Windshield, installing Volkswagen Jetta IV

Windshield, installing

Preparing undamaged window for glazing. Refer to Preparing undamaged window for glazing .

Preparing new window for glazing. Refer to Preparing new window for glazing .

Preparing window flange for glazing. Refer to Preparing window flange for glazing .

Installation notes. Refer to Installation notes .

Minimum curing time. Refer to Minimum curing time .

Scheme 163

1 - Side window

1. Remove side window. Refer to «Undamaged side window, removing»(ref-255029-S08730896302007052300000)
2. Installing side window. Refer to «Side window, installing»(ref-255029-S21546934772007052300000)

2 - Ceramic coating

3 - Sealing lip (component part of pre-coating)

4 - PUR adhesive sealant

1. Bead cross section
2. Width = 7 mm
3. Height = 11 mm (including pre-coating, residual material on window glass and window flange)
4. Minimum curing time. Refer to «Minimum curing time»(ref-255029-S39419892102007052300000)

5 - Gap dimension - a - = 56 mm

1. Gap dimension must be maintained since distance is necessary for securing roof base carrier
