DRIVE AXLE TWELVE-POINT BOLT, LOOSENING AND TIGHTENING
Special tools and workshop equipment required
- Socket XZN 24 T10361
- Angle wrench V.A.G 1756
Wheel bearing must not be burdened while drive axle threaded connection on the wheel side is loose.
If the bearings are loaded by the vehicle's own weight the wheel bearing will be damaged. The wheel bearings will be stressed and the life expectancy reduced. Therefore, observe the following
- Procedure for loosening 12-point bolt.
Vehicles without drive axle must not be moved, otherwise wheel bearing will be damaged. If vehicle must be moved, observe the following
Install an outer joint in place of the drive axle.
Tighten outer joint to 120 Nm.
Loosening
With vehicle still resting on wheels, loosen 12-point bolt with T10361 maximum 90°, otherwise, wheel bearing will be damaged.
Raise vehicle enough that wheels hang freely.
Operate brake (second mechanic required).
Remove 12-point bolt -arrow-.
Scheme 1
Tightening
Replace 12-point bolt.
Note. Wheels must not yet touch the ground to tighten the drive axle, wheel bearing may otherwise be damaged.
Operate brake (second mechanic required).
Tighten 12-point bolt to 70 Nm.
Lower vehicle onto its wheels.
Tighten 12-point bolt an additional 90°.
FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| ABS Wheel Speed Sensor to Wheel Bearing Housing Bolt | 8 | |
| Ball Joint to Steel Control Arm Nut (1) | 60 | |
| Ball Joint to Sheet Steel or Aluminum Control Arm Nut (1) | 100 | |
| Ball Joint to Wheel Bearing Housing Nut (1) | M12 x 1.5 | 60 |
| Console to Body Bolt (1) | M12 x 1.5 x 90 | 70 + 90° turn |
| Control Arm to Console Bolt (1) , (2) | M12 x 1.5 x 110 | 70 + 180° turn |
| Coupling Rod to Stabilizer Bar Nut (1) | 65 | |
| Coupling Rod to Suspension Strut Nut (1) | 65 | |
| Cover Plate to Wheel Bearing Housing Bolt | 10 | |
| CV Boot Hose Clamp | 25 | |
| Drive Axle Heat Shield | ||
| FWD Bolt | 25 | |
| AWD Nut (3) | 20 | |
| Drive Axle to Transmission Bolt (1) , (4) | ||
| With CV Joint VL90 and VL100 | M8 x 48 | 40 |
| With CV Joint VL107 | M10 x 52 | 70 |
| With Triple Roller Joint AAR3300i | M10 x 23 | 70 |
| Drive Axle to Wheel Hub Bolt (1) | 70 + 90° turn | |
| Level Control System Sensor to Console Bolt | M6 x 16 | 9 |
| Level Control System Sensor to Control Arm Nut (1) | 9 | |
| Mounting Bracket to Body Bolt (1) | M12 x 1.5 x 90 | 70 + 90° turn |
| Mounting Bracket to Subframe Bolt (1) | 50 + 90° turn | |
| Pendulum Support to Subframe Bonded Rubber Bushing Bolt | M14 x 1.5 x 70 | 100 + 90° turn |
| Pendulum Support to Transmission Bolt (1) | 50 + 90° turn | |
| Shield to Subframe | M6 | 6 |
| Steering Column Universal Joint to Steering Gear Bolt | 30 | |
| Steering Gear to Subframe Bolt (1) | 50 + 90° turn | |
| Stabilizer Bar to Subframe Bolt (1) | 20 + 90° turn | |
| Subframe to Body Bolt (1) | 70 + 90° turn | |
| Suspension Strut to Suspension Strut Bearing Nut (1) | M14 x 1.5 | 60 |
| Suspension Strut to Suspension Strut Dome Bolt (1) | 15 + 90° turn | |
| Suspension Strut to Wheel Bearing Housing Nut (1) | 70 + 90° turn | |
| Tie Rod End to Wheel Bearing Housing Nut (1) | 20 + 90° turn | |
| Wheel Hub to Wheel Bearing Housing Bolt (1) | 70 + 90° turn | |
| (1) Always replace after removal. (2) Always tighten threaded connections in curb weight position. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION . (3) Pre-tighten all nuts to 10 Nm. (4) Pre-tighten to 10 Nm in a diagonal sequence, then tighten to tightening specification in a diagonal sequence. | ||
| (1) | Always replace after removal. |
| (2) | Always tighten threaded connections in curb weight position. Refer to WHEEL BEARING, LIFTING TO CURB WEIGHT POSITION . |
| (3) | Pre-tighten all nuts to 10 Nm. |
| (4) | Pre-tighten to 10 Nm in a diagonal sequence, then tighten to tightening specification in a diagonal sequence. |
TIGHTENING HOSE CLAMP ON OUTER JOINT
Attach V.A.G 1682 as shown in illustration. Be sure that edges of clamping pliers are seated in corners -arrows B- of hose clamp.
Tension clamp by turning spindle with a torque wrench (do not tilt clamp tool).
Note. A stainless steel clamp must be used due to hardness of CV boot material (compared to rubber). This clamp can only be tensioned using V.A.G 1682. Torque specification: 25 Nm. Use torque wrench -C- with adjustment range 5...50 Nm (e.g. torque wrench V.A.G 1331). Be sure thread of spindle -A- of clamp tool moves freely. Grease with MOS 2 grease if necessary. If it does not move freely, e.g. due to dirt in thread, the required clamp tension will not be achieved at the specified torque.
Attach V.A.G 1682 as shown in illustration. Be sure that edges of clamping pliers are seated in corners -arrows B- of hose clamp.
Tension clamp by turning spindle with a torque wrench (do not tilt clamp tool).
Note. A stainless steel clamp must be used due to hardness of CV boot material (compared to rubber). This clamp can only be tensioned using V.A.G 1682. Torque specification: 25 Nm. Use torque wrench -C- with adjustment range 5...50 Nm (e.g. torque wrench V.A.G 1331). Be sure thread of spindle -A- of clamp tool moves freely. Grease with MOS 2 grease if necessary. If it does not move freely, e.g. due to dirt in thread, the required clamp tension will not be achieved at the specified torque.
Attach V.A.G 1682 as shown in illustration. Be sure that edges of clamping pliers are seated in corners -arrows B- of hose clamp.
Tension clamp by turning spindle with a torque wrench (do not tilt clamp tool).
TIGHTENING THE TENSIONING CLAMP ON THE SMALLER DIAMETER ON THE INNER/OUTER JOINT
CV joint, checking function, refer to CV JOINT, CHECKING FOR FUNCTION .
