LEVEL CONTROL SYSTEM SENSOR
The level control system transmits the vehicle inclination in the form of a signal to the automatic headlamp range control system. The level control system determines this signal from all of the signals transmitted by the level control system sensors.
The vehicle level control system sensor is a component of the level control system. For removing and installing the vehicle level sensor, refer to Removal and Installation
Note. The illustrations show how to replace the left parking lamp -M1-. Replacing the right parking lamp bulb -M3- in the right headlamp is identical. It is not necessary to remove the headlamp in order to remove the parking lamp bulb.
Removal
Switch off ignition, switch off all electrical consumers and remove ignition key.
Turn the cap -2- to the left and remove it.
Pull the bulb socket -1- together with the parking lamp bulb out of the reflector. Pay attention to the wires still connected.
Scheme 83
Pull the parking lamp bulb -1- out of the bulb socket -2- in -direction of arrow-.
Scheme 84
Parking lamp bulb: Bulb 12V, 5W
Installation
| CAUTION | When installing the cover cap, make sure the cap is properly seated. It is destroyed by entry of water into headlamp. |
Note. Do not touch the glass of the light bulb, when installing. Your fingers will leave traces of grease on the glass which, when the light is switched on, will evaporate and cloud the glass.
Install in reverse order of removal, noting the following
Check headlamp for function.
