Heating, Ventilation (Sedan) (A5 Platform): Overview Volkswagen Jetta V

Automatic HVAC System 3 illustrations ~513 words

PASSENGER COMPARTMENT HEATING OVERVIEW

Disconnect battery before removing components marked with **. Refer to [For transmission(s) 0A4, 02E, 09G, 02Q] [For engine(s) BRM, BGP, BPY, BGQ, CBTA, CBEA, CJAA, CBUA, CCTA, CBFA] Removal and Installation .

Scheme 53

Scheme 53: PASSENGER COMPARTMENT HEATING OVERVIEW
  1. Dash Panel **
  2. Center Vents Removing vents, refer to «CENTER VENT»(ref-479481-S26051043982012061300000) .
  3. Right Side Vent
  4. Right Vent Removing vents, refer to «RIGHT OR LEFT VENT»(ref-479481-S40183013342012061300000) .
  5. Fresh Air and Heated Air Controls With Fresh Air/Recirculation Door Switch -E159-. On vehicles with an auxiliary heater, also with Immediate Heating Button -E537-. Removing controls, refer to «HEAT AND FRESH AIR CONTROLS»(ref-479481-S24783076542012061300000) .
  6. Fresh/Recirculating Air Door Motor -V154- Removing, refer to «FRESH/RECIRCULATED AIR DOOR MOTOR -V154»(ref-479481-S09998549562012061300000) .
  7. Right Footwell Vent Removing and installing, refer to «RIGHT FOOTWELL VENT»(ref-479481-S05715614502012061300000) .
  8. Fresh Air Blower -V2- Removing, refer to «FRESH AIR BLOWER -V2»(ref-479481-S34009433552012061300000) .
  9. Fresh Air Blower Series Resistor With Fuse -N24- Removing and installing, refer to «FRESH AIR BLOWER SERIES RESISTOR WITH FUSE -N24»(ref-479481-S07696597442012061300000) .
  10. Heating Unit Partition Removing, refer to «REMOVING HEATER PARTITION»(ref-479481-S07494871322012061300000) .
  11. Sealing Caps Only in vehicles without air guide to vent installed in center console at rear.
  12. Dust and Pollen Filter With activated charcoal filter. Removing and installing, refer to «DUST AND POLLEN FILTER»(ref-479481-S03204578932012061300000) .
  13. Connection For center console air guide. To remove, center console must be removed. Refer to «Removal and Installation»(ref-479538-S30502900232012061300000) .
  14. Rear Channel For Right Footwell Removing and installing, refer to «REAR FOOTWELL CHANNEL»(ref-479481-S39497446752012061300000) .
  15. Rear Channel For Left Footwell Removing and installing, refer to «REAR FOOTWELL CHANNEL»(ref-479481-S39497446752012061300000) .
  16. Screw Quantity: 8 Varying lengths.
  17. Adapter For Controls Removing and installing, refer to «TEMPERATURE DOOR RELEASE CABLE»(ref-479481-S17282460622012061300000) .
  18. Auxiliary Heater Heating Element -Z35- Vehicles Through 1K-7M 119 726 With Auxiliary Air Heater Control Module -J604- Check using the Vehicle Diagnostic, Testing and Information System VAS 5051 (or succeeding model) under Heating & Air Conditioning, OBD-capable System; Auxiliary Heating; Electrical Components. Removing and installing, refer to «AUXILIARY AIR HEATER HEATING ELEMENT -Z35-, VEHICLES THROUGH 1K-7M 119 726»(ref-479481-S23443805962012061300000) . Vehicles From 1K-7M 119 726 A 3-stage Auxiliary Heater Heating Element -Z35- is installed here; it is controlled by each motor control module via relays. Only installed on vehicles with Diesel engine without auxiliary heater. Removing and installing, refer to «AUXILIARY HEATER HEATING ELEMENT -Z35-, VEHICLES FROM 1K-7M 119 727»(ref-479481-S29575686282012061300000) .
  19. Heat Exchanger After replacing heater core, replace all the coolant. Refer to «DRAINING AND FILLING»(ref-479567-S10974463242012061300000) or «DRAINING AND FILLING»(ref-479574-S30062936622012061300000) . Removing and installing, refer to «HEAT EXCHANGER»(ref-479481-S22104988452012061300000) .
  20. Left Footwell Vent Removing and installing, refer to «LEFT FOOTWELL VENT»(ref-479481-S16866426932012061300000) .
  21. Bowden Cable For Temperature Door Removing and installing, refer to «TEMPERATURE DOOR RELEASE CABLE»(ref-479481-S17282460622012061300000) .
  22. Flexible Shaft Removing and installing, refer to «FLEXIBLE AIR DISTRIBUTION SHAFT»(ref-479481-S09003388402012061300000) .
  23. Heater Unit Removing and installing, refer to «HEATER UNIT»(ref-479481-S31559526412012061300000) . Disassembling and assembling, refer to «HEATER UNIT»(ref-479481-S11008131012012061300000) .
  24. Left Side Vent

Scheme 54

Scheme 54: REMOVING HEATER PARTITION

Remove the plastic screws -2- and the partition -1-.

Scheme 55

Scheme 55

Seal is first inserted into bulkhead between heater and engine compartment -A-, then placed on heater core.

Note. To prevent water from entering vehicle interior, note the installation position.
