POWER FORWARD/BACK ADJUSTMENT UNIT
The following describes removing and installing the seat forward/back adjustment on the left front seat frame. Removal and installation of the right seat longitudinal adjuster is performed in the same way.
Removing
Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095.
Remove the front seat. Refer to FRONT SEAT .
Attach the seat to the fixture for seat repairVAS 6136.
Remove front right seat trim. Refer to RIGHT SEAT TRIM
Remove left power seat trim. Refer to LEFT POWER SEAT TRIM
Remove retainer and power seat bracket. Refer to POWER SEAT BRACKET AND SUPPORT
Remove front seat drawer mount. Refer to SEAT DRAWER MOUNT
Remove front seat backrest. Refer to LEFT FRONT SEAT BACKREST
Remove cover and cushion from front seat backrests. Refer to FRONT SEAT PAN COVERS AND CUSHION
Remove screws -1- and -2- on right side.
Remove screw -3- in rear area.
Note. Screw -3- in installation position points from inside toward outside.
Remove screw -4- in front area.
Remove seat pan -5- from longitudinal adjuster -6-.
Scheme 71
Installing
Install in reverse order of removal.
POWER SEAT ANGLE ADJUSTMENT UNIT
Removal and installation of seat inclination adjuster is described for left backrest frame. Removal and installation of the right seat inclination adjuster is performed in the same way.
Removing
Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095.
Remove the front seat. Refer to FRONT SEAT .
Attach the seat to the fixture for seat repairVAS 6136.
Remove front right seat trim. Refer to RIGHT SEAT TRIM
Remove left power seat trim. Refer to LEFT POWER SEAT TRIM
Remove retainer and power seat bracket. Refer to POWER SEAT BRACKET AND SUPPORT
Remove front seat drawer mount. Refer to SEAT DRAWER MOUNT
Remove front seat backrest. Refer to LEFT FRONT SEAT BACKREST
Remove cover and cushion from front seat backrests. Refer to FRONT SEAT PAN COVERS AND CUSHION
Disconnect wiring harness -1- from inclination adjuster -2-.
Remove the bolt -3-.
Remove the two sets of bolts -4- and -5-.
Remove inclination adjustment -2- from seat frame.
Scheme 72
Installing
Install in reverse order of removal.
POWER SEAT HEIGHT ADJUSTMENT UNIT
Removal and installation of seat height adjuster is described for left backrest frame. Removal and installation of the right seat height adjuster is performed in the same way.
Removing
Mount the fixture for seat repairVAS 6136 on the engine and transmission holderVAS 6095.
Remove the front seat. Refer to FRONT SEAT .
Attach the seat to the fixture for seat repairVAS 6136.
Remove front right seat trim. Refer to RIGHT SEAT TRIM
Remove left power seat trim. Refer to LEFT POWER SEAT TRIM
Remove retainer and power seat bracket. Refer to POWER SEAT BRACKET AND SUPPORT
Remove front seat drawer mount. Refer to SEAT DRAWER MOUNT
Remove front seat backrest. Refer to LEFT FRONT SEAT BACKREST
Remove cover and cushion from front seat backrests. Refer to FRONT SEAT PAN COVERS AND CUSHION
Remove screw -1- in rear area of seat base.
Note. Screw -1- in installation position points from inside toward outside.
Disconnect wiring harness -2- from height adjuster -3-.
Remove the two bolts -4-.
Remove height adjuster -3- from mounts in seat base.
Scheme 73
Installing
Install in reverse order of removal.
POWER SEAT BACKREST ADJUSTMENT MOTOR
If backrest adjustment motor is faulty, backrest frame must be replaced.
