjustment Circuit Breaker 1 -S44- 30A, engine code BPY, from July 2007: - Circuit Breakers Under Instrument Panel, Left Side, Engine Code BPY, From July 2007 |
| (1) For component location, refer to illustrations (Scheme 5) and (Scheme 7). |
Scheme 8
Scheme 8: Relay Arrangements, Overview, From November 2004
| Location No. | Description | Refer to |
|---|
| 1 | Relay arrangements on auxiliary relay panel, below E-Box, in engine compartment, left side | Relay arrangements: - AUXILIARY RELAY PANEL, BELOW E-BOX - ENGINE COMPARTMENT - LEFT SIDE (FROM NOVEMBER 2004) |
| 2 | Relay arrangements in engine compartment, left side | Relay arrangements, E-Box with 54 Fuses: -2.0L Engine Turbo (FSI) from May 2005: - RELAYS, E-BOX WITH 54 FUSES - ENGINE COMPARTMENT - LEFT SIDE (FROM NOVEMBER 2004) -Relay arrangements, E-Box with 30 Fuses: - RELAYS, E-BOX WITH 30 FUSES - ENGINE COMPARTMENT - LEFT SIDE (FROM MAY 2005) |
| 3 | Relay arrangements on relay panel at Vehicle Electrical System Control Module under instrument panel, left side | Relay arrangements: - RELAYS ON RELAY PANEL AT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE UNDER INSTRUMENT PANEL, LEFT SIDE (FROM NOVEMBER 2004) |
| 4 | Relay arrangements on relay panel be low instrument panel, left side | Relay arrangements: - RELAY ARRANGEMENTS AND CIRCUIT BREAKERS ON RELAY PANEL, BELOW INSTRUMENT PANEL, LEFT SIDE |
