ENGINE CODE
Engines are identified by a 3-letter code stamped on the engine. For engine code locations (Scheme 3)- see scheme 6. Engine codes are also located on the vehicle data plate.
Note. The engine number for the 1.8L turbo can be found on the mating flange between the engine and transmission. The engine code is also imprinted on the front engine lift eyelet (visible after removing cover above fuel injectors).
Scheme 3
Scheme 4
Note. Engine code for 1.9L TDI is located between the diesel injection pump and the exhaust manifold on the engine block.
Scheme 5
Note. Engine code for 2.0L AEG is located on machined pad on front of cylinder block above crankcase breather.
Scheme 6
Note. Engine code and serial number for 2.0L AVH and AZG is located can be found on the flange between engine/transmission. Additionally there is a sticker on the timing belt guard containing the engine code and serial number. The engine code is also included on the vehicle data plate.
Scheme 7
Battery Fuse Panel
Battery fuse panel is located on battery. (Scheme 9)
Scheme 8
Scheme 9
| Fuse No. | Amp Rating | Circuits Protected | |
|---|---|---|---|
| 162 | |||
| Engine Codes AEG, AFP, AVH, AWW, AZG | 50 | Secondary Air Injector Pump | |
| Engine Code ALH | 50 | Preheating Coolant Relay (Low & High Heat) | |
| Engine Code AWW | 50 | Secondary Air Injector Pump (1) , Main Fuse Panel | |
| 163 | |||
| Engine Codes AEG, AFP, AVH, AWW, AZG | 50 | Fuel Pump | |
| Engine Code ALH | 50 | Glow Plug Relay | |
| 164 | 40 | Coolant Fan Control Module | |
| 176 | 110 | Ignition/Starter Switch, Power Supply Relay (B+ Terminal), Passenger Compartment Fuse Panel, Load Reduction Relay | |
| 177 | |||
| Engine Codes AEG, AVH, AZG | 110 | Generator | |
| Engine Codes AFP, ALH, AWW | 150 | Generator | |
| 178 | 30 | ABS Control Module | |
| 179 | 30 | ABS Control Module | |
| 180 | 30 | Coolant Fan Control Module, Coolant Fan Thermal Switch | |
| (1) Applies to manual transmission only. | |||
| (1) | Applies to manual transmission only. |
FUSE IDENTIFICATION (BATTERY FUSE PANEL)
Main Fuse Panel
For fuse position number, amp rating and description of circuits protected, see FUSE IDENTIFICATION (FUSE PANEL) table.
Note. Fuses 23 through 44 may be designated in wiring diagrams with a prefix of 2. For example, fuse No. 29 may be labeled as 229. Fuse No. 43 may be labeled as 243.
| Fuse No. | Amp Rating | Circuits Protected | |
|---|---|---|---|
| 1 | 10 | Glove Compartment Light, Washer Nozzle Heater (Left & Right), Memory Seat Control Module | |
| 2 (1) | 10 | Emergency Flasher Switch | |
| 3 | 5 | Instrument Panel Light Dimmer Switch, Fog Light Switch | |
| 4 | 5 | License Plate Light | |
| 5 | |||
| All Vehicles | 7.5 | Daytime Running Lights Change-Over Relay, Brake Pedal Switch (Brake Vacuum Vent Valve Switch), Heated Seat Control Module (Driver's & Passenger's), Outside Mirror Heating, Cruise Control Switch, Fresh Air/Recirculating Flap Switch, Automatic Day/Night Interior Mirror, Outside Mirror Switch, High Pressure Sensor, Coolant Fan Control Module, DLC | |
| Engine Code AFP | 7.5 | Clutch Vacuum Vent, Climate Control Module | |
| Engine Codes AVH, AWW, AZG | 7.5 | Cruise Control Switch, Clutch Vacuum Vent Valve Switch | |
| 6 | 5 | Comfort System Central Control Module | |
| 7 (1) | |||
| All Vehicles | 10 | Back-Up Light, Speedometer Vehicle Speed Sensor | |
| (2) | 10 | Park/Neutral Position Relay, Selector Lever Position Warning Light | |
| 8 | N/A | Vacant | |
| 9 | 5 | ABS Control Module | |
| 10 | |||
| Engine Codes AEG, AVH, AWW, AZG | 15 | Engine Control Module (ECM) | |
| Engine Code AFP | 10 | Engine Control Module (ECM) | |
| Engine Code ALH | 5 | Diesel Direct Fuel Injection Engine Control Module | |
| 11 | |||
| All Vehicles | 5 | Control Module W/Indicator Unit | |
| (2) | 5 | Control Module W/Indicator Unit, Shift Lock Solenoid | |
| 12 | 7.5 | DLC | |
| 13 | 10 | Brake Light Switch | |
| 14 | 10 | Comfort System Central Control Module, Remote Rear Lid Unlock Motor Relay | |
| 15 | 5 | Control Module W/Indicator Unit, Transmission Control Module (2) | |
| 16 | 10 | Coolant Fan Control Module | |
| 17 | N/A | Vacant | |
| 18 | 10 | High Beam Head Light, Headlight (Right), Fog Light Relay And Switch | |
| 19 | 10 | Headlight (Left) | |
| 20 | 15 | Head Light (Right) | |
| 21 | 15 | Head Light (Left) | |
| 22 | 5 | Control Module W/Indicator, Tail Light (Right), Parking Light (Right), Front Side Marker Light (Right) | |
| 23 | 5 | Control Module W/Indicator, Tail Light (Left), Parking Light (Left), Front Side Marker Light (Left) | |
| 24 | 20 | Wiper/Washer Intermittent Relay And Switch | |
| 25 | 25 | Climate Control Module, Fresh Air Blower Switch | |
| 26 | 25 | Rear Window Defogger Switch | |
| 27 | 15 | Rear Windshield Wiper Motor | |
| 28 | 15 | Fuel Pump | |
| 29 | |||
| Engine Codes AEG, AFP | 15 | Ignition Coils, Motronic Engine Control Module | |
| Engine Code ALH | 10 | Diesel Direct Fuel Injection Engine Control Module | |
| Engine Codes AVH, AWW, AZG | 15 | Motronic Engine Control Module | |
| 30 | 20 | Power Sunroof Control Module | |
| 31 (2) | |||
| Engine Codes AEG, AFP, AVH, AWW, AZG | 20 | Brake Booster Control Module, Transmission Control Module, Multi-Function Transmission Range Switch | |
| Engine Code ALH | 20 | Transmission Control Module, Multi-Function Transmission Range Switch | |
| 32 | |||
| Engine Codes AEG, AFP, AVH, AWW, AZG | 10 | Fluid Injectors | |
| Engine Code ALH | 30 | Fuel Quantity Adjuster, Diesel Direct Fuel Injection Engine Control Module | |
| 33 | 20 | Wiper/Washer Intermittent Relay | |
| 34 | |||
| Engine Codes AEG, AVH, AZG | 10 | Positive Crank Case Ventilation Heating Element | |
| Engine Code AFP | 10 | Brake Booster Vacuum Valve, Intake Manifold Change-Over Valve, Positive Crank Case Heating Element | |
| Engine Code ALH | 10 | Mass Air Flow Sensor, EGR Vacuum Regulator Solenoid Valve, Wastegate Bypass Regulator Valve, Change-Over Valve For Intake Manifold Flap, Cold Start Injector | |
| Engine Code AWW | 10 | Turbocharger Recirculating Valve, Wastegate Bypass Regulator Valve, Camshaft Adjustment Valve | |
| 35 | 30 | Luggage Compartment 12V Socket | |
| 36 | 15 | Fog Light Switch | |
| 37 (1) | 10 | Control Module W/Indicator Unit, Comfort System Central Control Module, Radio | |
| 38 | 15 | Comfort System Central Control Module, Remote Fuel Tank Door, Remote Unlock Rear Lid Motor Relay, Door Control Module (Driver Side Front, Driver Side Rear, Passenger Side Front, Passenger Side Rear) (3) | |
| 39 (4) | 15 | Emergency Flasher Switch | |
| 40 | 20 | Dual Horn Relay | |
| 41 | 15 | Cigarette Lighter | |
| 42 (4) | 25 | Radio, Amplifier | |
| 43 | |||
| Engine Codes AEG, AFP, AVH, AWW, AZG | 10 | Leak Detection Pump, Evaporative Emission Canister Purge Valve, Mass Air Flow Sensor, Oxygen Sensor, Heated Oxygen Sensor, Secondary Air Injector Solenoid Valve, Secondary Air Injector Pump Relay | |
| Engine Code ALH | 10 | Clutch Vacuum Vent Valve Switch (5) , Preheating Coolant Relay (5) , Brake Vacuum Vent Valve Switch (Cruise Control/Diesel), Positive Crankcase Ventilation Heating Element | |
| 44 (2) | 15 | Heated Seat Control Module (Driver's & Passenger's) | |
| (1) Ignition powered. (2) For 4-speed automatic transmission only. (3) Applies to vehicles equipped with power windows only. (4) Battery powered. (5) Manual transmission only. | |||
| (1) | Ignition powered. |
| (2) | For 4-speed automatic transmission only. |
| (3) | Applies to vehicles equipped with power windows only. |
| (4) | Battery powered. |
| (5) | Manual transmission only. |
FUSE IDENTIFICATION (FUSE PANEL)
| Fuse No. | Amp Rating | Circuits Protected |
|---|---|---|
| S51 (1) | 20 | ABS Vacuum Pump |
| S130 (1) | 40 | Secondary Air Injection Pump |
| (1) Located in left side of engine compartment, within protective housing. | ||
| (1) | Located in left side of engine compartment, within protective housing. |
MISCELLANEOUS FUSES
RELAY PANEL & THIRTEENFOLD AUXILIARY RELAY PANEL
For relay position within panels see scheme 11 Thirteenfold auxiliary relay panel is located above relay panel. For relay number, position number and circuits protected, see RELAY IDENTIFICATION (RELAY PANEL) and RELAY IDENTIFICATION (THIRTEENFOLD AUXILIARY RELAY PANEL) tables.
Note. Thirteenfold auxiliary relay panel is under driver's side of dash, behind lower instrument panel trim.
Scheme 10
| Position No. | Relay No. | Circuit Protected |
|---|---|---|
| 1 | J4 | Dual Horn |
| 2 | J59 | Load Reduction |
| 3 (1) | J207 | Starting Interlock |
| 4 | J17 | Fuel Pump |
| V | J31 | Wiper/Washer Intermittent |
| VI | J31 | Wiper/Washer Intermittent |
| (2) | S44 | Power (Memory) Circuit Breaker |
| (1) Manual transmission only. (2) Relay is installed in any free position, and is not allocated any specific position within 13-way relay carrier. | ||
| (1) | Manual transmission only. |
| (2) | Relay is installed in any free position, and is not allocated any specific position within 13-way relay carrier. |
RELAY IDENTIFICATION (RELAY PANEL)
| Position No. | Relay No. | Circuit Protected |
|---|---|---|
| 1 | N/A | Not Used |
| 2 | J398 | Remote Unlock Rear Lid Motor |
| 3 | J207 | Starting Interlock |
| 4 | J5 | Fog Light Relay |
| 5 | J453 | Multi-Function Steering Wheel Control Module |
| 6 | J453 | Multi-Function Steering Wheel Control Module |
| 7 | J89 | Daytime Running Lights |
| 8 | N/A | Not Used |
| 9 | N/A | Not Used |
| 10 (1) | J52 | Glow Plug |
| 11 (2) | J226 | Park/Neutral Position |
| 12 (1) | J317 | Power Supply (B+ Terminal) |
| 13 | N/A | Not Used |
| (1) Applies to vehicle equipped with engine (ALH) only. (2) Applies to vehicles equipped with 4-speed automatic only. | ||
| (1) | Applies to vehicle equipped with engine (ALH) only. |
| (2) | Applies to vehicles equipped with 4-speed automatic only. |
RELAY IDENTIFICATION (THIRTEENFOLD AUXILIARY RELAY PANEL)
Note. Fuse panel is located above thirteenfold auxiliary relay panel. For positions on thirteenfold auxiliary relay panel see scheme 11
| Position No. | Fuse No. | Amp Rating | Circuit Protected |
|---|---|---|---|
| (1) | S37 | 30 | Window Regulator |
| F | S111 | 15 | Alarm System And Anti-Theft |
| G | S144 | 15 | Central Locking/Anti-Theft Warning System |
| (1) Manufacturer does not specify position of fuse. Available positions are "D" and "E". | |||
| (1) | Manufacturer does not specify position of fuse. Available positions are "D" and "E". |
FUSE IDENTIFICATION (THIRTEENFOLD AUXILIARY RELAY PANEL)
