2.0L - Cooling System - Engine Code(s): Cjaa: Overview Volkswagen Golf Mk7

Cooling Fan 2 illustrations ~288 words

COOLING SYSTEM COMPONENTS OVERVIEW, ENGINE SIDE

Coolant hose connection diagram. Refer to COOLANT HOSE CONNECTION DIAGRAM .

Scheme 1

Scheme 1: COOLING SYSTEM COMPONENTS OVERVIEW, ENGINE SIDE
  1. Lower Coolant Hose, to Expansion Tank
  2. Upper Coolant Hose, to Expansion Tank
  3. Bolt 10 Nm
  4. Ventilation Pipe
  5. Engine Coolant Temperature Sensor -G62
  6. Retaining Clip
  7. O-ring Always replace.
  8. Transmission Oil Cooler Only on vehicles with the Direct Shift Gearbox (DSG).
  9. Engine Oil Cooler Coolant Supply Hose On vehicles without a transmission fluid cooler. On vehicles with a transmission oil cooler: Transmission oil cooler coolant return line.
  10. Engine Oil Cooler Coolant Return Hose Coolant hose connection diagram. Refer to «COOLANT HOSE CONNECTION DIAGRAM»(ref-480924-S33593852222012061900000) .
  11. to the Radiator, Upper Connection
  12. Bracket for Wiring Harness and Coolant Pipe
  13. Coolant Hose To the coolant pipe on the cylinder block.
  14. Coolant Hoses For the transmission oil cooler. Only on vehicles with the DSG. Installed depending on the vehicle equipment level.
  15. Coolant Line Not available in the US/Canadian market. Installed depending on the vehicle equipment level For the engine pre-warmer.
  16. Engine Pre-Warmer Not available in the US/Canadian market. Installed depending on the vehicle equipment level.
  17. Engine Oil Cooler
  18. 4/2-Way Valve With the coolant thermostat. Removing and installing, refer to «4/2-WAY VALVE WITH THERMOSTAT»(ref-480924-S30384473772012061900000) .
  19. Bolt 15 Nm
  20. Hose to the Radiator Lower Connection
  21. Coolant Pump
  22. Bolt 15 Nm

COOLING SYSTEM COMPONENTS OVERVIEW, TRANSMISSION SIDE

Coolant hose connection diagram. Refer to COOLANT HOSE CONNECTION DIAGRAM .

Scheme 2

Scheme 2: COOLING SYSTEM COMPONENTS OVERVIEW, TRANSMISSION SIDE
  1. Coolant Supply Hose
  2. Coolant Hose to the Ventilation Pipe
  3. Exhaust Gas Recirculation (EGR) Cooler Coolant Return Hose
  4. Coolant Return Hose
  5. Heater Core Coolant Supply Hose
  6. Heater Core Coolant Return Hose
  7. EGR Cooler Coolant Supply Hose
  8. Transmission Oil Cooler Coolant Supply Hose
  9. Transmission Oil Cooler
  10. Transmission Oil Cooler Coolant Return Line
