AM FREQUENCY FILTER
Removing
Perform the following steps before starting
Switch off ignition, switch off all electrical consumers and remove ignition key.
The rear lid trim panel must be removed first in order to be able to replace the AM frequency filter.
Remove the red circlip -1- in -direction of arrow- from the connector housing. Press the release -2- and disconnect the connector.
Scheme 35
Do the same with the other two connectors.
Remove the 3 screws -arrows- and remove the frequency filter.
Scheme 36
Installing
Install in reverse order of removal.
Scheme 37
View of removed amplifier
Perform the following steps before starting
Switch off ignition, switch off all electrical consumers and remove ignition key.
Amplifier is installed under front left seat.
Move seat into uppermost and rearmost position.
Unclip the cover on the bottom of the seat in -direction of arrow-.
Scheme 38
Remove screws -arrows- on amplifier.
Scheme 39
Pull out the amplifier just far enough until the connector is accessible.
Move the lever in -direction of arrow-. This will push the connector out of the amplifier.
Scheme 40
Remove amplifier.
Installing
Install the amplifier in -direction of arrow-.
Scheme 41
When installing the amplifier, be sure to slide it in -direction of arrow A- so that it fits into the notch -arrow B-.
Scheme 42
Further installation is in the reverse sequence to removal.
