Instrument cluster — Electronic compass circuit Volkswagen Golf Mk6
All systems — 32 systems
- Air conditioning 3
- Anti-lock brakes 2
- Anti-theft 3
- Body control modules 4
- Computer data lines
- Cooling fan
- Cruise control 2
- Defoggers 2
- Electronic power steering
- Electronic suspension
- Engine performance 2.0l turbo diesel
- Engine performance 2.5l 2
- Exterior lights 4
- Ground distribution 2
- Headlights 4
- Horn 2
- Instrument cluster 2
- Interior lights 2
- Navigation 3
- Power distribution 2
- Power door locks 2
- Power mirrors 3
- Power seats 3
- Power top/sunroof
- Power windows 2
- Radio 5
- Shift interlock 4
- Starting/charging 2
- Supplemental restraints 4
- Transmission 5
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 6
Click a component to highlight it on every diagram it appears on.
