IGNITION COIL WITH POWER OUTPUT STAGE
Special Tools And Workshop Equipment Required
- Ignition Coil Puller T40039
- Special Lubricant G 052 141 A2
Removing
Note. To remove from the spark plugs, place the ignition coil puller T40039 on the top most thick rib -arrow- of the ignition coil with power output stage. The lower ribs may be damaged if they are used.
Remove the engine cover with air filter. Refer to ENGINE COVER WITH AIR FILTER .
Disconnect the connector -arrow- from the secondary air injection solenoid valve -N112-, if applicable.
Scheme 18
In order to prevent damage to the wire guide, remove the ignition coil with power output stage as follows
Pull all the ignition coils approximately 10 mm out of the spark plug shaft using the ignition coil puller T40039 Start with ignition coil -1-.
Scheme 19
Then, pull out all ignition coils a further 10 mm in the same sequence.
Disengage all connectors and pull them out only slightly.
Disconnect all the connectors -A- starting at ignition coil -1- and remove the ignition coils from the spark plug shaft.
Scheme 20
Installing
Insert all ignition coils loosely into the spark plug shaft.
Align the ignition coils to the recesses in the cylinder head cover. Connect all the connectors to the ignition coils in the opposite order.
Press the ignition coils evenly onto the spark plugs by hand.
