Windshield Wiper/washer System: Overview Volkswagen Golf Mk7

WINDSHIELD WASHER SYSTEM OVERVIEW

Note. Three different versions of reservoir for windshield washer and headlamp cleaning systems are installed, depending on the vehicle equipment level. Illustration shows the version for vehicles without parking heater.

Scheme 13

1. Y-Connection
2. Right Spray Nozzle For Windshield Washer System Removing and installing, refer to «WINDSHIELD SPRAY NOZZLES»(ref-480975-S34996793032012061900000) . Adjusting, refer to «WINDSHIELD WASHER SYSTEM SPRAY NOZZLES, ADJUSTING»(ref-480975-S34613438112012061900000) .
3. Left Spray Nozzle For Windshield Washer System Removing and installing, refer to «WINDSHIELD SPRAY NOZZLES»(ref-480975-S34996793032012061900000) . Adjusting, refer to «WINDSHIELD WASHER SYSTEM SPRAY NOZZLES, ADJUSTING»(ref-480975-S34613438112012061900000) .
4. Angle Coupling Connection at spray nozzle for windshield washer system, left. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-480975-S27454511412012061900000) .
5. Hose Hose repair, refer to «HOSES, REPAIRING»(ref-480975-S16191706132012061900000) .
6. Angle Coupling Connection at spray nozzle for windshield washer system, right. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-480975-S27454511412012061900000) .
7. Filler Tube For Tank For Windshield Washer System and Headlamp Cleaning System Removing and installing, refer to «WINDSHIELD AND HEADLAMP WASHER FLUID RESERVOIR FILLER NECK»(ref-480975-S11845415722012061900000) .
8. Filler Tube Connecting Tube To Reservoir Removed and installed together with reservoir.
9. Washer Fluid Reservoir Removing and installing, refer to «WINDSHIELD AND HEADLAMP WASHER SYSTEM RESERVOIR»(ref-480975-S14327552762012061900000) . Removing and installing (GTI), refer to «WINDSHIELD AND HEADLAMP WASHER FLUID RESERVOIR, GTI»(ref-480975-S11557203632012061900000) .
10. Windshield and Rear Window Washer Pump -V59- Removing and installing, refer to «WINDSHIELD AND REAR WINDOW WASHER PUMP -V59»(ref-480975-S36787832172012061900000) .
11. Angle Coupling Connection to Windshield and Rear Window Washer Pump -V59-. Washer hose couplings, overview, refer to «WASHER FLUID LINE HOSE CONNECTIONS»(ref-480975-S27454511412012061900000) .
12. Windshield Washer Fluid Level Sensor -G33- Removing and installing, refer to «WINDSHIELD WASHER FLUID LEVEL SENSOR -G33»(ref-480975-S18603814462012061900000) .

1. Windshield and headlamp washer fluid reservoir to body - 8 Nm.

Scheme 14

1. Mounting Nuts, Wiper Arm To Linkage 20 Nm
2. Windshield Wiper Removing and installing, refer to «JOINT-FREE WINDSHIELD WIPER»(ref-480975-S04223076712012061900000) . Adjusting park position, refer to «WINDSHIELD WIPER BLADES, ADJUSTING PARK POSITION»(ref-480975-S04284023982012061900000) .
3. Wiper Arms Removing and installing, refer to «WINDSHIELD WIPER ARMS»(ref-480975-S31545094722012061900000) .
4. Bolts For Wiper Frame With Linkage To Body 8 Nm
5. Wiper Frame With Linkage Removing and installing, refer to «WIPER FRAME WITH LINKAGE AND WIPER MOTOR, REMOVING»(ref-480975-S12661769642012061900000) .
6. Windshield Wiper Motor -V- with Wiper Motor Control Module -J400- For removing and installing the wiper frame, refer to «WIPER MOTOR»(ref-480975-S02099725502012061900000) . Wiper Motor Control Module -- Coding/Deactivating the APP Function, refer to «WIPER MOTOR ALTERNATING PARK POSITION FUNCTION, DEACTIVATING»(ref-480975-S32234528302012061900000) .
7. Rubber Grommet In The Bulkhead Note installation instructions, refer to «WINDSHIELD WIPER SYSTEM»(ref-480975-S05059340262012061900000) .

1. Screws, windshield wiper motor to wiper frame and linkage - 8 Nm.
2. Windshield wiper motor crank to windshield wiper motor shaft - 18 Nm.
