Installing Volkswagen Golf Mk4

Body Exterior (A4 Platform) 10 illustrations ~1068 words

Installing

  1. Engage locking clamp again.
  2. Position lock cylinder housing on to grip piece and lock in handle with an audible click.
  3. Then proceed in reverse order of removal.

Scheme 49

Scheme 49: Lock cylinder housing, removing and installing
Scheme 49: Lock cylinder housing, removing and installing

1 - Handle

2 - Guide sleeves

3 - Handle recess

4 - Seal

5 - Retaining clip

6 - Pin

7 - Circlip

8 - Spring

9 - Seal

10 - Lock cylinder housing

  1. Removing
  1. Unclip lid trim (handle is secured with a bolt).
  2. Unclip pull lever for lid lock (operating rod for central locking system if necessary), pry out locking clamp and remove lock cylinder housing from grip plate.

11 - Rod clip

  1. For lid lock

12 - Rod clip

  1. For actuator

Special tools, testers and auxiliary items required

  1. Socket wrench T10010
  1. Adjusting gauge 3371

Scheme 50

Scheme 50: Rear lid (Jetta), assembly overview
Scheme 50: Rear lid (Jetta), assembly overview

1 - Rear lid

  1. Adjusting. Refer to «Rear lid, adjusting»(ref-255029-S36666250122007052300000)

Lid adjustment if performed as for Golf

  1. Gap dimension Body panel gaps; Body, rear

2 - Trim

  1. Removing and installing. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)

3 - Rubber stop

  1. Adjusting. Refer to «Rear lid, adjusting»(ref-255029-S36666250122007052300000)

4 - Hex nuts

  1. 22 Nm

5 - Hinge

6 - Bolt

  1. 22 Nm

7 - Rubber buffer

8 - Gas-filled strut

  1. Removing and installing. Refer to «Gas-filled strut, removing»(ref-255029-S22621477912007052300000)
  2. Venting gas. Refer to «Releasing gas from gas-filled strut»(ref-255029-S24683639752007052300000)

9 - Lock plate

  1. adjusting - within elongated holes
  2. Gap dimension Body panel gaps; Body, rear

10 - Bolt

  1. 22 Nm

11 - Lock plate

  1. Only for USA

12 - Pop rivet

  1. Tighten using Pop rivet tongs V.A.G 1765 A

13 - Identification plate

  1. Press on only on hatched area
  2. Replacement part has two foils. First foil covers adhesive surface, second must be removed after installing.

14 - Wire

15 - Hinge cover

Scheme 51

Scheme 51: Rear lid lock, removing and installing (Jetta)
Scheme 51: Rear lid lock, removing and installing (Jetta)

1 - Lock cylinder housing

  1. Removing and installing. Refer to «Lock cylinder housing, removing and installing»(ref-255029-S40992495752007052300000)

2 - Handle

  1. Removing. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)
  1. Remove bolt , disconnect connector for switch and remove handle from lid.

3 - Switch for rear lid release E165

4 - Rear Lid

5 - Lock

  1. Removing. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)
  1. Disconnect connector from lock.

6 - Hex nut

  1. 7 Nm

7 - Actuator lever with linkage clip

8 - Motor for rear lid release V139

  1. Removing. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)
  1. Disconnect connector from motor.
  2. Remove nuts and remove carrier plate.
  3. Remove motor for rear lid release from carrier plate.

9 - Actuator lever

10 - Hex nut

  1. 7 Nm

11 - Actuator rod

12 - Support bracket

13 - Actuator rod

14 - Bolt

  1. 7 Nm

Scheme 52

Scheme 52: Lock cylinder housing, removing and installing
Scheme 52: Lock cylinder housing, removing and installing

1 - VW-symbol

  1. consisting of emblem carrier and message
  2. To install VW symbol, remove protective foil and adhere to lock cylinder housing using two-sided adhesive tape

2 - Lock cylinder housing

  1. Removing
  1. Remove rear lid trim. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)
  2. Disconnect connector for micro-switch / wiring harness.
  3. Remove operating rod at actuator lever.
  4. Remove screws (3x).
  1. Remove lock cylinder housing with VW symbol from rear lid.
  1. Installing

Installation is performed in reverse order of removal.

3 - Micro-switch

  1. For vehicles with central locking system
  2. For vehicles without central locking system
  3. Allocation Original parts distributor
  4. Removing and installing. Refer to «Micro-switch, removing and installing»(ref-255029-S02117316362007052300000)

4 - Linkage clip

  1. To remove operating rod, disconnect linkage clip and pull open

5 - Seal

  1. Attached in area of lock cylinder housing

6 - Bolt

  1. Qty. 3
  2. 4 Nm

7 - Bolt

  1. Qty. 2
  2. 0.3 Nm

Scheme 53

Scheme 53: Removing
Scheme 53: Removing
  1. Removing and installing lock cylinder housing - 2 -. Refer to «Lock cylinder housing, removing and installing»(ref-255029-S40992495752007052300000) .
  2. Release catches at micro-switch - 1 -.

To do so, press catches downward - arrow -.

Scheme 54

Scheme 54
Scheme 54
  1. Disengage catches - arrows - of micro-switch - 1 - from lock cylinder housing - 2 -.
  2. Remove micro-switch - 1 - from lock cylinder - 2 -.

Scheme 55

Scheme 55: Installing
Scheme 55: Installing
  1. Secure wires - 1 - and - 2 - in retaining profile - arrow - of micro-switch - 3 -.
  1. Lock catches - arrows - of micro-switch - 1 - into lock cylinder housing - 2 -.

Scheme 56

Scheme 56
Scheme 56
  1. Make sure that micro-switch is positioned with securing tabs - arrows - on lock cylinder housing - 1 -.
  2. Before locking micro-switch, if must be checked that wires are lying correctly in retaining profile of micro-switch and lock cylinder. If this is not case and micro-switch is locked, wires/micro-switch may be damaged.
  1. Lock micro-switch - 1 - with lock cylinder housing - 2 -. Make sure that catch - arrow - is locks correctly.
  2. Install lock cylinder housing. Refer to «Lock cylinder housing, removing and installing»(ref-255029-S40992495752007052300000)

Scheme 57

Scheme 57: Rear lid (Jetta Wagon), assembly overview
Scheme 57: Rear lid (Jetta Wagon), assembly overview

1 - Rear lid

  1. Adjusting. Refer to «Rear lid, adjusting»(ref-255029-S36666250122007052300000)
  2. Gap dimension Body panel gaps; Body, rear

2 - Trim

  1. Removing and installing. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)

3 - Rubber stop

  1. Adjusting. Refer to «Rear lid, adjusting»(ref-255029-S36666250122007052300000)

4 - Gas-filled strut

  1. Removing and installing. Refer to «Gas-filled strut, removing»(ref-255029-S22621477912007052300000)
  2. Venting gas. Refer to «Releasing gas from gas-filled strut»(ref-255029-S24683639752007052300000)

5 - Ball stud

  1. 10 Nm

6 - Bolt

  1. 22 Nm

7 - Closure plate

  1. Adjusting - within elongated holes
  2. Gap dimension Body panel gaps; Body, rear

8 - Cap

9 - Pop rivet

10 - Hex nuts

  1. 22 Nm

11 - Hinge

12 - Bolt

  1. 10 Nm

13 - Identification plate

  1. Press on only on hatched area
  2. Replacement part has two foils. First foil covers adhesive surface, second must be removed after installing.

14 - Internally threaded pop rivet

  1. Tighten using Pop rivet tongs V.A.G 1765 A

Scheme 58

Scheme 58: Rear lid lock, removing and installing
Scheme 58: Rear lid lock, removing and installing

1 - Lock cylinder housing

  1. Removing and installing. Refer to «Lock cylinder housing, removing and installing»(ref-255029-S32801217882007052300000)

2 - Handle

  1. Removing. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)
  1. Remove bolt , disconnect connector for switch and remove handle from lid.

3 - Tailgate/trunk lid release switch E165

4 - Bolt

  1. 7 Nm

5 - Carrier plate

6 - Operating rod

7 - Nut

  1. 7 Nm

8 - Tailgate/trunk lid release motor V139

  1. Removing. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)
  1. Disconnect connector from motor.
  2. Unclip operating rod from lock cylinder housing.
  3. Unclip operating rod from motor for rear lid release.
  4. Remove hex nuts and remove carrier plate.
  1. Remove motor for rear lid release from carrier plate.

9 - Operating rod

10 - Bolt

  1. 22 Nm

11 - Lock

  1. Removing
  1. Remove lid trim. Refer to «70 - INTERIOR TRIM»(ref-255030-S15969850052007052300000)
  2. Disconnect connector from lock.

12 - Rear lid

13 - Actuator lever with linkage clip
