INSTRUMENT CLUSTER GENERAL INFORMATION
Note. Additional information
General Description
The following components are integrated in the instrument cluster
- Instrument Cluster Control Module -J285
- Anti-Theft Immobilizer Control Module -J362
- Speedometer
- Tachometer
- Fuel gauge
- Coolant temperature gauge
- Multifunction indicator
- Indicator lamp, refer to «WARNING LAMP SYMBOLS IN INSTRUMENT PANEL INSERT»(ref-480959-S26576819572012061900000) .
To audibly support the visual displays of the instrument panel insert, the control module activates a warning buzzer.
All indicator lamps have LEDs. Servicing the instrument cluster is not planned. In the event of malfunctions, the complete instrument cluster must be replaced. Refer to INSTRUMENT CLUSTER, REPLACE .
The Data Bus On Board Diagnostic Interface -J533- (Gateway) is designed as a separate control module and not a component of the instrument cluster as it is for various other vehicles. Refer to DATA BUS ON BOARD DIAGNOSTIC INTERFACE, GATEWAY .
DTC Recognition and Display
The instrument cluster is equipped with On Board Diagnostic (OBD) capabilities which assists with troubleshooting.
Use the Vehicle Diagnosis, Testing and Information System VAS 5051A under "Guided Fault Finding".
Scheme 1
Note. Do not disassemble instrument cluster. In the event of malfunctions, replace complete instrument cluster.
- Warning buzzer
- 32-pin harness connector
