TELEPHONE SYSTEM OVERVIEW

The telephone system and telephone preparation primarily differ in that the telephone system has a factory-installed cell phone -R54-. Therefore, the following overview only illustrates the complete telephone system.

Scheme 1

Scheme 1: TELEPHONE SYSTEM OVERVIEW
  1. Telephone Antenna -R65- At the top of the rear window on the left side (Sedan). Roof antenna, Wagon. Roof antenna, Sedan, from MY 11. For the antenna on the Sedan, refer to «ANTENNA SYSTEMS»(ref-479603-S10044035902012061300000) .
  2. Telephone Baseplate -R126- On the right of the instrument panel. Removing and installing through 06.2006, refer to «TELEPHONE BASEPLATE -R126-, THROUGH 06.06»(ref-479603-S38982207742012061300000) . Removing and Installing, from 07.06. Refer to «TELEPHONE BASEPLATE -R126-, FROM 06.06»(ref-479603-S35980614022012061300000) .
  3. Telephone Transceiver -R36- Under the right front seat. Removing and installing through 06.06, refer to «TELEPHONE TRANSCEIVER -R36-, THROUGH 06.06»(ref-479603-S03489590942012061300000) Removing and installing, from 07.06, refer to «TELEPHONE TRANSCEIVER -R36-, FROM 07.06»(ref-479603-S36990250222012061300000) .
  4. Telephone Microphone -R38- In Front Interior Light -W1-. Removing and installing, refer to «TELEPHONE MICROPHONE -R38»(ref-479603-S30419621122012061300000) .
  5. Radio/RNS
  6. Speaker Systems
  7. Steering Column Electronic Systems Control Module -J527
  8. Multifunction Steering Wheel Refer to «MULTIFUNCTION STEERING WHEEL»(ref-479603-S35558672482012061300000) .
  9. CAN Bus
  10. Instrument Cluster

Scheme 2

Scheme 2: UHV LOW / UHV PREMIUM LIGHT OVERVIEW
  1. Instrument Cluster
  2. Multifunction Steering Wheel Refer to «MULTIFUNCTION STEERING WHEEL»(ref-479603-S35558672482012061300000) .
  3. Steering Column Electronic Systems Control Module -J527
  4. Telephone Antenna -R65- At the top of the rear window on the left side (Sedan). Roof antenna (Wagon). Roof antenna, Sedan, from MY 11. For the antenna on the Sedan, refer to one of the following: Through MY 2010, refer to «ANTENNA SYSTEMS»(ref-479603-S10044035902012061300000) .
  5. Cellular Telephone Preparation Control Head -E508- In Front Interior Light -W1-. Removing and installing, refer to «CELLULAR TELEPHONE PREPARATION CONTROL HEAD -E508»(ref-479603-S02192180152012061300000) .
  6. Telephone Transceiver -R36- Under the right front seat. Removing and Installing, from 07.06. Refer to «TELEPHONE TRANSCEIVER -R36-, FROM 07.06»(ref-479603-S36990250222012061300000) .
  7. Telephone Baseplate -R126- Does not apply to US vehicles.
  8. Cell phone -R54- Not obtained with vehicle. Refer to the Owner's Manual.
  9. Headset Not obtained with vehicle. Refer to the Owner's Manual.
  10. Laptop Not obtained with vehicle. Refer to the Owner's Manual.
  11. Telephone Microphone -R38- In Front Interior Light -W1- Removing and installing, refer to «TELEPHONE MICROPHONE -R38»(ref-479603-S30419621122012061300000) .
  12. Radio or Radio/Navigation Display Unit Control Module -J503
  13. Speaker System
  14. Data Bus On Board Diagnostic Interface -J533

Scheme 3

Scheme 3: TELEPHONE TRANSCEIVER -R36- CONNECTORS, THROUGH 06.06

A - Cell phone operating electronics control module -J412

B - 20-pin connector, red, to the Telephone baseplate -R126- (Does not apply to US vehicles)

C - Black 18-pin connector

Scheme 4

Scheme 4

1 - Terminal 31

4 - Telephone, mute to radio

7 - LF (-) to radio

8 - CAN bus, low

9 - Telephone Microphone -R38- (-)

10 - Terminal 15

11 - Terminal 30

12 - Terminal 58d

16 - LF (+) to radio

17 - CAN bus, high

18 - Telephone Microphone -R38- (+)

Scheme 5

Scheme 5: TELEPHONE TRANSCEIVER -R36- CONNECTORS, UHV

A - Connection (GSM) Telephone antenna -R65- only on UHV Premium Light

B - 54-pin connector

Scheme 6

Scheme 6

1 - Terminal 30

2 - Terminal 31

8 - LF (+) to radio

9 - LF (-) to radio

11 - Telephone Microphone -R38- (+)

12 - Telephone Microphone (-)

17 - CAN bus, high

18 - CAN bus, low

27 - Cellular Telephone Preparation Control Head -E508

28 - Cellular Telephone Preparation Control Head

30 - Cellular Telephone Preparation Control Head

31 - Cellular Telephone Preparation Control Head

37 - Telephone baseplate -R126- (Does not apply to US vehicles)

38 - Telephone baseplate (Does not apply to US vehicles)

39 - Telephone baseplate (Does not apply to US vehicles)

40 - Telephone baseplate (Does not apply to US vehicles)

44 - Telephone baseplate (Does not apply to US vehicles)

47 - Telephone baseplate (Does not apply to US vehicles)

48 - Telephone baseplate (Does not apply to US vehicles)

Scheme 7

Scheme 7: TELEPHONE SYSTEM INSTALLED LOCATIONS
  1. Telephone Baseplate -R126- Does not apply to US vehicles.
  2. Telephone Transceiver -R36- Under the right front seat. Connectors through 06.06, refer to «TELEPHONE TRANSCEIVER -R36- CONNECTORS, THROUGH 06.06»(ref-479603-S17181862192012061300000) . Connectors (UHV) refer to «TELEPHONE TRANSCEIVER -R36- CONNECTORS, UHV»(ref-479603-S04866797612012061300000) . Removing and installing through 06.06, refer to «TELEPHONE TRANSCEIVER -R36-, THROUGH 06.06»(ref-479603-S03489590942012061300000) . Removing and Installing, from 07.06, refer to «TELEPHONE TRANSCEIVER -R36-, FROM 07.06»(ref-479603-S36990250222012061300000) .
  3. Front Interior Lamp -W1- Telephone Microphone -R38- Cellular Telephone Preparation Control Head -E508- Removing and installing Telephone Microphone -R38-, refer to «TELEPHONE MICROPHONE -R38»(ref-479603-S30419621122012061300000) . Removing and installing cellular telephone preparation control head -E508-, refer to «CELLULAR TELEPHONE PREPARATION CONTROL HEAD -E508»(ref-479603-S02192180152012061300000) .
  4. Telephone Antenna -R65- At the top of the rear window on the left side (Sedan). Roof antenna (Wagon). Roof antenna, Sedan, from MY 11. For the antenna on the Sedan, refer to one of the following: Through MY 2010, refer to «ANTENNA SYSTEMS»(ref-479603-S10044035902012061300000) .
  5. Speaker System
  6. Radio/RNS

Scheme 8

Scheme 8: USB CONNECTION BASEPLATE -R193- CONNECTOR
  1. DATA IN
  2. CLOCK
  3. Terminal 31
  4. DATA OUT
  5. Not used
  6. Terminal 30
  7. Right audio
  8. Control signal from the radio
  9. Audio ground
  10. Left audio
  11. Not used
  12. Not used
